from Konstantin Ryabitsev

Many people know that you can PGP-sign git objects — such as tags or commits themselves — but very few know of another attestation feature that git provides, which is signed git pushes.

Why sign git pushes? And how are they different from signed tags/commits?

Signed commits are great, but one thing they do not indicate is intent. For example, you could write some dangerous proof-of-concept code and push it into refs/heads/dangerous-do-not-use. You could even push it into some other fork hosted on a totally different server, just to make it clear that this is not production-ready code.

However, if your commits are PGP-signed, someone could take them and replay over any other branch in any other fork of your repository. To anyone checking the commit signatures, everything will look totally legitimate, as the actual commits are signed by you — never mind that they contain dangerous vulnerable code and were never intended to be pushed into something like refs/heads/next. At the very least, you will look reckless for pushing bad code, even though you were just messing around in a totally separate environment set up specifically for experimentation.

To help hedge against this problem, git provides developers a way to sign their actual pushes, as a means to attest “yes, I actually did intend to push these commits into this ref in this repository on this server, and here's my PGP signature to prove it.” When a push is signed, git will both check the signature it received against a trusted keyring and generate a “push certificate” that can be logged in something like a transparency log:

https://git.kernel.org/pub/scm/infra/transparency-logs/gitolite/git/1.git/plain/m?id=c06eebe4875d6103d580efcf8cd78cc9cc4b5192

Now, before you rush to enable signed pushes, please keep in mind that this functionality needs to first be enabled on the server side, and the vast majority of public git hosting forges do NOT have this turned on. Thankfully, git provides an if-asked setting, which will first check if the remote server supports signed pushes, and only generate the push certificate if the remote server accepts them. To enable this feature for yourself, simply add the following to your ~/.gitconfig:

[push]
    gpgSign = if-asked

Enabling on the server side

If you are running your own git server, then it is easy to enable this on the server side. Add the following either to each repository config file, or to /etc/gitconfig to enable it globally:

[receive]
    advertisePushOptions = true
    certNonceSeed = "<uniquerandomstring>"

You should set the certNonceSeed setting to some randomly generated long string that should be kept secret. It is combined with the timestamp to generate a one-time value (“nonce”) that the git client is required to sign and provides both a mechanism to prevent replay attacks and to offer proof that the certificate was generated for that specific server (though for others to verify this, they would need to know the value of the nonce seed).

Once you have this feature enabled, it is up to you what you do with the generated certificates. You can simply opt to record them, just like we do with our transparency log, or you can actually reject pushes that do not come with valid push certificates. I refer you to the git documentation and to our post-receive-activity-feed hook, which we use to generate the transparency log:


Read more...

from Konstantin Ryabitsev

This week we made public all of our git commit logs, going back to 2013, in hopes to increase the transparency of high-importance kernel.org operations. All writes performed on public git repositories are now recorded in a public-inbox feed, which is immediately replicated to multiple worldwide servers. This is done with the goal do make it difficult for someone to make changes to any git repository hosted on kernel.org without it generating a verifiable, tamper-evident record.

The transparency logs are available at the following address:

https://git.kernel.org/pub/scm/infra/transparency-logs/gitolite/git/

You can read more detailed documentation here:

https://korg.docs.kernel.org/gitolite/transparency-log.html


Read more...

from linusw

This is the continuation of Setting Up the ARM32 Architecture, part 1.

As a recap, we have achieved the following:

  • We are executing in virtual memory
  • We figured out how to get the execution context of the CPU from the init task with task ID 0 using the sp register and nothing else
  • We have initialized the CPU
  • We have identified what type of machine (ARM system) we are running on
  • We have enumerated and registered the memory blocks available for the kernel to use with the primitive memblock memory manager
  • We processed the early parameters earlyparams
  • We have provided early fixmaps and early ioremaps
  • We have identified lowmem and highmem bounds

Memory Blocks – Part 2

We now return to the list of memory available for the Linux kernel.

arm_memblock_init() in arch/arm/mm/init.c is called, resulting in a number of memory reservations of physical memory the Linux memory allocator can NOT use, given as physical start address and size. So we saw earlier that memblock stores a list of available blocks of memory, and in addition to that it can set aside reserved memory.

For example the first thing that happens is this:

memblock_reserve(__pa(KERNEL_START), KERNEL_END - KERNEL_START);

It makes perfect sense that the kernel cannot use the physical memory occupied by by the kernel – the code of the kernel we are executing. KERNEL_END is set to _end which we know from previous investigation to cover not only the TEXT segment but also BSS of the kernel, i.e. all the memory the kernel is using.

Next we call arm_mm_memblock_reserve() which will reserve the memory used by the kernel initial page table, also known as pg_swapper_dir. Would be unfortunate if we overwrite that with YouTube videos.

Finally we reserve the memory used by the device tree (at the moment I write this there is a patch pending to fix a bug here) and any other memory reservations defined in the device tree.

A typical example of a memory reservation in the device tree is if you have a special video ram (VRAM). The following would be a typical example:

        reserved-memory {
                #address-cells = <1>;
                #size-cells = <1>;
                ranges;

                /* Chipselect 3 is physically at 0x4c000000 */
                vram: vram@4c000000 {
                            /* 8 MB of designated video RAM */
                            compatible = "shared-dma-pool";
                            reg = <0x4c000000 0x00800000>;
                            no-map;
                };
        };

This specific memory block (taken from the Versatile Express reference design) will be outside of the physical RAM memory and not disturb any other allocations, but it uses the very same facility in the device tree: anything with compatible “shared-dma-pool” will be set aside for special use.

When chunks of common (non-special-purpose) RAM is set aside these chunks are referred to as “carveouts”. A typical use of such carveouts is media buffers for video and audio.

Next, before we have started to allocate any memory on the platform we set aside memory to be used for contiguous memory allocation (CMA) if this memory manager is in use. The CMA memory pool can be used for other things than contiguous memory, but we cannot have unmovable allocations in there, so we better flag this memory as “no unmoveable allocations in here” as soon as possible.

As CMA is so good at handling contiguous memory it will be used to handle the random carveouts and special memory areas indicated by “shared-dma-pool” as well. So be sure to select the Kconfig symbols CMA and CMA_DMA if you use any of these.

Next we call memblock_dump_all() which will show us nothing, normally. However if we pass the command line parameter memblock=debug to the kernel we will get a view of what things look like, first how much memory is available in total and how much is reserved in total for the things we outlined above, and then a detailed list of the memory available and set aside, similar to this:

MEMBLOCK configuration:
 memory size = 0x08000000 reserved size = 0x007c1256
 memory.cnt  = 0x1
 memory[0x0]    [0x00000000-0x07ffffff], 0x08000000 bytes flags: 0x0
 reserved.cnt  = 0x3
 reserved[0x0]    [0x00004000-0x00007fff], 0x00004000 bytes flags: 0x0
 reserved[0x1]    [0x00008400-0x007c388b], 0x007bb48c bytes flags: 0x0
 reserved[0x2]    [0x00c38140-0x00c39f09], 0x00001dca bytes flags: 0x0

This is taken from the ARM Versatile reference platform and shows that we have one big chunk of memory that is 0x08000000 (128 MB) in size. In this memory we have chiseled out three reservations of in total 0x007C1256 (a bit more than 7 MB). The first reservation is the page table (swapper_pg_dir) the second is the kernel TEXT and BSS and the last reservation is the DTB.

After this point, we know what memory in the system we can and cannot use: early memory management using memblock is available. This is a crude memory management mechanism that will let you do some rough memory reservations before the “real” memory manager comes up. We can (and will) call memblock_alloc() and memblock_phys_alloc() to allocate virtual and physical memory respectively.

If you grep the kernel for memblock_alloc() calls you will see that this is not a common practice: a few calls here and there. The main purpose of this mechanism is for the real memory manager to bootstrap itself: we need to allocate memory to be used for the final all-bells-and-whistles memory management: data structures to hold the bitmaps of allocated memory, page tables and so on.

At the end of this bootstrapping mem_init() will be called, and that in turn calls memblock_free_all() and effectively shuts down the memblock mechanism. But we are not there yet.

After this excursion among the memblocks we are back in setup_arch() and we call adjust_lowmem_bounds() a second time, as the reservations and carveouts in the device tree may have removed memory from underneath the kernel. Well we better take that into account. Redo the whole thing.

Setting up the paging

We now initialize the page table. early_ioremap_reset() is called, turning off the early ioremap facility (it cannot be used while the paging proper is being set up) and then we enable proper paging with the call to paging_init(). This call is really interesting and important: this is where we set up the system to perform the lower levels of proper memory management.

This is a good time to recap the inner workings of the ARM32 page tables before you move along. The relationship between kernel concepts such as PGD, PMD and PTE and the corresponding ARM level-1, level-2 and on LPAE level-3 page table descriptors need to be familiar.

The first thing we do inside paging_init() is to call prepare_page_table(). What it does is to go into the PGD and clear all the PMDs that are not in use by the kernel. As we know, the PGD has 4096 32bit/4-bytes entries on the classic ARM32 MMU grouped into 2048 PMDs and 512 64bit/8 byte entries on LPAE corresponding to one PMD each. Each of them corresponds to a 2MB chunk of memory. The action is going to hit the swapper_pg_dir at 0xC0004000 on classic MMUs or a combination of PGD pointers at 0xC0003000 and PMD pointers at 0xC0004000 on LPAE MMUs.

Our 1MB section mappings currently covering the code we are running and all other memory we use are first level page table entries, so these are covering 1 MB of virtual memory on the classic MMU and 2 MB of memory on LPAE systems. However the size we advance with is defined as PMD_SIZE which will always be 2 MB so the loop clearing the page PMDs look like so:

for (addr = 0; addr < PAGE_OFFSET; addr += PMD_SIZE)
        pmd_clear(pmd_off_k(addr));

(Here I simplified the code by removing the execute-in-place (XIP) case.)

We advance one PMD_SIZE (2 MB) chunk at a time and clear all PMDs that are not used, here we clear the PMDs covering userspace up to the point in memory where the linear kernel mapping starts at PAGE_OFFSET.

We have stopped using sections of 1 MB or any other ARM32-specific level-1 descriptor code directly. We are using PMDs of size 2 MB and the generic kernel abstractions. We talk to the kernel about PMDs and not “level-1 descriptors”. We are one level up in the abstractions, removed from the mundane internals of the ARM32 MMU.

pmd_clear() will in practice set the entry to point at physical address zero and all MMU attributes will also be set to zero so the memory becomes non-accessible for read/write and any other operations, and then flush the translation lookaside buffer and the L2 cache (if present) so that we are sure that all this virtual memory now points to unaccessible zero – a known place. If we try to obtain an instruction or data from one of these addresses we will generate a prefect abort of some type.

One of the PMDs that get wiped out in this process is the two section-mapping PMDs that were 1-to1-mapping __turn_mmu_on earlier in the boot, so we swipe the floor free from some bootstrapping.

Next we clear all PMDs from the end of the first block of lowmem up until VMALLOC_START:

end = memblock.memory.regions[0].base + memblock.memory.regions[0].size;
if (end >= arm_lowmem_limit)
    end = arm_lowmem_limit;

for (addr = __phys_to_virt(end); addr < VMALLOC_START; addr += PMD_SIZE)
    pmd_clear(pmd_off_k(addr));

What happens here? We take the first memory block registered with the memblock mechanism handling physical memory, then we cap that off at arm_lowmem_limit which we saw earlier is in most cases set to the end of the highest memory block, which will mostly be the same thing unless we have several memory blocks or someone passed in command parameters reserving a lot of vmalloc space, so this procedure assumes that the kernel is loaded into the first available (physical) memory block, and we will then start at the end of that memory block (clearly above the kernel image) and clear all PMDs until we reach VMALLOC_START.

VMALLOC_START is the end of the virtual 1-to-1 mapping of the physical memory + 8 MB. If we have 512 MB of physical memory at physical address 0x00000000 then that ends at 0x1FFFFFFF and VMALLOC_START will be at 0x20000000 + PAGE_OFFSET + 0x00800000 = 0xE0800000. If we have 1 GB of physical memory VMALLOC_START will run into the highmem limit at 0xF0000000 and the end of the 1-to-1 physical mapping will naturally be there, so the VMALLOC_START will be at 0xF0800000 for anything with more 768 MB memory. The 8 MB between the end of lowmem and VMALLOC_START is a “buffer” to catch stray references.

For example if a system has 128 MB of RAM starting at 0x00000000 in a single memory block and the kernel zImage is 8MB in size and gets loaded into memory at 0x10008000-0x107FFFFF with the PGD (page global directory) at 0x10004000, we will start at address 0x20000000 translated to virtual memory 0xE0000000 and clear all PMDs for the virtual memory up until we reach 0xF0800000.

The physical memory in the memblock that sits above and below the start of the kernel, in this example the physical addresses 0x00000000-0x0FFFFFFF and 0x10800000-0x1FFFFFFF will be made available for allocation as we initialize the memory manager: we have made a memblock_reserve() over the kernel and that is all that will actually persist – memory in lowmem (above the kernel image) and highmem (above the arm_lowmem_limit, if we have any) will be made available to the memory allocator as well.

This code only initializes the PMDs, i.e. the entries in the first level of the page table, to zero memory with zero access to protect us from hurting ourselves.

Clearing the PMDs This image illustrates what happens when we initialize the PMDs (the picture is not to scale). The black blocks are the PMDs we clear, making them unavailable for any references for now. We have one block of physical memory from 0x00000000-0x1FFFFFFF (512 MB) and we clear out from the end of that block in virtual memory until we reach VMALLOC_START.

Mapping lowmem

Next we call map_lowmem() which is pretty self-describing. Notice that we are talking about lowmem here: the linear kernelspace memory map that is accessed by adding or subtracting an offset from/to the physical or virtual memory address. We are not dealing with the userspace view of the memory at all, only the kernel view of the memory.

We round two physical address pointers to the start and end PMDs (we round on SECTION_SIZE, i.e. 1 MB bounds) of the executable portions of the kernel. The lower part of the kernel (typically starting at address 0xC0008000) is the executable TEXT segment so the start of this portion of the virtual memory is assigned to pointer kernel_x_start and kernel_x_end is put rounded up to the next section for the symbol __init_end, which is the end of the executable part of the kernel.

The BSS segment and other non-execuable segments are linked below the executable part of the kernel, so this is in the virtual memory above the executable part of the kernel.

Then we loop over all the memory blocks we have in the system and call create_mapping() where we first check the following conditions:

  • If the end of the memblock is below the start of the kernel the memory is mapped as readable/writeable/executable MT_MEMORY_RWX. This is a whole memory block up in userspace memory and similar. We want to be able to execute code up there. I honestly do not know why, but I can think about things such as small firmware areas that need to be executable, registered somewhere in a very low memblock.
  • If the start of the memblock is above kernel_x_end the memory is mapped as readable/writeable. No execution shall happen in the linear map above the executable kernel memory.

Next we reach the situation where the memblock is covering both the executable and the non-executable part of the kernel image. There is even a comment saying “this better cover the entire kernel” here: the whole kernel has to be inside one memory block under these circumstances or the logic will not work.

This is the most common scenario under all circumstances, such as my example with a single 128 MB physical memory block. Most ARM32 systems are like this.

We then employ the following pretty intuitive mapping:

  • If the memblock starts below the executable part of the kernel kernel_start_x we chop off that part and map it as readable/writeable with MT_MEMORY_RW.
  • Then we map kernel_x_start to kernel_x_end as readable/writeable/executable with MT_MEMORY_RWX.
  • Then we map the last part of the kernel above kernel_x_end to the end of the memblock as readable/writeable with MT_MEMORY_RW.

Remapping the kernel image This illustrates how the memory above the kernel is readable/writeable, the upper part of the kernel image with the text segment is readable/writeable/executable while the lower .data and .bss part is just readable/writeable, then the rest of lowmem is also just readable writable. In this example we have 128MB (0x20000000) of memory and the in the kernel image lowmem is mapped 0x00000000 -> 0xB0000000, 0x10000000 -> 0xC0000000 and 0x20000000 -> 0xD0000000. The granularity may require individual 4K pages so this will use elaborate page mapping.

The executable kernel memory is also writable because the PGD is in the first PMD sized chunk here – we sure need to be able to write to that – and several kernel mechanisms actually rely on being able to runtime-patch the executable kernel, even if we have already finalized the crucial physical-to-virtual patching. One example would be facilities such as ftrace.

Everything that fits in the linearly mapped lowmem above and below the kernel will be readable and writable by the kernel, which leads to some optimization opportunities – especially during context switches – but also to some problems, especially regarding the highmem. But let’s not discuss that right now.

map_lowmem() will employ create_mapping() which in turn will find out the PGD entries (in practice, on a classical MMU in this case that will be one entry of 32 bits/4 bytes in the level-1 page table) for the address we pass in (which will be PMD-aligned at 2 MB), and then call alloc_init_p4d() on that pgd providing the start and end address. We know very well that ARM32 does not have any five- or four-level page tables but this is where the generic nature of the memory manager comes into play: let’s pretend we do. alloc_init_p4d() will traverse the page table ladder with alloc_init_pud() (we don’t use that either) and then alloc_init_pmd() which we actually use, and then at the end if we need it alloc_init_pte().

What do I mean by “if we need it”? Why would we not allocate PTEs, real page-to-page tables for every 0x1000 chunk of physical-to-virtual map?

It’s because allocinitpmd() will first see if the stuff we map is big enough to use one or more section mappings – i.e. just 32 bits/4 bytes in the PGD at 0xC0004000-somewhere to map the memory. In our case that will mostly be the case! The kernel will if possible remain section mapped, and we call __map_init_section() which will create and write the exact same value into the PGD as we had put in there before – well maybe it was all executable up onto this point, so at least some small bits will change. But we try our best to use the big and fast section maps if we can without unnecessarily creating a myriad of PTE-level objects that turn into level-2 descriptors that need to be painstakingly traversed.

However on the very last page of the executable part of the kernel and very first page of the data segments it is very likely that we cannot use a section mapping, and for the first time the generic kernel fine-granular paging using 4 KB pages will kick in to provide this mapping. We learnt before that the linker file has been carefully tailored to make sure that each segment of code starts on an even page, so we know that we can work at page granularity here.

In create_mapping(), if the start and end of the memory we try to map is not possible to fit perfectly into a section, we will call alloc_init_pte() for the same address range. This will allocate and initialize a PTE, which is the next level down in the page table hierarchy.

phys_addr_t start, end;
struct map_desc map;

map.pfn = __phys_to_pfn(start);
map.virtual = __phys_to_virt(start);
map.length = end - start;
map.type = MT_MEMORY_RWX;

create_mapping(&map);

A typical case of creating a mapping with create_mapping(). We set the page frame number (pfn) to the page we want to start the remapping at, then the virtual address we want the remapping to appear at, and the size and type of the remapping, then we call create_mapping().

So Let’s Map More Stuff

We now know what actually happens when we call create_mapping() and that call is used a lot in the early architecture set-up. We know that map_lowmem() will chop up the border between the executable and non-executable part of the kernel using the just described paging layout of our MMU using either the classic complicated mode or the new shiny LPAE mode.

The early section mappings we put over the kernel during boot and start of execution from virtual memory are now gone. We have overwritten them all with the new, proper mappings, including the very memory we executed the remappings in. Nothing happens, but the world is now under generic kernel memory management control. The state of the pages is, by the way, maintained in the page tables themselves.

If we create new PTEs these will be allocated into some new available memory page as well using alloc(). At this point that means that the memblock allocator will be used, since the proper memory management with kmalloc() is not yet operational. The right type of properties (such as read/write/execute or other MT_* characteristics) will be used however so we could say that we have a “halfway” memory manager: the hardware is definitely doing the right thing now, and the page tables are manipulated the right way using generic code.

map_lowmem() is done. We call memblock_set_current_limit(arm_lowmem_limit) because from now on we only want memblock allocations to end up in lowmem proper, we have just mapped it in properly and all. In most cases this is the same as before, but in some corner cases we cannot put this restriction until now.

We remap the contiguous memory allocation area if CMA is in use, again using all the bells and whistles of the kernel’s generic memory manager. MMU properties for DMA memory is set to MT_MEMORY_DMA_READY which is very close to normal read/writeable memory.

Next we shutdown the fixmap allocations. The remapped memory that was using fixmaps earlier gets mapped like the kernel itself and everything else using create_mapping() instead of the earlier hacks poking directly into the page tables. They are all one page each and uses MT_DEVICE, i.e. write-through, uncached registers of memory-mapped I/O, such as used by the earlyconsole UART registers.

Next we set up some special mappings in devicemaps_init() that apart from the early ones we just reapplied add some new ones, i.e. some not-so-early mappings. They are mostly not devices either so the function name is completely misleading. The function is called like this because it at one point calls the machine-specific ->map_io() callback for the identified machine descriptor, which on pure device tree systems isn’t even used.

Inside devicemaps_init() We clear some more PMDs. Now we start at VMALLOC_START: the place where we previously stopped the PMD clearing, advancing 2 MB at a time up to FIXADDR_TOP which is the location of the fixmaps. Those have been redefined using the generic kernel paging engine, but they are still there, so we must not overwrite them.

Next follow some special mappings, then we get to something really interesting: the vectors.

Setting Up and Mapping the Exception Vector Table

The vector table is a page of memory where the ARM32 CPUs will jump when an exception occurs. Exceptions vectors can be one of:

  • Reset exception vector: the address the PC is set to if the RESET line to the CPU is asserted.
  • Undefined instruction exception vector: the address we jump to if an undefined instruction is executed. This is used for example to emulate floating point instructions if your CPU does not have them.
  • Software Interrupt (SWI) exception vector: also called a “trap”, is a way to programmatically interrupt the program flow and execute a special handler. In Linux this is used by userspace programs to execute system calls: to call on the kernel to respond to needs of a userspace process.
  • Prefetch abort exception vector: this happens when the CPU tries to fetch an instruction from an illegal address, such as those addresses where we have cleared the level-1 page table descriptor (PMD) so there is no valid physical memory underneath. This is also called a page fault and is used for implementing demand paging, a central concept in Unix-like operating systems.
  • Data abort exception vector: same thing but the CPU is trying to fetch data rather than an instruction. This is also used for demand paging.
  • Address exception vector: this is described in the source as “this should never happen” and some manuals describe it as “unused” or “reserved”. This is actually an architectural leftover from the ARM26 (ARMv1, v2, v3) no longer supported by Linux. In older silicon the virtual address space was 26 bits rather than the 32 bits in later architectures, and this exception would be triggered when an address outside the 26 bit range was accessed. (This information came from LWN reader farnz as a reply to this article.) On full 32-bit silicon it should indeed never happen.
  • Interrupt Request IRQ exception vector: the most natural type of exception in response to the IRQ line into the CPU. In later ARM32 CPUs this usually comes from the standard GIC (Generic Interrupt Controller) but in earlier silicon such as ARMv4 or ARMv5 some custom interrupt controller is usually connected to this line. The origin of the line was a discrete signal routed out on the CPU package, but in modern SoCs these are usually synthesized into the same silicon so the line is not visible to the outside, albeit the concept is the same.
  • Fast Interrupt Request FIQ exception vector: this is mostly unused in Linux, and on ARMv7 silicon often used to trap into the secure world interrupt handlers and thus not even accessible by the normal world where Linux is running.

These eight vectors in this order is usually all we ever need on any ARM32 CPU. They are one 32bit word each, so the PC is for example set at address 0xFFFF0000 when reset occurs and whatever is there is executed.

The way the vector table/page works is that the CPU will store the program counter and processor state in internal registers and put the program counter at the corresponding vector address. The vector table can be put in two locations in memory: either at address 0x00000000 or address 0xFFFF0000. The location is selected with a single bit in the CP15 control register 1. Linux supports putting the vectors in either place with a preference for 0xFFFF0000. Using address 0x00000000 is typically most helpful if the MMU is turned off and you have a 1-to-1 mapping to a physical memory that starts at address 0x00000000. If the MMU is turned on, which it is for us, the address used is the virtual one, even the vector table goes through MMU translation, and it is customary to use the vectors high up in memory, at address 0xFFFF0000.

As we noted much earlier, each exception context has its own copy of the sp register and thus is assigned an exception-specific stack. Any other registers need to be spooled out and back in by code before returning from the exception.

Exception vectors on the ARM CPUs The ARM32 exception vector table is a 4KB page where the first 8 32-bit words are used as vectors. The address exception should not happen and in some manuals is described as “unused”. The program counter is simply set to this location when any of these exceptions occur. The remainder of the page is “poisoned” with the word 0xE7FDDEF1.

ARM Linux uses two consecutive pages of memory for exception handling: the first page is the vectors, the second page is called stubs. The vectors will typically be placed at 0xFFFF0000 and the stubs at the next page at 0xFFFF1000. If you use the low vectors these will instead be at 0x00000000 and 0x00001000 respectively. The actual physical pages backing these locations are simply obtained from the rough memblock allocator using memblock_alloc(PAGE_SIZE * 2).

The stubs page requires a bit of explanation: since each vector is just 32 bits, we simply cannot just jump off to a desired memory location from it. Long jumps require many more bits than 32! Instead we do a relative jump into the next page, and either handle the whole exception there (if it’s a small thing) or dispatch by jumping to some other kernel code. The whole vector and stubs code is inside the files arch/arm/kernel/entry-armv.S and arch/arm/kernel/traps.c. (The “armv” portion of the filename is misleading, this is used for pretty much all ARM32 machines. “Entry” means exception entry point.)

The vector and stub pages is set up in the function early_trap_init() by first filling the page with the 32bit word 0xE7FDDEF1 which is an undefined instruction on all ARM32 CPUs. This process is called “poisoning”, and makes sure the CPU locks up if it ever would put the program counter here. Poisoning is done to make sure wild running program counters stop running around, and as a security vulnerability countermeasure: overflow attacks and other program counter manipulations often tries to lead the program counter astray. Next we copy the vectors and stubs to their respective pages.

The code in the vectors and stubs has been carefully tailored to be position-independent so we can just copy it and execute it wherever we want to. The code will execute fine at address 0xFFFF0000-0xFFFF1FFF or 0x00000000-0x00001FFF alike.

You can inspect the actual vector table between symbols __vector_start and __vector_end at the end of entry-armv.S: there are 8 32-bit vectors named vector_rst, vector_und … etc.

Clearing out PMDs setting vectors We cleared some more PMDs between VMALLOC_START and the fixmaps, so now the black blocks are bigger in the virtual memory space. At 0xFFFF0000 we install vectors and at 0xFFFF1000 we install stubs.

We will not delve into the details of ARM32 exception handling right now: it will suffice to know that this is where we set it up, and henceforth we can deal with them in the sense that ARM32 will be able to define exception handlers after this point. And that is pretty useful. We have not yet defined any generic kernel exception or interrupt interfaces.

The vectors are flushed to memory and we are ready to roll: exceptions can now be handled!

At the end of devicemaps_init() we call early_abt_enable() which enables us to handle some critical abort exceptions during the remaining start-up sequence of the kernel. The most typical case would be a secondary CPU stuck in an abort exception when brought online, we need to cope with that and recover or it will bring the whole system down when we enable it.

The only other notable thing happening in devicemaps_init() is a call to the machine descriptor-specific .map_io() or if that is undefined, to debug_ll_io_init(). This used to be used to set up fixed memory mappings of some device registers for the machine, since at this point the kernel could do that properly using create_mapping(). Nowadays, using device trees, this callback will only be used to remap a debug UART for LL_DEBUG (all other device memory is remapped on-demand) which is why the new function name debug_ll_io_init() which isn’t even using the machine descriptor is preferred.

Make no mistake: DEBUG_LL is already assuming a certain virtual address for the UART I/O-port up until this point and it better remain there. We mapped that much earlier in head.S using a big fat section mapping of 1MB physical-to-virtual memory.

What happens in debug_ll_io_init() is that the same memory window is remapped properly with create_mapping() using a fine-granular map of a single page of memory using the right kernel abstractions. We obtain the virtual address for the UART using the per-serialport assembly macro addruart from the assembly file for the corresponding UART in arch/arm/include/debug/*.

This will overwrite the level-1 section mapping descriptor used for debug prints up until this point with a proper level-1 to level-2 pointer using PMDs and PTEs.

Initialzing the Real Memory Manager

Back in paging_init() we call kmap_init() that initialize the mappings used for highmem and then tcm_init() which maps some very tiny on-chip RAMs if we have them. The TCM (tightly coupled memory) is small SDRAMs that are as fast as cache, that some vendors synthesize on their SoCs.

Finally we set top_pmd to point at address 0xFFFF0000 (the vector space) and we allocate a page called the empty_zero_page which will be a page filled with zeroes. This is sometimes very helpful for the kernel when referencing a “very empty page”.

We call bootmem_init() which brings extended memblock page handling online: it allows resizing of memblock allocations, finds the lowest and highest page frame numbers pfns, performs an early memory test (if compiled in) and initializes sparse memory handling in the generic virtual memory manager.

We then chunk the physical memory into different memory zones with the final call to free_area_init() providing the maximum page frame numbers for the different memory zones: ZONE_DMA, ZONE_NORMAL, and ZONE_HIGHMEM are used on ARM32. The zones are assumed to be consecutive in physical memory, so only the maximum page frame numbers for each zone is given.

  • ZONE_DMA is for especially low physical memory that can be accessed by DMA by some devices. There are machines with limitations on which addresses some devices can access when performing DMA bus mastering, so these need special restrictions on memory allocation.
  • ZONE_NORMAL is what we refer to as lowmem on ARM32: the memory that the kernel or userspace can use for anything.
  • ZONE_HIGHMEM is used with the ARM32 definition of highmem , which we have discussed in detail above: memory physically above the 1-to-1-mapped lowmem.

After returning from free_area_init() the generic kernel virtual memory pager is finally initialized. The memory management is not yet online: we cannot use kmalloc() and friends, but we will get there. We still have to use memblock to allocate memory.

We call request_standard_resources(), which is a call to register to the kernel what purpose specific memory areas have. Here we loop over the memblocks and request them as System RAM if nothing else applies. The resource request facility is hierarchical (resources can be requested inside resources) so the kernel memory gets requested inside the memory block where it resides. This resource allocation provides the basic output from the file /proc/iomem such as the location of the kernel in memory. This facility is bolted on top of the actual memory mapping and just works as an optional protection mechanism.

Finalizing Architecture Setup

We are getting close to the end of ARM32:s setup_arch() call.

If the machine descriptor has a restart hook we assign the global function pointer arm_pm_restart to this. Nominally drivers to restart modern platforms should not use this: they should provide a restart handler in drivers/power/reset/* registering itself using register_restart_handler(), but we have a bit of legacy code to handle restarts, and that will utilize this callback.

Next we unflatten the device tree, if the machine uses this, which all sufficiently modern ARM32 machines should. The device tree provided from boot is compact, binary and read only, so we need to process it so that boot code and device drivers can traverse the device tree easily. An elaborate data structure is parsed out from the device tree blob and allocated into free pages, again using the crude memblock allocator.

So far we only used very ad hoc device tree inspection to find memory areas and memory reservations.

Now we can inspect the device tree in a more civilized manner to find out some very basic things about the platform. The first thing we will actually do is to read the CPU topology information out of the device tree and build a list of available CPUs on the system. But that will happen later on during boot.

Finally, and lastly, we check if the machine has defined ->init_early() and need some other early work. If it does then we call this callback. Else we are done with setup_arch().

After this we return to the function start_kernel() in init/main.c again, where we will see how the kernel builds zones of the memory blocks, initializes the page allocator and finally gets to call mm_init() which brings the proper memory management with kmalloc() and friends online. We will set up SMP, timekeeping and call back into the architecture to finalize the deal.

But this is all a topic for another time.


Read more...

from linusw

After we have considered how the ARM32 kernel uncompressed and the early start-up when the kernel jumps from executing in physical memory to executing in virtual memory we now want to see what happens next all the way until the kernel sets up the proper page tables and starts executing from properly paged virtual memory.

To provide a specific piece of the story that does not fit into this linear explanation of things, i have also posted a separate article on how the ARM32 page tables work. This will be referenced in the text where you might need to recapture that part.

To repeat: we have a rough initial section mapping of 1 MB sections covering the kernel RAM and the provided or attached Device Tree Blob (DTB) or ATAGs if we use a legacy system that is not yet using device tree. We have started executing from virtual memory in arch/arm/kernel/head-common.S, from the symbol __mmap_switched where we set up the C runtime environment and jump to start_kernel() in init/main.c. The page table is at a pointer named swapper_pg_dir.

Initial page table layout The initial page table swapper_pg_dir and the 1:1 mapped one-page-section __turn_mmu_on alongside the physical to virtual memory mapping at early boot. In this example we are not using LPAE so the initial page table is -0x4000 from (PAGE_OFFSET +TEXT_OFFSET), usually at 0xC0004000 thru 0xC0007FFF and memory ends at 0xFFFFFFFF.

We are executing in virtual memory, but interrupts and caches are disabled and absolutely no device drivers are available, except the initial debug console. The initial debug console can be enabled with CONFIG_DEBUG_LL and selecting the appropriate debug UART driver for your system. This makes the kernel completely non-generic and custom for your system but is great if you need to debug before the device drivers come up. We discussed how you can insert a simple print in start_kernel() using this facility.

In the following text we start at start_kernel() and move down the setup_arch() call. When the article ends, we are not yet finished with setup_arch() so there will be a second part to how we set up the architecture. (I admit I ran over the maximum size for a post, else it would be one gigantic post.)

In the following I will not discuss the “nommu” (uClinux) set-up where we do not use virtual memory, but just a 1-to-1 physical-to-virtual map with cache and memory protection. It is certainly an interesting case, but should be the topic for a separate discussion. We will describe setting up Linux on ARM32 with full classic or LPAE MMU support.

Setting Up the Stack Pointer and Memory for the init Task

In the following section the words task and thread are used to indicate the same thing: an execution context of a process, in this case the init process.

Before we start executing in virtual memory we need to figure out where our stack pointer is set. __mmap_switched in head-common.S also initializes the ARM stack pointer:

   ARM( ldmia   r4!, {r0, r1, sp} )
 THUMB( ldmia   r4!, {r0, r1, r3} )
 THUMB( mov     sp, r3 )

r4 in this case contains __mmap_switched_data where the third variable is:

.long   init_thread_union + THREAD_START_SP

THREAD_START_SP is defined as (THREAD_SIZE - 8), so 8 bytes backward from the end of the THREAD_SIZE number of bytes forward from the pointer stored in the init_thread_union variable. This is the first word on the stack that the stack will use, which means that bytes at offset THREAD_SIZE - 8, -7, -6, -5 will be used by the first write to the stack: only one word (4 bytes) is actually left unused at the end of the THREAD_SIZE memory chunk.

The init_thread_union is a global kernel variable pointing to the task information for the init process. You find the actual memory for this defined in the generic linker file for the kernel in include/asm-generic/vmlinux.lds.h where it is defined as a section of size THREAD_SIZE in the INIT_TASK_DATA section definition helper. ARM32 does not do any special tricks with this and it is simply included into the RW_DATA section, which you find in the linker file for the ARM kernel in arch/arm/kernel/vmlinux.lds.S surrounded by the labels _sdata and _edata and immediately followed by the BSS section:

        _sdata = .;
        RW_DATA(L1_CACHE_BYTES, PAGE_SIZE, THREAD_SIZE)
        _edata = .;

        BSS_SECTION(0, 0, 0)

This will create a section which is aligned at a page boundary, beginning with INIT_TASK_DATA of size THREAD_SIZE, initialized to the values assigned during compilation and linking and writable by the kernel.

The union thread_union is what is actually stored in this variable, and in the ARM32 case it actually looks like this after preprocessing:

union thread_union {
    unsigned long stack[THREAD_SIZE/sizeof(long)];
};

It is just an array of unsigned long 4 byte chunks, as the word length on ARM32 is, well 32 bits, and sized so that it will fit a THREAD_SIZE stack. The name stack is deceptive: this chunk of THREAD_SIZE bytes stores all ARM-specific context information for the task, and the stack, with the stack in the tail of it. The remaining Linux generic accounting details are stored in a struct task_struct which is elsewhere in memory.

THREAD_SIZE is defined in arch/arm/include/asm/thread_info.h to be (PAGE_SIZE << THREAD_SIZE_ORDER) where PAGE_SIZE is defined in arch/arm/include/asm/page.h to be (1 << 12) which usually resolves to (1 << 13) so the THREAD_SIZE is actually 0x2000 (8196) bytes, i.e. 2 consecutive pages in memory. These 0x2000 bytes hold the ARM-specific context and the stack for the task.

The struct thread_info is the architecture-specific context for the task and for the init task this is stored in a global variable called init_thread_info that you find defined at the end of init/init_task.c:

struct thread_info init_thread_info __init_thread_info = INIT_THREAD_INFO(init_task);

The macro __init_thread_info expands to a linker directive that puts this into the .data.init_thread_info section during linking, which is defined in the INIT_TASK_DATA we just discussed, so this section is only there to hold the init task thread_info. 8 bytes from the end of this array of unsigned longs that make up the INIT_TASK_DATA is where we put the stack pointer.

Where is this init_thread_union initialized anyway?

It is pretty hard to spot actually, but the include/asm-generic/vmlinux.lds.h INIT_DATA_TASK linker macro does this. It contains these statements:

init_thread_union = .;
init_stack = .;

So the memory assigned to the pointers init_thread_union and init_stack is strictly following each other in memory. When the .stack member of init_task is assigned to init_stack during linking, it will resolve to a pointer just a little further ahead in memory, right after the memory chunk set aside for the init_thread_union. This is logical since the stack grows toward lower addresses on ARM32 systems: .stack will point to the bottom of the stack.

Init thread During the early start of the kernel we take extra care to fill out these two thread_info and task_struct data structures and the pointers to different offsets inside it. Notice the sp (stack pointer) pointing 8 bytes up from the end of the end of the two pages assigned as memory to hold the task information. The first word on the stack will be written at sp, typically at offset 0x1FF8 .. 0x1FFB.

This init_stack is assigned to .stack of struct task_struct init_task in init/init_task.c, where the rest of the task information for the init task is hardcoded. This task struct for the init task is in another place than the thread_info for the init task, they just point back and forth to each other. The task_struct is the generic kernel part of the per-task information, while the struct thread_info is an ARM32-specific information container that is stored together with the stack.

Here we see how generic and architecture-specific code connect: the init_thread_info is something architecture-specific and stores the state and stack of the init task that is ARM32-specific, while the task_struct for the init task is something completely generic, all architectures use the same task_struct.

This init task is task 0. It is not identical to task 1, which will be the init process. That is a completely different task that gets forked in userspace later on. This task is only about providing context for the kernel itself, and a point for the first task (task 1) to fork from. The kernel is very dependent on context as we shall see, and that is why its thread/task information and even the stack pointer for this “task zero” is hardcoded into the kernel like this. This “zero task” does not even appear to userspace if you type ps aux, it is hidden inside the kernel.

Initializing the CPU

The very first thing the kernel does in start_kernel() is to initialize the stack of the init task with set_task_stack_end_magic(&init_task). This puts a STACK_END_MAGIC token (0x57AC6E9D) where the stack ends. Since the ARM stack grows downwards, this will be the last usable unsigned long before we hit the thread_info on the bottom of the THREAD_SIZE memory chunk associated with our init task.

init thread stack end marker We insert a 0x57AC6E9D token so we can see if the last word of per-task stack ever gets overwritten and corrupted. The ARM32 stack grows towards the lower addresses. (Up along the arrow in the picture.)

Next smp_setup_processor_id() is called which is a weak symbol that each architecture can override. ARM does this: arch/arm/kernel/setup.c contains this function and if we are running on an SMP system, we execute read_cpuid_mpidr() to figure out the ID of the CPU we are currently running on and initialize the cpu_logical_map() array such that the current CPU is at index 0 and we print the very first line of kernel log which will typically be something like:

Booting Linux on physical CPU 0x0

If you are running on a uniprocessor system, there will be no print like this.

The kernel then sets up some debug objects and control group information that is needed early. We then reach local_irq_disable(). Interrupts are already disabled (at least they should be) but we exercise this code anyways. local_irq_disable() is defined to arch_local_irq_disable() which in the ARM case can be found in arch/arm/include/asm/irqflags.h. As expected it resolves to the assembly instruction cpsid i which will disable any ordinary IRQ in the CPU. This is short for change processor state interrupt disable i. It is also possible to issue cpsid f to disable FIQ, which is an interrupt which the ARM operating systems seldom make use of.

ARM systems usually also have an interrupt controller: this is of no concern here: we are disabling the line from the interrupt controller (such as the GIC) to the CPU: this is the big main switch, like going down in the basement and cutting the power to an entire house. Any other lightswitches in the house are of no concern at this point, we haven’t loaded a driver for the interrupt controller so we just ignore any interrupt from any source in the system.

Local IRQ big powerswitch The local_irq_disable() results in cpsid i which will cut the main interrupt line to the CPU core.

This move makes a lot of sense, because at this point we have not even set up the exception vectors, which is what all IRQs have to jump through to get to the destined interrupt handler. We will get to this in due time.

Next we call boot_cpu_init(). As the name says this will initialize the one and only CPU we are currently running the kernel on. Normally any other CPUs in the system are just standing by with frozen instruction counters at this point. This does some internal kernel bookkeeping. We note that smp_processor_id() is called and __boot_cpu_id is assigned in the SMP case. smp_processor_id() is assigned to raw_smp_processor_id() in include/linux/smp.h and that will go back into the architecture in arch/arm/include/asm/smp.h and reference the global variable current_thread_info()->cpu, while on uniprocessor (UP) systems it is simply defined to 0.

Let’s see where that takes us!

In the SMP case, current_thread_info() is defined in arch/arm/include/asm/thread_info.h and is dereferenced from the current_stack_pointer like this:

static inline struct thread_info *current_thread_info(void)
{
        return (struct thread_info *)
                (current_stack_pointer & ~(THREAD_SIZE - 1));
}

current_stack_pointer in turn is defined in arch/arm/include/asm/percpu.h and implemented as the assembly instruction sp. We remember that we initialized this to point at the end of THREAD_SIZE minus 8 bytes of the memory reserved for init_thread_info. The stack grows backward. This memory follows right after the thread_info for the init task so by doing this arithmetic, we get a pointer to the current struct thread_info, which will be the init_task. Further we see that the link file contains this:

. = ALIGN(THREAD_SIZE);
(...)
RW_DATA(L1_CACHE_BYTES, PAGE_SIZE, THREAD_SIZE)

So the linker takes care to put thread info into a THREAD_SIZE:d chunk in memory. This means that if THREAD_SIZE is 0x2000, then the init task thread_info will always be on addresses like 0x10000000, 0x10002000, 0x10004000...

For example if THREAD_SIZE is 0x2000 then (THREAD_SIZE - 1) is 0x00001FFF and ~0x00001FFF is 0xFFFFE000 and since we know that the struct thread_info always start on an even page, this arithmetic will give us the address of the task information from the stack pointer. If the init_thread_info ends up at 0x10002000 then sp points to 0x10003FF8 and we calculate 0x10003FF8 & 0xFFFFE000 = 0x10002000 and we have a pointer to our thread_info, which in turn has a pointer to init_task: thus we know all about our context from just using sp.

Thus sp is everything we need to keep around to quickly look up the information of the currently running task, i.e. the process context. This is a central ARM32 Linux idea.

Since the kernel is now busy booting we are dealing with the init task, task 0, but all tasks that ever get created on the system will follow the same pattern: we go into the task context and use sp to find any information associated with the task. The init_task provides context so we don't crash. Now it becomes evident why this special “task zero” is needed so early.

So to conclude: when raw_smp_processor_id() inspects current_thread_info()->cpu to figure out what CPU we are running on, this thread info is going to be the init_thread_info and ->cpu is going to be zero because the compiler has assigned the default value zero to this member during linking (we haven’t assigned anything explicitly). ->cpu is an index and at index zero in the cpu_logical_map() is where we poked in our own CPU ID a little earlier using smp_setup_processor_id() so we can now find ourselves through the sp. We have come full circle.

As I pointed out this clever sp mechanism isn’t just used for the init task. It is used for all tasks on the system, which means that any allocated thread info must strictly be on a memory boundary evenly divisible with THREAD_SIZE. This works fine because kmalloc() that is used to allocate kernel memory returns chunks that are “naturally aligned”, which means “aligned to the object size if that size is a power of two” – this will ascertain that the allocation ends up on a page boundary evenly divisible by the object allocated, and the current_thread_info() call will always work fine. This is one of the places where the kernel assumes this kind of natural alignment.

Hello World

Next we call page_address_init() which mostly does nothing, but if the system is using highmem (i.e. has a lot of memory) this will initialize a page hash table. We will explain more about how highmem is handled later in this article.

Next we print the Linux banner. The familiar first text of the kernel appear in the kernel print buffer stating what version and git hash we built from and what compiler and linker was used to build this kernel:

Linux version 5.9.0-rc1-00021-gbbe281ed6cfe-dirty (...)

Even if we have an early console defined for the system, i.e. if we defined CONFIG_DEBUG_LL these first few messages will still NOT be hammered out directly on the console. They will not appear until we have initialized the actual serial console driver much later on. Console messages from CONFIG_DEBUG_LL only come out on the console as a result of printascii() calls. This banner is just stashed aside in the printk memory buffer until we get to a point where there is a serial device that can actually output this text. If we use earlyprintk and the serial driver has the proper callbacks, it will be output slightly earlier than when the memory management is properly up and running. Otherwise you will not see this text until the serial driver actually gets probed much later in the kernel start-up process.

But since you might have enabled CONFIG_DEBUG_LL there is actually a trick to get these prints as they happen: go into kernel/printk/printk.c and in the function vprintk_store() insert some code like this at the end of the function, right before the call to log_output():

#if defined(CONFIG_ARM) && defined(CONFIG_DEBUG_LL)
       {
               extern void printascii(char *);
               printascii(textbuf);
       }
#endif

This will make all printk:s get hammered out on the console immediately as they happen, with the side effect that once the serial port is up you get conflict about the hardware and double prints of everything. However if the kernel grinds to a halt before that point, this hack can be really handy: even the very first prints to console comes out immediately. It’s one of the ARM32-specific hacks that can come in handy.

Next we call early_security_init() that will call ->init() on any Linux Security Modules (LSMs) that are enabled. If CONFIG_SECURITY is not enabled, this means nothing happens.

Setting Up the Architecture

The next thing that happens in start_kernel() is more interesting: we call setup_arch() passing a pointer to the command line. setup_arch() is defined in <linux/init.h> and will be implemented by each architecture as they seem fit. The architecture initializes itself and passes any command line from whatever mechanism it has to provide a command line. In the case of ARM32 this is implemented in arch/arm/kernel/setup.c and the command line can be passed from ATAGs or the device tree blob (DTB).

Everything in this article from this point on will concern what happens in setup_arch(). Indeed this function has given the name to this whole article. We will conclude the article once we return out of setup_arch(). The main focus will be memory management in the ARM32 MMUs.

Setting Up the CPU

ARM32 first sets up the processor. This section details what happens in the setup_processor() call which is the first thing the setup_arch() calls. This code will identify the CPU we are running on, determine its capabilities such as cache type and prepare the exception stacks. It will however not enable the caches or any other MMU functionality such as paging, that comes later.

We call read_cpuid_id() which in most cases results in a CP15 assembly instruction to read out the CPU ID: mrc p15, 0, <Rd>, c0, c0, 0 (some silicon such as the v7m family require special handling).

Using this ID we cross reference a struct with information about the CPU, struct proc_info_list. This is actually the implementation in assembly in head-common.S that we have seen earlier, so we know that this will retrieve information about the CPU from the files in arch/arm/mm/proc-*.S for example arch/arm/mm/proc-v7.S for all the ARMv7 processors. With some clever linkage the information about the CPU is now assigned into struct proc_info_list from arch/arm/include/asm/procinfo.h, so that any low-level information about the CPU and a whole set of architecture-specific assembly functions for the CPU can be readily accessed from there. A pointer to access these functions is set up in a global vector table named, very clearly, processor.

We print the CPU banner which can look something like this (Qualcomm APQ8060, a dual-core Cortex A9 SMP system):

CPU: ARMv7 Processor [510f02d2] revision 2 (ARMv7), cr=10c5787d

From the per-processor information struct we also set up elf_hwcap and elf_hwcap2. These flags that can be found in arch/arm/include/uapi/asm/hwcap.h tells the ELF (Executable and Linkable Format) parser in the kernel what kind of executable files we can deal with. For example if the executable is using hardware floating point operations or NEON instructions, a flag is set in the ELF header, and compared to this when we load the file so that we can determine if we can even execute the file.

Just reading that out isn’t enough though so we call in succession cpuid_init_hwcaps() to make a closer inspection of the CPU, disable execution of thumb binaries if the kernel was not compiled with thumb support, and we later also call elf_hwcap_fixup() to get these flags right for different fine-granular aspects of the CPU.

Next we check what cache type this CPU has in cacheid_init(). You will find these in arch/arm/include/asm/cachetype.h with the following funny names tagged on: VIVT, VIPT, ASID, PIPT. Naturally, this isn’t very helpful. These things are however clearly defined in Wikipedia, so go and read.

We then call cpu_init() which calls cpu_proc_init() which will execute the per-cputype callback cpu_*_proc_init from the CPU information containers in arch/arm/mm/proc-*.S. For example, the Faraday FA526 ARMv4 type CPU cpu_fa526_proc_init() in arch/arm/mm/proc-fa526.S will be executed.

Lastly there is a piece of assembly: 5 times invocation of the msr cpsr_c assembly instruction, setting up the stacks for the 5 different exceptions of an ARM CPU: IRQ, ABT, UND, FIQ and SVC. msr cpsr_c can switch the CPU into different contexts and set up the hardware-specific sp for each of these contexts. The CPU stores these copies of the sp internally.

The first assembly instruction loads the address of the variable stk, then this is offsetted for the struct members irq[0], abt[0], und[0], and fiq[0]. The struct stack where this is all stored was located in the beginning of the cpu_init() with these two codelines:

unsigned int cpu = smp_processor_id();
struct stack *stk = &stacks[cpu];

stacks is just a file-local struct in a cacheline-aligned variable:

struct stack {
    u32 irq[3];
    u32 abt[3];
    u32 und[3];
    u32 fiq[3];
} ____cacheline_aligned;

static struct stack stacks[NR_CPUS];

In the ARM32 case cacheline-aligned means this structure will start on an even 32, 64 or 128-byte boundary. Most commonly a 32-byte boundary, as this is the most common cacheline size on ARM32.

So we define as many exception callstacks as there are CPUs in the system. Interrupts and other exceptions thus have 3 words of callstack. We will later in this article descript how we set up the exception vectors for these exceptions as well.

Setting up the machine

We have managed to set up the CPU per se and we are back in the setup_arch() function. We now need to know what kind of machine we are running on to get further.

To do this we first look for a flattened device tree (DTB or device tree blob) by calling setup_machine_fdt(). If this fails we will fall back to ATAGs by calling setup_machine_tags() which was the mechanism used for boardfiles before we had device trees.

We have touched upon this machine characteristic before: the most important difference is that in device trees the hardware on the system is described using an abstract hierarchical tree structure and in ATAGs the hardware is defined in C code in a so-called boardfile, that will get called later during this initialization. There are actually to this day three ways that hardware is described in the ARM systems:

  1. Compile-time hardcoded: you will find that some systems such as the RISC PC or StrongARM EBSA110 (evaluation board for StrongARM 110) will have special sections even in head.S using #ifdef CONFIG_ARCH_RPC and similar constructs to kick in machine-specific code at certain stages of the boot. This was how the ARM32 kernel was started in 1994-1998 and at the time very few machines were supported. This was the state of the ARM32 Linux kernel as it was merged into the mainline in kernel v2.1.80.
  2. Machine number + ATAGs-based: as the number of ARM machines grew quickly following the successful Linux port, the kernel had to stop relying on compile-time constants and needed a way for the kernel to identify which machine it was running on at boot time rather than at compile time. For this reason ATAGs were introduced in 2002. The ATAGs are also called the kernel tagged list and they are a simple linked list in memory passed to the kernel at boot, and most importantly provides information about the machine type, physical memory location and size. The machine type is what we need to call into the right boardfile and perform the rest of the device population at runtime. The ATAGs are however not used to identify the very machine itself. To identify the machine the boot loader also passes a 32bit number in r1, then a long list of numbers identifying each machine, called mach-types, is compiled into the kernel to match this number.
  3. Device Tree-based: the Android heist in 2007 and onward started to generate a constant influx of new machine types to the ARM kernel, and the board files were growing wild. In 2010 Grant Likely proposed that ARM follow PowerPC and switch to using device trees to describe the hardware, rather than ATAGs and boardfiles. In 2011 following an outburst from Torvalds in march, the situation was becoming unmaintainable and the ARM community started to accelerate to consolidate the kernel around using device trees rather than boardfiles to cut down on kernel churn. Since then, the majority of ARM32 boards use the device tree to describe the hardware. This pattern has been followed by new architectures: Device Tree is established as the current most viable system description model for new machines.

All of the approaches use the kernel device and driver model to eventually represent the devices in the kernel – however during the very early stages of boot the most basic building blocks of the kernel may need to shortcut this to some extent, as we will see.

Whether we use ATAGs or a DTB, a pointer to this data structure is passed in register r2 when booting the kernel and stored away in the global variable __atags_pointer. The name is a bit confusing since it can also point to a DTB. When using ATAGs a second global variable named __machine_arch_type is also used, and this contains register r1 as passed from the boot loader. (This value is unused when booting from a device tree.)

Using the ATAGs or the DTB, a machine descriptor is located. This is found either from the numerical value identifying the machine in __machine_arch_type or by parsing the DTB to inspect the .compatible value of the machine, at the very top node of the device tree.

While ARM32 device tree systems are mainly relying on the device tree to boot, they also still need to match against a machine descriptor in some file under arch/arm/mach-*/*.c, defined with the macro DT_MACHINE_START. A simple grep DT_MACHINE_START gives you an idea of how many basic ARM32 machine types that boot from the device tree. The ARM64 (Aarch64) kernel, by contrast, has been engineered from start not to require any such custom machine descriptors and that is why it is not found in that part of the kernel. On ARM64, the device trees is the sole machine description.

If you inspect the arch/arm/kernel/devtree.c file you will see that a default device tree machine named Generic DT based system is defined if we are booting a multiplatform image. If no machine in any subdirectory matches the compatible-string of the device tree, this one will kick in. This way it is possible to rely on defaults and boot an ARM32 system with nothing but a device tree, provided you do not need any fix-ups of any kind. Currently quite a lot of ARM32 machines have some quirks though. ARM64 again, have no quirks on the machine level: if quirks are needed for some hardware, these will normally go into the drivers for the machine, and gets detected on a more fine-granular basis using the compatible-string or data found in hardware registers. Sometimes the ARM64 machines use firmware calls.

In either case the physical address pointing to the data structure for ATAGs or DTB is converted to a virtual address using __phys_to_virt() which involves a bit of trickery as we have described in an earlier article about phys_to_virt patching.

Memory Blocks – Part 1

One of the more important effects of calling either setup_machine_fdt() or setup_machine_tags() depending on machine, is the population of a list of memory blocks, memblocks or regions, which is the basic boot-time unit of physical RAM in Linux. Memblocks is the early memory abstraction in Linux and should be contiguous (follow each other strictly in memory). The implementation as used by all Linux architectures can be found in mm/memblock.c.

Either parser (device tree or ATAGs) identifies blocks of physical memory that are added to a list of memory blocks using the function arm_add_memory(). The memory blocks (regions) are identified with start and size, for example a common case is 128MB of memory starting at 0x00000000 so that will be a memory block with start = 0x00000000 and size = 0x08000000 (128 MB).

The memory blocks are actually stored in struct memblock_region which have members .base and .size for these two numbers, plus a flag field.

The ATAG parser calls arm_add_memory() which will adjust the memory block a bit if it has odd size: the memory block must start at a page boundary, be inside a 32bit physical address space (if we are not using LPAE), and it must certainly be on or above PHYS_OFFSET.

When arm_add_memory() has aligned a memory block it will call a facility in the generic memory manager of the Linux kernel with memblock_add() which will in effect store the list of memory blocks in a kernel-wide global list variable with the helpful name memory.

Why must the memory blocks be on or above (i.e. at higher address) than PHYS_OFFSET?

This is because of what has been said earlier about boot: we must load the kernel into the first block of physical memory. However the effect of this check is usually nothing. PHYS_OFFSET is, on all modern platforms, set to 0x00000000. This is because they all use physical-to-virtual patching at runtime. So on modern systems, as far as memory blocks are concerned: anything goes as long as they fit inside a 32-bit physical memory address space.

Consequently, the device tree parser we enter through setup_machine_fdt() does not care about adjusting the memory blocks to PHYS_OFFSET: it will end up in early_init_dt_scan_memory() in drivers/of/fdt.c which calls early_init_dt_add_memory_arch() which just aligns the memory block to a page and add it to the list with memblock_add(). This device tree parsing code is shared among other Linux architectures such as ARC or ARM64 (Aarch64).

When we later want to inspect these memory blocks, we just use the iterator for_each_mem_range() to loop over them. The vast majority of ARM32 systems have exactly one memory block/region, starting at 0x00000000, but oddities exist and these are handled by this code. An example I will use later involves two memory blocks 0x00000000-0x20000000 and 0x20000000-0x40000000 comprising 2 x 512 MB of memory resulting in 1 GB of physical core memory.

Initial Virtual Memory init_mm

After some assigning of variables for the machine, and setting up the reboot mode from the machine descriptor we then hit this:

init_mm.start_code = (unsigned long) _text;
init_mm.end_code   = (unsigned long) _etext;
init_mm.end_data   = (unsigned long) _edata;
init_mm.brk       = (unsigned long) _end;

init_mm is the initial memory management context and this is a compile-time prepared global variable in mm/init-mm.c.

As you can see we assign some variables to the (virtual) addresses of the kernel .text and .data segments. Actually this also covers the BSS section, that we have initialized to zero earlier in the boot process, as _end follows after the BSS section. The initial memory management context needs to know these things to properly set up the virtual memory. This will not be used until much later, after we have exited setup_arch() and get to the call to the function init_mm(). (Remember that we are currently still running in a rough 1MB-chunk-section mapping.)

init MM set-up Here we can see the area where the kernel memory starts at PAGE_OFFSET and how we align in the different sections into init_mm. The swapper_pg_dir is actually the page global directory of the init_mm structure as we will see later.

The Early Fixmap and early_mm_init()

Next we initialize the early fixmap. The fixmap is a virtual memory area from 0xFFC00000-0xFFF00000 where some fixed physical-to-virtual mappings can be specified. They are used for remapping some crucial parts of the memory as well as some I/O memory before the proper paging is up, so we poke around in the page table in a simplified manner and we can do a few necessary I/O operations in the virtual memory even before the proper set-up of the virtual memory.

There are four types of fixmaps on ARM32, all found in arch/arm/include/asm/fixmap.h where enum fixed_addresses define slots to be used for different early I/O maps:

  1. FIX_EARLYCON: this is a slot used by the early console TTY driver. Some serial line drivers have a special early console callback that can be used to get an early console before the actual serial driver framework has started. This is supported on ARM32 but it has a very limited value, because on ARM32 we have CONFIG_DEBUG_LL which provides a hardcoded serial port at compile time, which makes it possible to get debug output on the serial port even before we are running in virtual memory, as we have seen earlier. CONFIG_DEBUG_LL cannot be used on a multiplatform image and has the upside of using the standard serial port driver callbacks, the serial port defines an EARLYCON_DECLARE() callback and assigns functions to ->con->write/read to get both read and write support on the early console.
  2. FIX_KMAP: As can be seen from the code, this is KM_TYPE_NR * NR_CPUS. KM_TYPE_NR is tied down to 16 for ARM32, so this will be 16 maps for each CPU. This area is used for high memory “highmem”. Highmem on ARM32 is a whole story on its own and we will detail it later, but it relates to the way that the kernel uses a linear map of memory (by patching physical to virtual memory mapping as we have seen), but for now it will suffice to say that this is where memory that cannot be accessed by using the linear map (a simple addition or subtraction to get between physical and virtual memory) is temporarily mapped in so that the kernel can make use of it. The typical use case will be page cache.
  3. FIX_TEXT_POKE[0|1]: These two slots are used by debug code to make some kernel text segments writable, such as when inserting breakpoints into the code. The fixmap will open a “window” over the code that it needs to patch, modify the code and close the window again.
  4. FIX_BTMAPS: This is parameterization for 32 * 7 slots of mappings used by early ioremap, see below.

Those early fixmaps are set up during boot as we call:

pmd_t *pmd;

pmd = fixmap_pmd(FIXADDR_TOP);
pmd_populate_kernel(&init_mm, pmd, bm_pte);

The abbreviations used here include kernel page table idiosyncracies so it might be a good time to read my article on how the ARM32 page tables work.

This will create an entry in the page middle directory (PMD) and sufficient page table entries (PTE) referring to the memory at FIXADDR_TOP, and populate it with the finer granular page table entries found in bm_pte. The page table entries in bm_pte uses PAGE_SIZE granularity so usually this is a number of 0x1000 sized windows from virtual to physical memory. FIXADDR_TOP points to the last page in the FIXADDR address space, so this will be at 0xFFF00000 - PAGE_SIZE so typically at 0xFFEFF000..0xFFEFFFF. The &init_mm parameter is actually ignored, we just set up this PMD using the PTEs in bm_pte. Finally the memory storing the PMD itself is flushed in the translation lookaside buffer so we know the MMU has the right picture of the world.

Did we initialize the init_mm->pgd member now again? Nope. init_mm is a global variable defined in <linux/mm_types.h> as extern struct mm_struct init_mm, and the struct mm_struct itself is also defined in this header. To find init_mm you need to look into the core kernel virtual memory management code in mm/init-mm.c and there it is:

struct mm_struct init_mm = {
        .mm_rb          = RB_ROOT,
        .pgd            = swapper_pg_dir,
        (...)
};

So this is assigned at compile time to point to swapper_pg_dir, which we know already to contain our crude 1MB section mappings. We cross our fingers, hope that our fixmap will not collide with any of the existing 1MB section mappings, and just push a more complex, proper “PMD” entry into this PGD area called swapper_pg_dir. It will work fine.

So we still have our initial 1MB-sized section mappings, and to this we have added an entry to this new “PMD”, which in turn point to the page table entry bm_pte which stores our fixmaps.

Init MM context This illustrates the world of the init_mm memory management context. It is getting crowded in this picture. You can see the fixmap entries piling up around 0xFFF00000 and the serial port mapped in as one of the fixmaps.

Code will have to assign the physical base address (aligned to a page boundary) to use for each slot in the fixmap, and the kernel will assign and map a suitable virtual address for the physical address, for example the early console does this:

set_fixmap(FIX_EARLYCON, <physical address>);

This just loops back to __set_fixmap() in arch/arm/mm/mmu.c that looks up which virtual address has been assigned for this index (in this case the index is FIX_EARLYCON) by using __fix_to_virt() from the generic part of the fixmap in include/asm-generic/fixmap.h. There are two functions for cross referencing virtual to physical memory and vice versa that look like this:

#define __fix_to_virt(x)        (FIXADDR_TOP - ((x) << PAGE_SHIFT))
#define __virt_to_fix(x)        ((FIXADDR_TOP - ((x)&PAGE_MASK)) >> PAGE_SHIFT)

As you can see, the fixmap remappings are done one page at the time (so each remapping is one single page), backwards from FIXADDR_TOP (on ARM32 0xFFEFF000) so the first index for FIX_EARLYCON will be a page at 0xFFEFE000, the second index at 0xFFEFD000 etc.

It then looks up the PTE for this virtual address using pte_offset_fixmap():

pte_t *pte = pte_offset_fixmap(pmd_off_k(vaddr), vaddr);

Which at this point is a pointer to pte_offset_early_fixmap():

static pte_t * __init pte_offset_early_fixmap(pmd_t *dir, unsigned long addr)
{
    return &bm_pte[pte_index(addr)];
}

So we simply get a pointer to the PTE inside the bm_pte page table, which makes sense since this is the early fixmap page table where these page table entries physically reside.

Then set_fixmap() will modify the page table entry in the already registered and populated bm_pte page table by calling set_pte_at() which call set_pte_ext() which will eventually call down into per-CPU assembly symbol set_pte_ext in arch/arm/mm/proc-*.S This will conjure the right value for the PTE and write that back to the page table in the right slot, so that the virtual-to-physical mapping actually happens.

After this we call local_flush_tlb_kernel_range() just to make sure we don’t have this entry stored in the translation lookaside buffer for the CPU. We can now access the just remapped physical memory for the early console in the virtual address space. It better not be more than one page, but it’s cool: there is no memory mapped serial port that uses more than one page of memory. It will “just work”.

The early fixmaps will eventually be converted to proper (non-fixed) mappings once we call early_fixmap_shutdown() inside paging_init() which will be described later. Curiously only I/O memory is supported here. We better not use any fixmaps before early_fixmap_shutdown() that are not I/O memory and expect them to still be around after this point. This should be safe: the patching in the poke windows and the highmem business should not happen until later anyways.

As I noted the FIX_BTMAPS inside the early fixmaps are used for I/O memory. So this comes next, as well call early_ioremap_init(). As ARM32 is using the generic early ioremap code this just calls early_ioremap_setup() in mm/early_ioremap.c. This makes it possible to use early calls to ioremap(). As noted we have defined for NR_FIX_BTMAPS which we use to parameterize the generic early ioremap code. We can early ioremap 32 different memory areas.

For drivers it will transparently provide a back-end for ioremap() so that a piece of I/O memory can be remapped to a virtual address already at this point, and stay there, usually for the uptime of the system. A driver requesting an ioremap at this point will get a virtual-to-physical mapping in the assigned virtual memory area somewhere in the range 0xFFC00000-0xFFF00000 and it stays there.

Which device drivers will use these early ioremaps to get to the memory-mapped I/O? The early console is using it’s own fixmap so not that one. Well. actually not much as it looks. But it’s available.

Later, at runtime, the fixmaps will find another good use: they are used to map in highmem: memory that the kernel cannot handle due to being outside of the linear kernel map. Such areas will be mapped in here one piece at a time. This is causing complexities in the highmem handling, and is why we are investigating an end to highmem. If you do not know what highmem means in this context – do not worry! – it will be explained in more detail below.

Early Parameters

We have just set up some early mappings for the early console, so when we next call parse_early_param() in init/main.c to read a few command line parameters that just cannot wait. As the documentation in <linux/init.h> says: “only for really core code”.

Before we set up the early fixmap we actually copied the boot_command_line. This was already present since the call to setup_machine_fdt() or setup_machine_tags(). During the parsing of ATAGs or the DTB, boot_command_line is assigned from either source. So a kernel command line can be passed in from each of these two facilities. Parameters to the kernel can naturally be passed in on this command line.

The normal way to edit and pass these command line arguments is by using a facility in U-Boot, UEFI or GRUB to set them up in the boot loader before booting the kernel. U-Boot for example will either pass them in a special ATAG (old way) or by modifying the chosen node of the device tree in memory before passing a pointer to the device tree to the kernel in r2 when booting.

The early params are defined all over the kernel compiled-in code (not in modules, naturally) using the macro early_param(). Each of these result in a struct obs_kernel_param with a callback ->setup_func() associated with them, that gets stored in a table section named .init.setup by the linker and these will be called one by one at this point.

Examples of things that get set up from early params are cache policy, extra memory segments passed with mem=..., parameters to the IRQ controllers such as noapic to turn off the x86 APIC, initrd to point out the initial RAM disk.

mem is an interesting case: this is parsed by an early_param() inside setup.c itself, and if the user passed some valid mem= options on the command line, these will be added to the list of available memory blocks that we constructed from the ATAGs or DTB.

earlycon is also parsed, which will activate the early console if this string is passed on the command line. So we just enabled the special FIX_EARLYCON early fixmap, and now the early console can use this and dump out the kernel log so far. All this happens in drivers/tty/serial/earlycon.c by utilizing the early console callbacks of the currently active serial port.

If you are using device tree, early_init_dt_scan_chosen_stdout() will be called, which will call of_setup_earlycon() on the serial driver selected in the stdout-path in the chosen section in the root of the device tree, such as this:

/ {
    chosen {
         stdout-path = "uart0:19200n8";
    };
(...)

Or like this:

/ {
    chosen {
           stdout-path = &serial2;
    };
(...)
    serial2: uart@80007000 {
        compatible = "arm,pl011", "arm,primecell";
        reg = <0x80007000 0x1000>;
    };
};

The device tree parsing code will follow the phandle or use the string to locate the serial port. For this reason, to get an early console on device tree systems, all you need to pass on the command line is earlycon. The rest will be figured out by the kernel by simply inspecting the device tree.

On older systems it is possible to pass the name of the driver and a memory address of a serial port, for example earlycon=pl011,0x80007000 but this is seldomly used these days. Overall the earlycon, as noted, is seldomly used on ARM32. It is because we have the even more powerful DEBUG_LL that can always hammer out something on the serial port. If you need really early debugging information, my standard goto solution is DEBUG_LL and using printascii() until the proper kernel prints have come up. If earlycon is early enough, putting the stdout-path into your device tree and specifying the earlycon parameter should do the trick on modern systems.

Early Memory Management

As we reach early_mm_init() we issue build_mem_type_table() and early_paging_init() in sequence. This is done so that we can map the Linux memory the way it is supposed to be mapped using all features of the MMU to the greatest extent possible. In reality, this involves setting up the “extra bits” in the level-2/3 page descriptors corresponding to the page table pointer entries (PTE:s) so the MMU knows what to do.

build_mem_type_table() will fill in the mem_types[] array of memory types with the appropriate protection and access settings for the CPU we are running on. mem_types[] is an array of some 16 different memory types that can be found inside arch/arm/mm/mmu.c and list all the memory types that may exist in an ARM32 system, for example MT_DEVICE for memory-mapped I/O or MT_MEMORY_RWX for RAM that can be read, written and executed. The memory type will determine how the page descriptors for a certain type of memory gets set up. At the end of building this array, the kernel will print out some basic information about the current main memory policy, such as:

Memory policy: ECC enabled, Data cache, writeback

This tells us that was turned on by passing ecc=on on the command line, with the writeback data cache policy, which is the default. The message is a bit misleading since it actually just talks about a few select aspects of the memory policy regarding the use of ECC and the data cache. There are many other aspects to the cache policy that can be seen by inspecting the mmu.c file. It is not normal to pass in ecc=on, so this is just an example.

early_paging_init() then, is a function that calls ->pv_fixup() on the machine, and this is currently only used on the Texas Instruments Keystone 2 and really just does something useful when the symbol CONFIG_ARM_PV_FIXUP is defined. What happens then is that an address space bigger than 4GB is enabled using LPAE. This is especially complicated since on this machine even the physical addresses changes as part of the process and PHYS_OFFSET is moved upwards. The majority of ARM32 machines never do this.

We do some minor initialization calls that are required before kicking in the proper paging such as setting up the DMA zone, early calls to Xen (virtualization) and EFI. Then we get to the core of the proper Linux paging.

Paging Initialization: Lowmem and Highmem

We now reach the point where the kernel will initialize the virtual memory handling proper, using all the bells and whistles of the MMU.

The first thing we do is to identify the bounds of lowmem. ARM32 differentiates between lowmem and highmem like this:

  • Lowmem is the physical memory used by the kernel linear mapping. This is typically the virtual memory between 0xC0000000-0xF0000000, 768 MB. With an alternative virtual memory split, such as VMSPLIT_1G giving userspace 0x40000000 and kernelspace 0xC0000000 lowmem would instead be 0x40000000-0xD0000000, 2.8 GB. But this is uncommon: almost everyone and their dog uses the default VMSPLIT with 768 MB lowmem.
  • Highmem is any memory at higher physical addresses, that we cannot fit inside the lowmem linear physical-to-virtual map.

You might remember that this linear map between physical and virtual memory was important for ARM32. It is achieved by physical-to-virtual runtime patching as explained in a previous article, with the goal of being as efficient as possible.

As you can see, on ARM32 both lowmem and highmem have a very peculiar definition and those are just conventions, they have very little to do with any hardware limitations of the architecture or any other random definitions of “lowmem” and “highmem” that are out there.

A system can certainly have less than 768 MB (0x30000000) physical memory as well: then all is fine. The kernel can map in and access any memory and everyone is happy. For 14 years all ARM32 systems were like this, and “highmem” did not even exist as a concept. Highmem was added to ARM32 by Nicolas Pitre in september 2008. The use case was a Marvell DB-78x00-BP development board that happened to have 2 GB of RAM. Highmem requires fixmap support so that was added at the same time.

The kernel currently relies on being able to map all of the core memory – the memory used by the kernel itself, and all the userspace memory on the machine – into its own virtual memory space. This means that the kernel cannot readily handle a physical memory bigger than 768 MB, with the standard VMSPLIT at 0xC0000000. To handle any memory outside of these 768 MB, the FIX_KMAP windows in the fixmaps we discussed earlier are used.

Let’s inspect how this 768 MB limitation comes about.

To calculate the end of lowmem we call adjust_lowmem_bounds(), but first notice this compiled-in constant a little bit above that function:

static void * __initdata vmalloc_min =
    (void *)(VMALLOC_END - (240 << 20) - VMALLOC_OFFSET);

vmalloc is shorthand for virtual memory allocation area, and indicates the memory area where the kernel allocates memory windows. It has nothing to do with the physical memory of the kernel at this point: it is an area of virtual addresses that the kernel can use to place mappings of RAM or memory-mapped I/O. It will be used by SLAB and other kernel memory allocators as well as by ioremap(), it is a number of addresses in the kernel’s virtual memory that it will be using to access random stuff in physical memory. As we noted, we had to use early fixmaps up to this point, and the reason is exactly this: there is no vmalloc area to map stuff into yet.

The variables used for this pointer can be found in arch/arm/include/asm/pgtable.h:

#define VMALLOC_OFFSET          (8*1024*1024)
#define VMALLOC_START           (((unsigned long)high_memory + VMALLOC_OFFSET) & ~(VMALLOC_OFFSET-1))
#define VMALLOC_END             0xff800000UL

Never mind the high_memory variable in VMALLOC_START: it has not been assigned yet. We have no idea about where the virtual memory allocation will start at this point.

VMALLOC_END is hardcoded to 0xFF800000, (240 << 20) is an interesting way of writing 0x0F000000 and VMALLOC_OFFSET is 0x00800000. So vmalloc_min will be a pointer to the virtual address 0xF0000000. This lower bound has been chosen for historical reasons, which can be studied in the commit. Above this, all the way to 0xFF800000 we will find our vmalloc area.

From this we calculate the vmalloc_limit as the physical address corresponding to vmalloc_min, i.e. what address in the physical memory the virtual address 0xF0000000 corresponds to in the linear map of physical-to-virtual memory. If our kernel was loaded/decompressed at 0x10008000 for example, that usually corresponds to 0xC0008000 and so the offset is 0xB0000000 and the corresponding physical address for 0xF0000000 would be 0xF0000000 - 0xB0000000 = 0x40000000. So this is our calculated vmalloc_limit.

We arrive at the following conclusion: since the kernel starts at 0x10000000 (in this example) and the linear map of the kernel stretches from 0x10000000-0x40000000 (in virtual address space 0xC0000000-0xF0000000) That would be the equivalent of 0x30000000 bytes of memory, i.e. 768MB. This holds in general: the linear map of the kernel memory is 768 MB. The kernel and all memory it directly references must fit in this area.

In adjust_lowmem_bounds() we first loop over all memblocks to skip over those that are not “PMD-aligned” which means they do not start at a physical address evenly divisible by 0x00200000 (2 MB) on ARM systems. These are marked nomap in the memblock mechanism, so they will not be considered for kernel mappings.

The patch-phys-to-virt mechanism and the way we map page tables over the kernel relies on the kernel being at a PMD boundary so we will not be able to use memory blocks that do not start at a PMD-aligned memory address. If the memory block is such an off thing, such as when a machine has some small memories at random locations for things like graphics or other buffers, these will not be considered as a candidate for the core of the system. You can think about this as a heuristic that says: “small memories are probably not supposed to be used as main RAM memory”.

The next loop is more interesting. Here we again loop over the memblocks, but skip over those we just marked as unfit for the core memory. For those that remain we check if they start below vmalloc_limit (in our example at 0x40000000). As the memory we are executing inside certainly must start below vmalloc_limit we have a core memory candidate and inspect it further: if the block ends above the current lowmem_limit we bump lowmem_limit to the end of the block, unless it would go past vmalloc_limit, in that case we will truncate it at vmalloc_limit. This will in effect fit the core memory candidate over the 768 MB available for lowmem, and make sure that lowmem_limit is at the end of the highest memblock we can use for the kernel alternatively at the hard vmalloc_limit if that is lower than the end of the memblock. vmalloc_limit in turn is just calculated by subtracting vmalloc_reserve from VMALLOC_END, and that is parsed from a command line argument, so if someone passed in a minimum size of vmalloc reservation space, that will be respected.

In most cases arm_vmalloc_limit will be at the end of the highest located memblock. Very often there is just one big enough memblock on a given system.

The loop is necessary: there could be two blocks of physical memory adjacent to each other. Say one memblock at 0x00000000-0x20000000 and another memblock at 0x20000000-0x40000000 giving 2 x 512 MB = 1 GB of core memory. Both must be mapped to access the maximum of core memory. The latter will however be truncated by the code so that it ends at vmalloc_limit, which will be at 0x30000000 as we can only map 768 MB of memory. Oops.

The remainder of the second memblock will be called highmem if we have enabled highmem support, else we will just call memblock_remove() to delete the remainder from the system, and in this case the remaining memory will be unused so we print a warning about this: “Consider using a HIGHMEM enabled kernel.”

Lowmem and highmem on 1 GB This shows how a 1 GB physical memory in two memblocks of 512 MB each starting at physical address 0x00000000 gets partitioned into a lowmem of 768 MB and highmem of 256 MB. The upper 256 MB cannot fit into the linear kernel memory map!

Lowmem and highmem on 2 GB If we instead have four memblocks of 512 MB physical memory comprising a total of 2 GB, the problem becomes ever more pronounced: 1.2 GB of memory is now in highmem. This reflects the situation in the first Marvell board with 2 GB of memory that initiated the work on highmem support for ARM32.

After exiting the function we set arm_lowmem_limit to the lowmem_limit we found. In our example with these two 512 MB banks, it will be set at physical address 0x30000000. This is aligned to the PMD granularity (0x00200000) which will again be 0x30000000, and set as a limit for memory blocks using memblock_set_current_limit(). The default limit is 0xFFFFFFFF so this will put a lower bound on where in physical memory we can make allocations with memblocks for the kernel: the kernel can now only allocate in physical memory between 0x00000000-0x30000000.

We immediately also assign high_memory to the virtual memory address right above arm_lowmem_limit, in this case 0xF0000000 of course. That means that this definition from arch/arm/include/asm/pgtable.h is now resolved:

#define VMALLOC_START (((unsigned long)high_memory + VMALLOC_OFFSET) & ~(VMALLOC_OFFSET-1))

And we find that VMALLOC_START is set to 0xF0800000. The VMALLOC area is now defined to be 0xF0800000-0xFF800000, 0x0F000000 bytes (240 MB). This looks familiar to the (240 << 20) statement in the vmalloc_min definition.

Next

This exploration will be continued in Setting Up the ARM32 Architecture, part 2 where we will take a second round around the memory blocks and set up the paging.


Read more...

from linusw

As I continue to describe in different postings how the ARM32 start-up sequence works, it becomes necessary to explain in-depth the basic kernel concepts around page tables and how it is implemented on ARM32 platforms.

To understand the paging setup, we need to repeat and extend some Linux paging lingo. Some good background is to read Mel Gormans description of the Linux page tables from his book “Understanding the Linux Virtual Memory Manager”. This book was published in 2007 and is based on Mel’s PhD thesis from 2003. Some stuff has happened in the 13 years since then, but the basics still hold. It is necessary to also understand the new layers in the page tables such as the five layers of page tables currently used in the Linux kernel.

First a primer: the ARM32 architecture with a classic MMU has 2 levels of page tables and the more recent LPAE (Large Physical Address Extension) MMU has 3 levels of page tables.

Only some of the ARMv7 architectures have LPAE, and it is only conditionally enabled, i.e. the machines can also use the classic MMU if they want, they have both. It is not enabled by default on the multi_v7 configuration: your machine has to explicitly turn it on during compilation. The layout is so different that the same binary image can never support both classic and LPAE MMU in the same kernel image.

Early implementations of ARMv7-A such as Cortex A8 and Cortex A9 do not support LPAE, rather it was introduced during the lifetime of this architecture. Since this is a compile-time setting, the default configuration for ARMv7 cannot enable it by default, or the older implementations would break. ARMv8 implementations all have LPAE enabled by default.

But let’s first discuss how Linux see the world of paging.

The Linux Kernel View of Page Tables

The generic paging management mechanism in the Linux kernel sees the world like this:

Paging directories Abstract page tables in the Linux kernel proceed from the PGD (page global directory) thru the P4D (fourth level directory), PUD (page upper directory), PMD (page middle directory) and down to the actual page table entries (PTEs) that maps individual pages pages of memory from virtual to physical address space.

Abbreviations:

  • pgd, pgd_t, pgdval_t = Page Global Directory – the Linux kernel main page table handling the PGD for the kernel memory is found in symbol swapper_pg_dir
  • p4d, p4d_t, p4dval_t = Page Level 4 Directory was introduced to handle 5-level page tables after the pud was introduced. Now it was clear that we need to replace pgd, pmd, pud with a figure indicating the directory level and we cannot go on with natural names any more. This is unused on ARM32.
  • pud, pud_t, pudval_t = Page Upper Direcory was introduced after the other abstractions to deal with 4-level page tables. Like p4d, this is unused on ARM32.
  • pmd, pmd_t, pmdval_t = Page Middle Directory, ARM32 uses this.
  • pte, pte_t, pteval_t = Page Table Entry, ARM32 uses this.
  • pfn = Page Frame Number each page in physical memory has a unique number, address 0x00000000 is page 0, address 0x00001000 is page 1 etc (see include/asm-generic/memory_model.h)

First and foremost notice that these are all except PTE named something-directory. This is because they all contain several pointers down to objects of the next level. Like any directory. So each of the entities PGD, P4D … etc are arrays of pointers. The PTE despite having a singular form also contain several pointers.

The Linux kernel will act as if 5 levels of page tables exist. This is of course grossly over-engineered for ARM32 which has 2 or 3 levels of page tables, but we need to cater for the rest of the world. One size fits all. In practice, the code is organized such that these page tables “fold” and we mostly skip over the intermediate translation steps when possible.

The other thing you need to know about the page table hierarchy is that on the lowest level the PTEs contains a number of pointers, which are 1-to-1 translation chunks. On ARM32, on the PTE level we always have 512 pointers per PTE, and each pointer translates one 4KB page (0x1000) of memory.

Page Table Entry A PTE on ARM32 contains 512 pointers, i.e. translations between physical and virtual pages. From the generic kernel virtual memory management point of view it is not important how this translation actually happens in hardware, all it needs to know is that a page of size 0x1000 (4KB) is translated by a single PTE pointer entry. This way a PTE is a directory, just like everything else in the page hierarchy. In the example the first pointer in the PTE translates physical address 0x10000000 to virtual address 0xC0000000.

On the PMD level the classic ARM32 MMU has one pointer per PMD and 2048 pointers per PGD. The P4D and PUD levels are “folded” i.e. unused. Having one pointer per PMD seems vaguely pointless: we have level-1 in the 2048 pointers in the PGD and level-2 in the 512 pointers in the PTE. You rightfully ask what the point is to have a “three level” hierarchy with the middle directory having one pointer per PMD. This is a way of fitting the Linux idea about page hierarchy with the actual ARM32 architecture, and will be explained shortly.

Classic ARM MMU page table The classic ARM32 paging setup in Linux folds P4D and PUD, providing 2048 pointers per PGD, 1 pointer per PMD and 512 pointers per PTE. It uses 3 levels of the hierarchy while ARM32 hardware only has two. This is however a good fit, as we shall see. To the left the object relations, to the right an illustration of the tables.

On LPAE the story is simpler: each PGD has 4 pointers covering 1GB each (for a total of 4GB of memory) and 512 pointers per PMD dividing each 1GB into 2MB chunks, then 512 pointers per PTE dividing the 2MB chunks into 4KB chunks (pages). The math should match up. The LPAE MMU can of course put more pointers into the PGD to cover up to 1TB of memory. Currently no ARM32 architectures need this so we just hammer it down to 4GB maximum for kernelspace. 4GB of kernelspace memory should be enough for everyone. Userspace is another story.

LPAE MMU page table The LPAE page table also folds P4D and PUD but has something meaningful on the PMD level: 4 PGD entries covering 1 GB each covers the whole 32bit address space, then there are 512 pointers per PMD and 512 pointers per PTE. Each PTE entry translate 4KB of physical memory to virtual memory. If we would fill the PGD with all the 512 available entries it would span exactly 1 TB of memory.

So when we say that the classic ARM32 MMU has 2 levels of page tables, we are presenting this to Linux in a peculiar way as “3 levels” where the middle one is a single pointer, whereas the LPAE MMU actually has 3 levels. We are sorry for the confusion.

Obtaining Pointers to Directory Entries

The pointer to an index in a directory is obtained with special inlined accessors that take a virtual address as parameter named for example pmd_off() and those traverse the whole hierarchy to get to the offset of the right element in hierarchy:

static inline pmd_t *pmd_off(struct mm_struct *mm, unsigned long va)
{
        return pmd_offset(pud_offset(p4d_offset(pgd_offset(mm, va), va), va), va);
}

On ARM32 the P4D and PUD parts of this ladder will resolve to nothing, get “folded” and optimized out at compile-time. The struct mm_struct *mm argument is the actual memory manager context (for the kernel this is init_mm) which stores the pointer to the memory where the page global directory (PGD) actually resides. And that will the the symbol swapper_pg_dir if we are running kernel code. This is how it actually happens in include/linux/pgtable.h;

#define pgd_offset(mm, address)         pgd_offset_pgd((mm)->pgd, (address))

(...)

static inline pgd_t *pgd_offset_pgd(pgd_t *pgd, unsigned long address)
{
        return (pgd + pgd_index(address));
};

In kernelspace mode the mm argument is init_mm and the ->pgd pointer points to swapper_pg_dir, the kernel memory space root page table and equal to the location in virtual memory of the actual physical global page table. All index pointer accessors operate on this principle.

The ARM32 View of the Page Tables

The virtual address for the kernespace global page directory is PAGE_OFFSET+0x3000 or PAGE_OFFSET+0x4000 and PAGE_OFFSET depends on the kernel VMSPLIT, but is typically 0xC0000000, kernel memory from 0xC0000000..0xFFFFFFFF. On ARM32 this base address, in physical memory, is set in TTBR0 (Translation Table Base Register). Linux uses the symbol swapper_pg_dir for this address. This is 0x5000 bytes in size for LPAE and 0x4000 bytes in size for the classic ARM MMU. If the kernel starts at the physical address 0xnnnn8000 it is at 0xnnnn8000-PG_DIR_SIZE so at 0xnnnn3000..0xnnnn7FFF for LPAE and 0xnnnn4000..0xnnnn7FFF for any other ARM. The most common location is at 0xC0004000..0xC0007FFF in virtual memory.

PTE page table entries and the associated types pte_t and pteval_t is of course purely a Linux concept. And that shows. Because what ARM32 MMUs are thinking about is not PTEs but coarse 2- or 3-level page tables of 4KB pages. It would be neat if Linux was engineered in a more flexible way to allow for a coarse page table to be ONE PTE but it isn’t always the case, for old ARM32 systems it definitely is not.

“Coarse” in this context means we start at a level-1 descriptor and see that for this 1MB of virtual memory we are using some smaller 4K pages so we have to look further: go and walk the page table ladder using the modified virtual address I give you here. ARM MMUs also have a concept of “fine” pages of just 1K. Linux does not use these. Yet.

We are here dealing with PAGE_SIZE granularity, and Linux memory manager expects a PTE to be one page big and full of pointers so we will for example call arm_pte_alloc() to allocate a new level-2 page (or level-3 on LPAE) table of 0x1000 (4096) bytes. That much is simple.

The world is also reasonably simple on LPAE systems, because there the PTE is indeed one page, and it is populated by 512 entries of 64 bits / 8 bytes each, meaning we have 512 * 8 = 4096 bytes and it is a perfect match. Also these 64 bits fulfils the contract between Linux’ memory manager and the architecture of providing some MMU facilities such as a “dirty” bit. One PTE on a LPAE MMU is one page full of these coarse third level descriptors (remember that LPAE has three levels of pages). This nice fit will also be the case on the ARM64 / Aarch64 platform. End of story. Good for them!

What is not so simple is how Linux utilize these 4096 bytes on the classic oldschool ARM MMU, which is described in include/asm/pgtable-2level.h.

What is done on the classic MMU is that we put the course page table index into the modified virtual address (MVA) field of the level-1 descriptor. This “coarse page table index” is in bits 10-31 of the level-1 descriptor (which is half a PGD entry, more about that later) and that corresponds to the highest 21 bits of the physical address of the level-2 page table. What is peculiar about the course page table index is that it does not correspond to a page in memory. Instead it corresponds to a quarter of a page. This is logical because level-2 page tables are 32 bit / 4 bytes and we need 256 of them to cover 1MB which is the coarseness of the level-1 descriptor, thus we need 256 * 4 = 1024 = 0x400 bytes. That’s one quarter of a 4KB page. So the coarse page table index points to a location in virtual memory indexed by the 0x400:th chunk. Which is mildly confusing.

Further we have the following problem: ARMs classic MMU does not have all the “dirty” and “accessed”/”young” bits that the generic Linux virtual memory manager presuppose to exist in the architecture.

One could imagine telling the Linux virtual memory manager that we have only 256 pointers per PTE, put some metadata in the remainder but end up using only half a page and waste lots of memory for the PTEs.

The actual solution, as implemented on ARM32 (I think this was invented by Russell King), is to squeeze in as much as possible in a page as follows:

  • Tell the Linux virtual memory manager that we have 512 page descriptors, which Linux calls “pointers” in a PTE, even though we know very well that the hardware has 256 of them. This is done by setting PTRS_PER_PTE to 512 in include/asm/pgtable-2level.h
  • Tell it that we map 2 MB of memory in a PMD. This is done by defining PMD_SHIFT to 21 in include/asm/pgtable-2level.h. This is done despite the fact that we know very well that a level-1 descriptor maps 1 MB and not 2 MB of memory. We also make the page middle directory into a 1-to-1 directory with just one pointer per PMD: PTRS_PER_PMD is set to 1.
  • Set __PAGETABLE_PMD_FOLDED so we don't allocate any real backing data structures for the PMDs, as these will be stored inside the PGD.
  • Tell it that the PGD contains 2048 pointers (setting PTRS_PER_PGD to 2048), while in fact the 0x4000 bytes of level-1 descriptors have 4096 pointers, that we just group in pairs.
  • Whenever the generic memory manager asks for a PGD entry we reference a PMD pointer with two level-1 page table descriptors.
  • Whenever the generic memory manager asks for a PMD entry we reference a 1-to-1 entity.
  • Whenever the generic memory manager asks for a PTE entry we reference two level-2 page table descriptors and two metadata entries of 32 bits each.

We then occupy half a page with these two sets of level-2 descriptors. To solve the mapping problem for different “accessed” or “young” bits, we use the half page that is left to hold some metadata about what Linux has requested so we can do a bit of back-and-forward emulation of the features that Linux virtual memory manager wants.

We have effectively posed to the kernel virtual memory manager that we have an MMU with three levels of page tables: PGD (2048 pointers), PMD (one pointer) and PTE (512 pointers), while in fact we have two, and then behind the back of the generic virtual memory manger we do this optimization to adjust the map to reality.

This is not so bad: the virtual memory manager is well aware that not the whole world uses all five levels of page tables it supports, so it has been written to “fold” levels like our artificial PMD already. This will work just fine.

Alas, this is not a very simple solution. But it is very efficient, counterintuitive and complicated. Since operating system development can be pretty hard in the details, this is what we can expect.

Classic page table The classic ARM32 MMU page table layout uses 32bit descriptors in two levels: two level-1 descriptors in the global page table (TTB, what Linux calls PGD, page global directory) are grouped into one PMD (page middle directory). There are 4096 level-1 descriptors grouped in pairs to form a PMD so there are 2048 PMDs. Then 256 + 256 = 512 level-1 page table pointers are grouped into one PTE (page table entry) with some metadata right above it. What Linux sees is a PMD managing 2MB and a PTE managing 256 4K pages which is also 2 MB. This way a PTE fills exactly one page of memory, which simplifies things. The 4K level-2 descriptors are referred to as “coarse”.

Level 1 and Level 2 classic descriptors The rough format of the 32bit Level-1 and Level-2 page descriptors used in the classic ARM32 MMU, which is what most ARM32 Linux kernels use. A “coarse” level-1 descriptor points to “small page” (4KB) page descriptor. As can be seen, the memory area covered at each level is mapped by simply using the high bits of the physical address as is common in MMUs. Some domain and access control is stuffed in in the remaining bits, the bits explicitly set to 0 or 1 should be like so.

An LPAE page table set-up on the other hand is simpler and deeper than the classic MMU: the descriptors are 64bit wide and include all the bits that Linux needs. Four 64bit level-1 descriptors/PGD pointers covering the first 4GB of physical memory (0x00000000-0xFFFFFFFF) at typically at 0xC0003000 points to the 512 level-2 descriptors/PMD pointers at 0xC0004000 and these are 64bit but cover 2MB each so they cover the same amount of virtual memory space as the classic MMU: instead of 1024 32 bit “coarse” entries covering 1MB each, we have 512 64bit entries covering 2MB each. This makes 1 PGD pointer correspond exactly to 1 level-1 page descriptor 1 PMD pointer correspond exactly to one level-2 page descriptor.

The level-2 descriptor points to a level-3 descriptor which is also 64bits wide and covers 4KB. At the third level, 512 4KB descriptors cover 2MB and perfectly fill out exactly one 4KB page of memory. Further, the descriptor layout in the level-3 descriptors fits hand-in-glove with Linux’ idea about what special bits it wants like “dirty”, “young” and “accessed”. PGD, PMD and PTE have identical concepts in hardware and this makes things much more intuitive. ARM64/Aarch64 also uses this style of page descriptors.

Classic page table The LPAE page table layout is simpler and more intuitive than the classic MMU. 64bit pointers on each level in three levels, where one descriptor corresponds to one PGD, PMD or PTE entry, we use 4 PGD pointers consecutive at 0xC0003000, one PMD has 512 64-bit pointers in each of the 4 pages at 0xC0004000, 0xC0005000, 0xC0006000 and 0xC0007000 to PTEs, and one PTE is exactly one page (0x1000 bytes) and consists of exactly 512 64-bit translation pointers.


Read more...

from Konstantin Ryabitsev

You can have lore.kernel.org mailing lists delivered right into your inbox straight from the git archive (in fact, this will work for any public-inbox server, not just for lore.kernel.org). It's efficient and (optionally) preserves a full copy of entire list archives on your system — should youwish to keep them.

Note: this requires grokmirror-2.0.2+, as earlier versions do not come with the grok-pi-piper utility.

Installing grokmirror-2.0

Easiest is to install from pip:

pip install --user grokmirror~=2.0.2

You may have grokmirror available from your distro packages, too, but make sure it's version 2.0.2 or above.

Installing procmail

Procmail should be available with your distribution, so install it like any other package.

Configuring procmail

Procmail configuration can be a book in itself, but if you just want to have messages delivered into your inbox, all you have to do is create a ~/.procmailrc with the following contents:

DEFAULT=$HOME/Mail/

# Don't deliver duplicates sent to multiple lists
:0 Wh: .msgid.lock
| formail -D 8192 .msgid.cache

If your mailbox is not in ~/Mail, then you should adjust the above accordingly.

Configuring grokmirror

Create a ~/.config/lore.conf with the following contents. We'll use three lists as examples: git, linux-hardening, and linux-doc, but you'll obviously want to use the lists you care about. You can see which lists are available from https://lore.kernel.org/lists, or the exact git repositories on https://erol.kernel.org/.

[core]
toplevel = ~/.local/share/grokmirror/lore
log = ${toplevel}/grokmirror.log

[remote]
site = https://lore.kernel.org
manifest = https://lore.kernel.org/manifest.js.gz

[pull]
post_update_hook = ~/.local/bin/grok-pi-piper -c ~/.config/pi-piper.conf
refresh = 300
include = /git/*
          /linux-hardening/*
          /linux-doc/*

The above assumes that you installed grokmirror with pip install --user. Now make the toplevel directory for the git repos:

$ mkdir -p ~/.local/share/grokmirror/lore

Configuring pi-piper

The last step is to create ~/.config/pi-piper.conf:

[DEFAULT]
pipe = /usr/bin/procmail
shallow = yes

The important bit here is shallow = yes. Public-inbox stores every mail message as a separate commit, so once a message is piped to procmail and delivered, we usually don't care about keeping a copy of that commit any more. If you set shallow = yes, pi-piper will prune all but the last successfully processed commit out of your local git copy by turning those repos into shallow git repositories. This helps to greatly save disk space, especially for large archives.

If you do want to keep full archives, then don't set shallow. You can change your mind at any time by running git fetch _grokmirror master --unshallow in each underlying git repository (you can find them in ~/.local/share/grokmirror/lore/).

You can also specify the shallow option per list:

[DEFAULT]
pipe = /usr/bin/procmail

[linux-hardening]
shallow = yes

Running grok-pull

You can now run grok-pull to get the initial repo copies. Note, that during the first run grokmirror will perform full clones even if you specified shallow = yes in the pi-piper config, so it may take some time for large archives like those for the git list. However, once the pi-piper hook runs, they will be repacked to almost nothing. Future versions of grokmirror may become smarter about this and perform shallow clones from the beginning.

During the initial pi-piper run, there will be no mail delivered, as it will just perform initial setup and make a note where the HEAD is pointing. If you run grok-pull again, two things may happen:

  1. There will be no changes and grok-pull will exit right away
  2. If there are changes, they will be fetched and the hook will deliver them to procmail (and to your inbox)

Running in the background

You can run grok-pull in the background, where it will check for updates as frequently as the refresh setting says (300 seconds in the example above).

You can either background it “the old way”:

grok-pull -o -c ~/.config/lore.conf &

Or the new way, using a systemd user service:

$ cat .config/systemd/user/grok-pull@.service

[Unit]
Description=Grok-pull service for %I
ConditionPathExists=%h/.config/%i.conf

[Service]
ExecStart=%h/.local/bin/grok-pull -o -c %h/.config/%i.conf
Type=simple
Restart=on-failure

[Install]
WantedBy=default.target

$ systemctl --user enable grok-pull@lore
$ systemctl --user start grok-pull@lore

If you make changes to ~/.config/lore.conf, for example to add new lists, you will need to restart the service:

$ systemctl --user restart grok-pull@lore

Combining with mbsync

You can totally combine this with mbsync and deliver into the same local inbox. As a perk, any messages injected from grokmirror will be uploaded to your remote imap mailbox. See this post from mcgrof about configuring mbsync:

Troubles

Email tools@linux.kernel.org if you have any trouble getting the above to work. The grok-pi-piper utility is fairly new, so it's entirely possible that it's full of bugs.


Read more...

from linusw

My previous article on how the kernel decompresses generated a lot of traffic and commentary, much to my surprise. I suppose that this may be because musings of this kind fill the same niche as the original Lions' Commentary on UNIX 6th Edition, with Source Code which was a major hit in the late 1970s. Operating system developers simply like to read expanded code comments, which is what this is.

When I’m talking about “ARM32” the proper ARM name for this is Aarch32 and what is implemented physically in the ARMv4 thru ARMv7 ARM architectures.

In this post I will discuss how the kernel bootstraps itself from executing in physical memory after decompression/boot loader and all the way to executing generic kernel code written in C from virtual memory.

This Is Where It All Begins

After decompression and after augmenting and passing the device tree blob (DTB) the ARM32 kernel is invoked by putting the program counter pc at the physical address of the symbol stext(), start of text segment. This code can be found in arch/arm/kernel/head.S.

A macro __HEAD places the code here in a linker section called .head.text and if you inspect the linker file for the ARM architecture at arch/arm/kernel/vmlinux.lds.S you will see that this means that the object code in this section will be, well, first.

This will be at a physical address which is evenly divisible by 16MB and an additional 32KB TEXT_OFFSET (which will be explained more later) so you will find stext() at an address such as 0x10008000, which is the address we will use in our example.

head.S contains a small forest of exceptions for different old ARM platforms making it hard to tell the trees from the forest. The standards for ATAGs and device tree boots came about since it was written so this special code has become increasingly complex over the years.

To understand the following you need a basic understanding of paged virtual memory. If Wikipedia is too terse, refer to Hennesy & Patterson’s book “Computer Architecture: A Quantitative Approach”. Knowing a bit of ARM assembly language and Linux kernel basics is implied.

ARM’s Virtual Memory Split

Let’s first figure out where in virtual memory the kernel will actually execute. The kernel RAM base is defined in the PAGE_OFFSET symbol, which is something you can configure. The name PAGE_OFFSET shall be understood as the virtual memory offset for the first page of kernel RAM.

You choose 1 out of 4 memory split alternatives, which reminds me about fast food restaurants. It is currently defined like this in arch/arm/Kconfig:

config PAGE_OFFSET
        hex
        default PHYS_OFFSET if !MMU
        default 0x40000000 if VMSPLIT_1G
        default 0x80000000 if VMSPLIT_2G
        default 0xB0000000 if VMSPLIT_3G_OPT
        default 0xC0000000

First notice that if we don’t have an MMU (such as when running on ARM Cortex-R class devices or old ARM7 silicon) we will create a 1:1 mapping between physical and virtual memory. The page table will then only be used to populate the cache and addresses are not rewritten. PAGE_OFFSET could very typically be at address 0x00000000 for such set-ups. Using the Linux kernel without virtual memory is referred to as “uClinux” and was for some years a fork of the Linux kernel before being brought in as part of the mainline kernel.

Not using virtual memory is considered an oddity when using Linux or indeed any POSIX-type system. Let us from here on assume a boot using virtual memory.

The PAGE_OFFSET virtual memory split symbol creates a virtual memory space at the addresses above it, for the kernel to live in. So the kernel keep all its code, state and data structures (including the virtual-to-physical memory translation table) at one of these locations in virtual memory:

  • 0x40000000-0xFFFFFFFF
  • 0x80000000-0xFFFFFFFF
  • 0xB0000000-0xFFFFFFFF
  • 0xC0000000-0xFFFFFFFF

Of these four, the last location at 0xC0000000-0xFFFFFFFF is by far the most common. So the kernel has 1GB of address space to live in.

The memory below the kernel, from 0x00000000-PAGE_OFFSET-1, i.e. typically at address 0x00000000-0xBFFFFFFF (3 GB) is used for userspace code. This is combined with the Unix habit to overcommit, which means that you optimistically offer programs more virtual memory space than what you have physical memory available for. Every time a new userspace process starts up it thinks that it has 3 gigabytes of memory to use! This type of overcommit has been a characteristic of Unix systems since their inception in the 1970s.

Why are there four different splits?

This is pretty straightforward to answer: ARM is heavily used for embedded systems and these can be either userspace-heavy (such as an ordinary tablet or phone, or even a desktop computer) or kernel-heavy (such as a router). Most systems are userspace-heavy or have so little memory that the split doesn’t really matter (neither will be very occupied), so the most common split is to use PAGE_OFFSET 0xC0000000.

Kernelspace userspace split The most common virtual memory split between kernelspace and userspace memory is at 0xC0000000. A notice on these illustrations: when I say memory is “above” something I mean lower in the picture, along the arrow, toward higher addresses. I know that some people perceive this as illogical and turn the figure upside-down with 0xFFFFFFFF on the top, but it is my personal preference and also the convention used in most hardware manuals.

It could happen that you have a lot of memory and a kernel-heavy use case, such as a router or NAS with lots of memory, say a full 4GB of RAM. You would then like the kernel to be able to use some of that memory for page cache and network cache to speed up your most typical use case, so you will select a split that gives you more kernel memory, such as in the extreme case PAGE_OFFSET 0x40000000.

This virtual memory map is always there, also when the kernel is executing userspace code. The idea is that by keeping the kernel constantly mapped in, context switches from userspace to kernelspace become really quick: when a userspace process want to ask the kernel for something, you do not need to replace any page tables. You just issue a software trap to switch to supervisor mode and execute kernel code, and the virtual memory set-up stays the same.

Context switches between different userspace processes also becomes quicker: you will only need to replace the lower part of the page table, and typically the kernel mapping as it is simple, uses a predetermined chunk of physical RAM (the physical RAM where it was loaded to begin with) and is linearly mapped, is even stored in a special place, the translation lookaside buffer. The translation lookaside buffer, “special fast translation tables in silicon”, makes it even faster to get into kernelspace. These addresses are always present, always linearly mapped, and will never generate a page fault.

Where Are We Executing?

We continue looking at arch/arm/kernel/head.S, symbol stext().

The next step is to deal with the fact that we are running in some unknown memory location. The kernel can be loaded anywhere (provided it is a reasonably even address) and just executed, so now we need to deal with that. Since the kernel code is not position-independent, it has been linked to execute at a certain address by the linker right after compilation. We don’t know that address yet.

The kernel first checks for some special features like virtualization extensions and LPAE (large physical address extension) then does this little dance:

    adr        r3, 2f
    ldmia      r3, {r4, r8}
    sub        r4, r3, r4            @ (PHYS_OFFSET - PAGE_OFFSET)
    add        r8, r8, r4            @ PHYS_OFFSET
    (...)
    2:         .long        .
               .long      PAGE_OFFSET

.long . is link-time assigned to the address of the label 2: itself, so . is resolved to the address that the label 2: is actually linked to, where the linker imagines that it will be located in memory. This location will be in the virtual memory assigned to the kernel, i.e. typically somewhere above 0xC0000000.

After that is the compiled-in constant PAGE_OFFSET, and we already know that this will be something like 0xC0000000.

We load in the compile-time address if 2: into r4 and the constant PAGE_OFFSET into r8. Then we subtract that from the actual address of 2:, which we have obtained in r3 using relative instructions, from r4. Remember that ARM assembly argument order is like a pocket calculator: sub ra, rb, rc => ra = rb - rc.

The result is that we have obtained in r4 the offset between the address the kernel was compiled to run at, and the address it is actually running at. So the comment @ (PHYS_OFFSET - PAGE_OFFSET) means we have this offset. If the kernel symbol 2: was compiled to execute at 0xC0001234 in virtual memory but we are now executing at 0x10001234 r4 will contain 0x10001234 - 0xC0001234 = 0x50000000. This can be understood as “-0xB0000000” because the arithmetic is commutative: 0xC0001234 + 0x50000000 = 0x10001234, QED.

Next we add this offset to the compile-time assigned PAGE_OFFSET that we know will be something like 0xC0000000. With wrap-around arithmetic, if we are again executing at 0x10000000 we get 0xC0000000 + 0x50000000 = 0x10000000 and we obtained the base physical address where the kernel is currently actually executing in r8 – hence the comment @PHYS_OFFSET. This value in r8 is what we are actually going to use.

The elder ARM kernel had a symbol called PLAT_PHYS_OFFSET that contained exactly this offset (such as 0x10000000), albeit compile-time assigned. We don’t do that anymore: we assign this dynamically as we shall see. If you are working with operating systems less sophisticated than Linux you will find that the developers usually just assume something like this in order to make things simple: the physical offset is a constant. Linux has evolved to this because we need to handle booting of one single kernel image on all kinds of memory layouts.

Physical virtual split 1 I do not know if this picture makes things easier or harder to understand. It illustrates physical to virtual memory mapping in our example.

There are some rules around PHYS_OFFSET: it needs to adhere to some basic alignment requirements. When we determine the location of the first block of physical memory in the uncompress code we do so by performing PHYS = pc & 0xF8000000, which means that the physical RAM must start at an even 128 MB boundary. If it starts at 0x00000000 that’s great for example.

There are some special considerations around this code for the XIP “execute in place” case when the kernel is executing from ROM (read only memory) but we leave that aside, it is another oddity, even less common than not using virtual memory.

Notice one more thing: you might have attempted to load an uncompressed kernel and boot it and noticed that the kernel is especially picky about where you place it: you better load it to a physical address like 0x00008000 or 0x10008000 (assuming that your TEXT_OFFSET is 0x8000). If you use a compressed kernel you get away from this problem because the decompressor will decompress the kernel to a suitable location (very often 0x00008000) and solve this problem for you. This is another reason why people might feel that compressed kernels “just work” and is kind of the norm.

Patching Physical to Virtual (P2V)

Now that we have the offset between virtual memory where we will be executing and the physical memory where we are actually executing, we reach the first sign of the Kconfig symbol CONFIG_ARM_PATCH_PHYS_VIRT.

This symbol was created because developers were creating kernels that needed to boot on systems with different memory configurations without recompiling the kernel. The kernel would be compiled to execute at a certain virtual address, like 0xC0000000, but can be loaded into memory at 0x10000000 like in our case, or maybe at 0x40000000, or some other address.

Most of the symbols in the kernel will not need to care of course: they are executed in virtual memory at an adress to which they were linked and to them we are always running at 0xC0000000. But now we are not writing some userspace program: things are not easy. We have to know about the physical memory where we are executing, because we are the kernel, which means that among other things we need to set up the physical-to-virtual mapping in the page tables, and regularly update these page tables.

Also, since we don’t know where in the physical memory we will be running, we cannot rely on any cheap tricks like compile-time constants, that is cheating and will create hard to maintain code full of magic numbers.

For converting between physical and virtual addresses the kernel has two functions: __virt_to_phys() and __phys_to_virt() converting kernel addresses in each direction (not any other addresses than those used by the kernel memory). This conversion is linear in the memory space (uses an offset in each direction) so it should be possible to achieve this with a simple addition or subtraction. And this is what we set out to do, and we give it the name “P2V runtime patching” . This scheme was invented by Nicolas Pitre, Eric Miao and Russell King in 2011 and in 2013 Santosh Shilimkar extended the scheme to also apply to LPAE systems, specifically the TI Keystone SoC.

The main observation is that if it holds that, for a kernel physical address PHY and a kernel virtual address VIRT (you can convince yourself of these two by looking at the last illustration):

PHY = VIRT – PAGE_OFFSET + PHYS_OFFSET VIRT = PHY – PHYS_OFFSET + PAGE_OFFSET

Then by pure laws of arithmetics it also holds that:

PHY = VIRT + (PHYS_OFFSET – PAGE_OFFSET) VIRT = PHY – (PHYS_OFFSET – PAGE_OFFSET)

So it is possible to always calculate the physical address from a virtual address by an addition of a constant and to calculate the virtual address from a physical address by a subtraction, QED. That is why the initial stubs looked like this:

static inline unsigned long __virt_to_phys(unsigned long x)
{
    unsigned long t;
    __pv_stub(x, t, "add");
    return t;
}

static inline unsigned long __phys_to_virt(unsigned long x)
{
    unsigned long t;
    __pv_stub(x, t, "sub");
    return t;
}

The __pv_stub() would contain an assembly macro to do add or sub. Since then the LPAE support for more than 32-bit addresses made this code a great deal more complex, but the general idea is the same.

Whenever __virt_to_phys() or __phys_to_virt() is called in the kernel, it is replaced with a piece of inline assembly code from arch/arm/include/asm/memory.h, then the linker switches section to a section called .pv_table, and then adds a entry to that section with a pointer back to the assembly instruction it just added. This means that the section .pv_table will expand into a table of pointers to any instance of these assembly inlines.

During boot, we will go through this table, take each pointer, inspect each instruction it points to, patch it using the offset to the physical and virtual memory where we were actually loaded.

Patching phys to virt Each and every location with an assembly macro doing a translation from physical to virtual memory is patched in the early boot process.

Why are we doing this complex manouver instead of just storing the offset in a variable? This is for efficiency reasons: it is on the hot data path of the kernel. Calls updating page tables and cross-referencing physical to virtual kernel memory are extremely performance-critical, all use cases exercising the kernel virtual memory, whether block layer or network layer operations, or user-to-kernelspace translations, in principle any data passing through the kernel, will at some point call these functions. They must be fast.

It would be wrong to call this a simple solution to the problem. Alas it is a really complicated solution to the problem. But it works and it is very efficient!

Looping through the patch table

We perform the actual patching by figuring out the offset like illustrated above, and iteratively patching all the assembly stubs. This is done in the call to the symbol __fixup_pv_table, where our just calculated offset in r8 comes into play: a table of 5 symbols that need to refer directly to physical memory known as the __pv_table is read into registers r3..r7 augmented using the same method described above (that is why the table is preceded by a .long .):

__fixup_pv_table:
	adr	r0, 1f
	ldmia	r0, {r3-r7}
	mvn	ip, #0
	subs	r3, r0, r3	@ PHYS_OFFSET - PAGE_OFFSET
	add	r4, r4, r3	@ adjust table start address
	add	r5, r5, r3	@ adjust table end address
	add	r6, r6, r3	@ adjust __pv_phys_pfn_offset address
	add	r7, r7, r3	@ adjust __pv_offset address
	mov	r0, r8, lsr #PAGE_SHIFT	@ convert to PFN
	str	r0, [r6]	@ save computed PHYS_OFFSET to __pv_phys_pfn_offset
	(...)
	b	__fixup_a_pv_table

1:	.long	.
	.long	__pv_table_begin
	.long	__pv_table_end
2:	.long	__pv_phys_pfn_offset
	.long	__pv_offset

The code uses the first value loaded into r3 to calculate the offset to physical memory, then adds that to each of the other registers so that r4 thru r7 now point directly to the physical memory contained in each of these labels. So r4 is a pointer to the physical memory storing __pv_table_begin, r5 points to __pv_table_end, r6 point to __pv_phys_pfn_offset and r7 points to __pv_offset. In C these would be u32 *, so pointers to some 32 bit numbers.

__pv_phys_pfn_offset is especially important, this means patch physical to virtual page frame number offset, so we first calculate this by making a logical shift right with mov r0, r8, lsr #PAGE_SHIFT using the value we earlier calculated in r8 (the offset from 0 to the kernel memory in our case 0x10000000), and writing it right into whatever location actually stores that variable with str r0, [r6]. This isn't used at this early stage of the kernel start-up but it will be used by the virtual memory manager later.

Next we call __fixup_a_pv_table which will loop over the addresses from r4 thru r5 (the table of pointers to instructions to be patched) and patch each of them in order using a custom binary patcher that convert the instructions whether in ARM or THUMB2 (the instruction set is known at compile time) to one with an immediate offset between physical and virtual memory encoded right into it. The code is pretty complex and contains quirks to accommodate for big endian byte order as well.

Notice that this also has to happen every time the kernel loads a module, who knows if the new module needs to convert between physical and virtual addresses! For this reason all module ELF files will contain a .pv_table section with the same kind of table and the very same assembly loop is called also every time we load a module.

Setting Up the Initial Page Table

Before we can start to execute in this virtual memory we have just chiseled out, we need to set up a MMU translation table for mapping the physical memory to virtual memory. This is commonly known as a page table, albeit what will use for the initial map is not pages but sections. The ARM architecture mandates that this must be placed on an even 16KB boundary in physical memory. Since it is also always 16KB in size this makes sense.

The location of the initial page table is defined in a symbol named swapper_pg_dir, “swapper page directory”, which is an idiomatic name for the initial page table for the kernel. As you realize it will later on be replaced (swapped, hence “swapper”) by a more elaborate page table.

The name “page table” is a bit misleading because what the initial mapping is using in ARM terminology is actually called sections, not pages. But the term is used a bit fuzzily to refer to “that thing which translates physical addresses to virtual addresses at boot”.

The symbol swapper_pg_dir is defined to be at KERNEL_RAM_VADDR - PG_DIR_SIZE. Let’s examine each of these.

KERNEL_RAM_VADDR is just what you would suspect: the address in the virtual memory where the kernel is located. It is the address to which the kernel was linked during compile.

The KERNEL_RAM_VADDR is defined to (PAGE_OFFSET + TEXT_OFFSET). PAGE_OFFSET can be one of four locations from the Kconfig symbol we just investigated, typically 0xC0000000. The TEXT_OFFSET is typically 0x8000, so the KERNEL_RAM_VADDR will typically be 0xC0008000 but with a different virtual memory split setting or exotic TEXT_OFFSET it will be something different. TEXT_OFFSET comes from textof-y in arch/arm/Makefile and is usually 0x8000, but can also be 0x00208000 on some Qualcomm platforms and 0x00108000 again on some Broadcom platforms, making KERNEL_RAM_VADDR 0xC0208000 or similar.

What we know for sure is that this address was passed to the linker when linking the kernel: if you inspect the linker file for the ARM architecture at arch/arm/kernel/vmlinux.lds.S like we did in the beginning of the article you can see that the linker is indeed instructed to place this at . = PAGE_OFFSET + TEXT_OFFSET. The kernel has been compiled to execute at the address given in KERNEL_RAM_VADDR, even if the very earliest code, that we are analyzing right now, has been written in assembly to be position-independent.

TEXT OFFSET illustration The TEXT_OFFSET is a small, typically 32KB area above the kernel RAM in both physical and virtual memory space. The location of the kernel in the physical RAM at 0x10000000 is just an example, this can be on any even 16MB boundary.

Notice that the little gap above the kernel, most commonly at 0xC0000000-0xC0007FFF (the typical 32KB if TEXT_OFFSET). While part of the kernelspace memory this is not memory that the kernel was compiled into: it contains the initial page table, potentially ATAGs from the boot loader and some scratch area and could be used for interrupt vectors if the kernel is located at 0x00000000. The initial page table here is certainly programmed and used by the kernel, but it is abandoned afterwards.

Notice that we add the same TEXT_OFFSET to physical and virtual memory alike. This is even done in the decompression code, which will decompress the kernel first byte of the kernel to PHYS_OFFSET + TEXT_OFFSET, so the linear delta between a kernel location in physical memory and the same location in virtual memory is always expressed in a few high bits of a 32bit word, such as bits 24 thru 31 (8 bits) making it possible to use immediate arithmetic and include the offset directly in the instruction we use when facilitating ARM_PATCH_PHYS_VIRT. From this comes the restriction that kernel RAM must begin at an address evenly divisible by 16MB (0x01000000).

So we find the physical location of swapper_pg_dir in virtual memory by adding TEXT_OFFSET to PAGE_OFFSET and then backing off PG_DIR_SIZE from there. In the common case this will be 0xC0000000 + 0x8000 - 0x4000 so the initial page table will be at 0xC0004000 in virtual memory and at the corresponding offset in physical memory, in my example with PHYS_OFFSET being 0x10000000 it will be at 0x10004000.

Inital page translation table in swapper pg dir The swapper_pg_dir symbol will in our example reside 16KB (0x4000 bytes) before the .text segment in physical memory, at 0x10004000 given that our PHYS_OFFSET is 0x10000000 and TEXT_OFFSET is 0x8000 while using classic ARM MMU.

If you use LPAE the page table PG_DIR_SIZE is 0x5000 so we end up at 0xC0003000 virtual and 0x10003000 physical. The assembly macro pgtbl calculates this for us: we take the physical address we have calculated in r8, add TEXT_OFFSET and subtract PG_DIR_SIZE and we end up on the physical address for the initial translation table.

The initial page table is constructed in a very simple way: we first fill the page table with zeroes, then build the initial page table. This happens at symbol __create_page_tables.

The ARM32 Page Table Format

The page table layout on ARM32 consists of 2 or 3 levels. The 2-level page table is referred to as the short format page table and the 3-level format is called the long format page table in ARM documentation. The long format is a feature of the large physical address extension, LPAE and as the name says it is there to handle larger physical memories requiring up to 40 bits of physical address.

These translation tables can translate memory in sections of 1MB (this is 2MB on LPAE but let’s leave that aside for now) or in pages of 16kB. The initial page table uses sections, so memory translation in the initial page table is exclusively done in sections of 1MB.

This simplifies things for the initial mapping: sections can be encoded directly in the first level of the page table. This way there is in general no need to deal with the complex 2-level hierarchy, and we are essentially treating the machine as something with 1-level 1MB section tables.

However if we are running on LPAE there is another level inbetween, so we need to deal with the first two levels and not just one level. That is why you find some elaborate LPAE code here. All it does is insert a 64bit pointer to our crude 2MB-sections translation table.

Page table format In the classic MMU we just point the MMU to a 1st level table with 1MB sections while for LPAE we need an intermediate level to get to the similar format with 2MB. The entries are called section descriptors.

Linux Page Table Lingo

At this point the code starts to contain some three-letter acronyms. It is dubious whether these are actually meaningful when talking about this crude initial page table, but developers refer to these short-hands out of habit.

  • PGD page global directory is Linux lingo for the uppermost translation table, where the whole MMU traversal to resolve sections and pages start. In our case this is at 0x10004000 in physical memory. In the ARM32 world, this is also the address that we write into the special CP15 translation table register (sometimes called TTBR0) to tell the MMU where to find the translations. If we were using LPAE this would be at 0x10003000 just to make space for that 0x1000 with a single 64bit pointer to the next level called PMD.
  • P4D page 4th level directory and PUD page upper directory are concepts in the Linux VMM (virtual memory manager) unused on ARM as these deal with translation table hierarchies of 4 or 5 levels and we use only 2 or 3.
  • PMD page middle directory is the the name for 3rd level translation stage only used in LPAE. This is the reason we need to reserve another 0x1000 bytes for the LPAE initial page table. For classic ARM MMU (non-LPAE) the PMD and the PGD is the same thing. This is why the code refers to PMD_ORDER for classic MMU and LPAE alike. Because of Linux VMM terminology this is understood as the “format of the table right above the PTE:s”, and since we’re not using PTEs but section mappings, the “PMD section table” is the final product of our mappings.
  • PTE:s, page table entries maps pages of RAM from physical to virtual memory. The initial boot translation table does not use these. We use sections.

Notice again: for classic ARM MMU PGD and PMD is the same thing. For LPAE it is two different things. This is sometimes referred to as “folding” PMD into PGD. Since in a way we are “folding” P4D and PUD as well, it becomes increasingly confusing.

If you work with virtual memory you will need to repeat the above from time to time. For our purposes of constructing the initial “page” table none of this really matters. What we are constructing is a list of 1MB sections mapping virtual memory to physical memory. We are not even dealing with pages at this point, so the entire “pages” terminology is mildly confusing.

The Binary Format of the Translation Table

Let use consider only the classic ARM MMU in the following.

From physical address 0x10004000 to 0x10007FFF we have 0x1000 (4096) section descriptors of 32 bits (4 bytes) each. How are these used?

The program counter and all CPU access will be working on virtual addresses after we turn on the MMU, so the translation will work this way: a virtual address is translated into a physical address before we access the bus.

The way the physical address is determined from the virtual address is as follows:

We take bits 31..20 of the virtual address and use this as index into the translation table to look up a 32bit section descriptor.

  • Addresses 0x00000000-0x000FFFFF (the first 1MB) in virtual memory will be translated by the index at 0x10004000-0x10004003, the first four bytes of the translation table, we call this index 0.
  • Virtual address 0x00100000-0x001FFFFF will be translated by index 1 at 0x10004004-0x10004007, so index times four is the byte address of the descriptor.
  • Virtual address 0xFFF00000-0xFFFFFFFF will be translated by index 0xFFF at 0x10003FFC-0x10003FFF

Oh. Clever. 0x4000 (16KB) of memory exactly spans a 32bit i.e. 4GB memory space. So using this MMU table we can make a map of any virtual memory address 1MB chunk to any physical memory 1MB chunk. This is not a coincidence.

This means for example that for the kernel virtual base 0xC0000000 the index into the table will be 0xC0000000 >> 20 = 0xC00 and since the index need to be multiplied by 4 to get the actual byte index we get 0xC00 * 4 = 0x3000 so at physical address 0x10004000 + 0x3000 = 0x10007000 we find the section descriptor for the first 1MB of the kernelspace memory.

The 32-bit 1MB section descriptors we will use for our maps may have something like this format:

Mock section descriptor

The MMU will look at bits 1,0 and determine that “10” means that this is a section mapping. We set up some default values for the other bits. Other than that we only really care about setting bits 31..20 to the right physical address and we have a section descriptor that will work. And this is what the code does.

For LPAE this story is a bit different: we use 64bit section descriptors (8 bytes) but at the same time, the sections are bigger: 2 MB instead of 1 MB, so in the end the translation table will have exactly the same size of 0x4000 bytes.

Identity mapping around MMU enablement code

First of all we create an identity mapping around the symbol __turn_mmu_on, meaning this snippet of code will be executing in memory that is mapped 1:1 between physical and virtual addresses. If the code is at 0x10009012 then the virtual address for this code will also be at 0x10009012. If we inspect the code we see that it is put into a separate section called .idmap.text. Creating a separate section means that this gets linked into a separate physical page with nothing else in it, so we map an entire 1MB section for just this code (maybe even two, if it happens to align just across a section boundary in memory), so that an identity mapping is done for this and this code only.

If we think about it this is usually cool, even if it spans say 2MB of memory: if we loaded the kernel at 0x10000000 as in our example, this code will be at something like 0x10000120 with an identity mapping at the same address this isn’t ever going to disturb the kernel at 0xC0000000 or even at 0x40000000 which is an extreme case of kernel memory split. If someone would start to place the start of physical memory at say 0xE0000000 we would be in serious trouble. Let’s pray that this never happens.

Mapping the rest

Next we create the physical-to virtual memory mapping for the main matter, starting at PHYS_OFFSET in the physical memory (the value we calculated in r8 in the section “Where Are We Executing”) and PAGE_OFFSET (a compile-time constant) in the virtual memory, then we move along one page at the time all the way until we reach the symbol _end in virtual memory which is set to the end of the .bss section of the kernel object itself.

Initial virtual memory mapping The initial page table swapper_pg_dir and the 1:1 mapped one-page-section __turn_mmu_on alongside the physical to virtual memory mapping at early boot. In this example we are not using LPAE so the initial page table is -0x4000 from PHYS_OFFSET and memory ends at 0xFFFFFFFF.

BSS is an idiomatic name for the section at the very end of the binary kernel footprint in memory and this is where the C compiler assigns locations for all runtime variables. The addresses for this section are well defined, but there is no binary data for them: this memory has undefined contents, i.e. whatever was in it when we mapped it in.

It is worth studying this loop of assembly in detail to understand how the mapping code works:

    ldr    r7, [r10, #PROCINFO_MM_MMUFLAGS] @ mm_mmuflags
    (...)
    add    r0, r4, #PAGE_OFFSET >> (SECTION_SHIFT - PMD_ORDER)
    ldr    r6, =(_end - 1)
    orr    r3, r8, r7
    add    r6, r4, r6, lsr #(SECTION_SHIFT - PMD_ORDER)
1:  str    r3, [r0], #1 << PMD_ORDER
    add    r3, r3, #1 << SECTION_SHIFT
    cmp    r0, r6
    bls    1b

Let us take this step by step. We assume that we use non-LPAE classic ARM MMU in this example (you can convince yourself that the same holds for LPAE).

add    r0, r4, #PAGE_OFFSET >> (SECTION_SHIFT - PMD_ORDER)

r4 contains the physical address of the page table (PGD or PMD) where we will set up our sections. (SECTION_SHIFT - PMD_ORDER) resolves to (20 – 2) = 18, so we take PAGE_OFFSET 0xC0000000 >> 18 = 0x3000 which is incidentally the absolute index into the translation table for 0xC0000000 as we saw earlier: aha. Well that makes sense since the index is 4 bytes. So whenever we see (SECTION_SHIFT - PMD_ORDER) that means “convert to absolute physical index into the translation table for this virtual address”, in our example case this will be 0x10003000.

So the first statement generates the physical address for the first 32bit section descriptor for the kernelspace memory in r0.

ldr    r6, =(_end - 1)

r6 is obviously set to the very end of the kernelspace memory.

    ldr    r7, [r10, #PROCINFO_MM_MMUFLAGS] @ mm_mmuflags
    (...)
    orr    r3, r8, r7

r8 contains the PHYS_OFFSET, in our case 0x10000000 (we count on bits 19..0 to be zero) and we OR that with r7 which represents what is jokingly indicated as “who cares” in the illustration above, is a per-CPU setting for the MMU flags defined for each CPU in arch/arm/mm/proc-*.S. Each of these files contain a special section named .proc.info.init and at index PROCINFO_MM_MMUFLAGS (which will be something like 0x08) there is the right value to OR into the section descriptor for the specific CPU we are using. The struct itself is named struct proc_info_list and can be found in arch/arm/include/asm/procinfo.h. Since assembly cannot really handle C structs some indexing trickery is used to get at this magic number.

So the section descriptor has a physical address in bits 31-20 and this value in r7 sets some more bits, like the two lowest, so that the MMU can handle this section descriptor right.

add    r6, r4, r6, lsr #(SECTION_SHIFT - PMD_ORDER)

This will construct the absolute physical index address for the section descriptor for the last megabyte of memory that we map. We are not OR:in on the value from r7: we till just use this for a loop comparison, not really write it into the translation table, so it is not needed.

So now r0 is the physical address of the first section descriptor we are setting up and r6 is the physical address of the last section descriptor we will set up. We enter the loop:

1:  str    r3, [r0], #1 << PMD_ORDER
    add    r3, r3, #1 << SECTION_SHIFT
    cmp    r0, r6
    bls    1b

This writes the first section descriptor into the MMU table, to the address in r0 which will start at 0x10003000 in our example. Then we post-increment the address in r0 with (1 << PMD_ORDER) which will be 4. Then we increase the descriptor physical address portion (bit 20 and upward) with 1 MB (1 << SECTION_SHIFT), check we we reached the last descriptor else loop to 1:.

This creates a virtual-to-physical map of the entire kernel including all segments and .bss in 1MB chunks.

Final mappings

Next we map some other things: we map the boot parameters specifically: this can be ATAGs or an appended device tree blob (DTB). ATAGs are usually the very first page of memory (at PHYS_OFFSET + 0x0100) While contemporary DTBs are usually somewhere below the kernel. You will notice that it would probably be unwise to place the DTB too far above the kernel, lest it will wrap around to lower addresses.

If we are debugging we also map the serial port specifically from/to predefined addresses in physical and virtual memory. This is done so that debugging can go on as we execute in virtual memory.

There is again an exception for “execute in place”: if we are executing from ROM we surely need to map the kernel from that specific address rather than the compile-time memory locations.

Jump to Virtual Memory

We are nearing the end of the procedure stext where we started executing the kernel.

First we call the per-cpu-type “procinit” function. This is some C/assembly clever low-level CPU management code that is collected per-CPU in arch/arm/mm/proc-*.S. For example most v7 CPUs have the initialization code in proc-v7.S and the ARM920 has its initialization code in proc-arm920.S. This will be useful later, but the “procinit” call is usually empty: only XScale really does anything here an it is about bugs pertaining to the boot loader initial state.

The way the procinit code returns is by the conventional ret lr which actually means that the value of the link register (lr) is assigned to the program counter (pc).

Before entering the procinit function we set lr to the physical address of label 1: which will make a relative branch to the symbol __enable_mmu. We also assign r13 the address of __mmap_switched, which is the compiletime-assigned, non-relative virtual address of the next execution point after the MMU has been enabled. We are nearing the end of relative code constructions.

We jump to __enable_mmu. r4 contains the address of the initial page table. We load this using a special CP15 instruction designed to load the page table pointer (in physical memory) into the MMU:

mcr    p15, 0, r4, c2, c0, 0

Nothing happens so far. The page table address is set up in the MMU but it is not yet translating between physical and virtual addresses. Next we jump to __turn_mmu_on. This is where the magic happens. __turn_mmu_on as we said is cleverly compiled into the section .idmap.text which means it has the same address in physical and virtual memory. Next we enable the MMU:

    mcr    p15, 0, r0, c1, c0, 0        @ write control reg
    mrc    p15, 0, r3, c0, c0, 0        @ read id reg

BAM! The MMU is on. The next instruction (which is incidentally an instruction cache flush) will be executed from virtual memory. We don’t notice anything at first, but we are executing in virtual memory. When we return by jumping to the address passed in r13, we enter __mmap_switched at the virtual memory address of this function, somewhere below PAGE_OFFSET (typically 0xC0nnnnnn). We can now facilitate absolute addressing: the kernel is executing as intended.

Executing in virtual memory The little “dance” of the program counter as we switch execution from physical to virtual memory.

We have successfully bootstrapped the initial page table and we are now finally executing the kernel at the location the C compiler thought the kernel was going to execute at.

Now Let’s Get Serious

__mmap_switched can be found in the file arch/arm/kernel/head-common.S and will do a few specific things before we call the C runtime-enabled kernel proper.

First there is an exceptional clause, again for execute-in-place (XIP) kernels: while the .text segment of the kernel can certainly continue executing from ROM we cannot store any kind of variables from the .data segment there. So first this is set up by either just copying the segment to RAM or, using some fancy extra code, uncompressed to RAM (saving more silicon memory).

Next we zero out the .bss segment we got to know earlier: in the Linux kernel we rely on static variables being initialized to zero. Other C runtime environments may not do this, but when you run the Linux kernel you can rely on static variables being zero the first time you enter a function.

The machine has now switched to virtual memory and fully prepared the C runtime environment. We have also patched all cross-references between physical and virtual memory. We are ready to go.

So next we save the processor ID, machine type and ATAG or DTB pointer and branch to the symbol start_kernel(). This symbol resolves to an absolute address and is a C function found a bit down in the init/main.c file. It is fully generic: it is the same point that all other Linux architectures call, so we have now reached the level of generic kernel code written in C.

Let’s see where this is: to disassemble the kernel I just use the objdump tool from the toolchain and pipe it to less:

arm-linux-gnueabihf-objdump -D vmlinux |less

By searching for start_kernel by /start_kernel in less and skipping to the second hit we find:

c088c9d8 <start_kernel>:
c088c9d8:       e92d4ff0        push    {r4, r5, r6, r7, r8, r9, sl, fp, lr}
c088c9dc:       e59f53e8        ldr     r5, [pc, #1000] ; c088cdcc
c088c9e0:       e59f03e8        ldr     r0, [pc, #1000] ; c088cdd0
c088c9e4:       e5953000        ldr     r3, [r5]
c088c9e8:       e24dd024        sub     sp, sp, #36     ; 0x24
c088c9ec:       e58d301c        str     r3, [sp, #28]
c088c9f0:       ebde25e8        bl      c0016198 <set_task_stack_end_magic>

Oh this is nice! We are executing C at address 0xC088C9D8, and we can now disassemble and debug the kernel as we like. When I have random crash dumps of the kernel I usually use exactly this method of combining objdump and less to disassemble the kernel and just search for the symbol that crashed me to figure out what is going on.

Another common trick among kernel developers is to enable low-level kernel debugging and putting a print at start_kernel() so that we know that we reach this point. My own favourite construction looks like this (I just insert these lines first in start_kernel()):

#if defined(CONFIG_ARM) && defined(CONFIG_DEBUG_LL)
{
    extern void printascii(char *);
    printascii("start_kernel\n");
}
#endif

As can be seen, getting low-level debug prints like this to work involves enabling CONFIG_DEBUG_LL, and then you should be able to see a life sign from the kernel before even the kernel banner is “Linux …” is printed.

This file and function should be well known to Linux kernel developers and a good thing to do on a boring day is to read through the code in this file, as this is how the generic parts of Linux bootstrap themselves.

The happiness of generic code will not last as we soon call setup_arch() and we are then back down in arch/arm again. We know for sure that our crude initial translation table will be replaced by a more elaborate proper translation table. There is not yet any such thing as a virtual-to-physical mapping of the userspace memory for example. But this is the topic of another discussion.


Read more...

from David Ahern

Long overdue blog post on XDP; so many details uncovered during testing causing tests to be redone.

This post focuses on a comparison of XDP and OVS in delivering packets to a VM from the perspective of CPU cycles spent by the host in processing those packets. There are a lot of variables at play, and changing any one of them radically affects the outcome, though it should be no surprise XDP is always lighter and faster.

Setup

I believe I am covering all of the settings here that I discovered over the past few months that caused variations in the data.

Host

The host is a standard, modern server (Dell PowerEdge R640) with an Intel® Xeon® Platinum 8168 CPU @ 2.70GHz with 96 hardware threads (48 cores + hyper threading to yield 96 logical cpus in the host). The server is running Ubuntu 18.04 with the recently released 5.8.0 kernel. It has a Mellanox Connectx4-LX ethernet card with 2 25G ports into an 802.3ad (LACP) bond, and the bond is connected to an OVS bridge.

Host setup

As discussed in [1] to properly compare the CPU costs of the 2 networking solutions, we need to consolidate packet processing to a single CPU. Handling all packets destined to the same VM on the same CPU avoids lock contention on the tun ring, so consolidating packets to a single CPU is actually best case performance.

Ensure RPS is disabled in the host:

for d in eth0 eth1; do
    find /sys/class/net/${d}/queues -name rps_cpus |
    while read f; do
            echo 0 | sudo tee ${f}
    done
done

and add flow rules in the NIC to push packets for the VM under test to a single CPU:

sudo ethtool -N eth0 flow-type ether dst 12:34:de:ad:ca:fe action 2
sudo ethtool -N eth1 flow-type ether dst 12:34:de:ad:ca:fe action 2

For this host and ethernet card, packets for queue 2 are handled on CPU 5 (consult /proc/interrupts for the mapping on your host).

XDP bypasses the qdisc layer, so to have a fair comparison make noqueue the default qdisc before starting the VM:

sudo sysctl -w net.core.default_qdisc=noqueue

(or add a udev rule [2]).

Finally, the host is fairly quiet with only one VM running (the one under test) and very little network traffic outside of the VM under test and a few, low traffic ssh sessions used to run commands to collect data about the tests.

Virtual Machine

The VM has 8 cpus and is also running Ubuntu 18.04 with a 5.8.0 kernel. It uses tap+vhost for networking with the tap device a port in the OVS bridge as shown in the picture above. The tap device has a single queue, and RPS is also disabled in the guest:

echo 00 | see tee /sys/class/net/eth0/queues -name rps_cpus

The VM is also quiet with no load running in the guest OS.

The point of this comparison is host side processing of packets, so packets are dropped in the guest as soon as possible using a bpf program [3] attached to eth0 as a tc filter. (Note: Theoretically, XDP should be used to drop the packets in the guest OS since it truly is the fewest cycles per packet. However, XDP in the VM requires a multi-queue NIC[5], and adding queues to the guest NIC has a huge affect on the results.)

In the host, the qemu threads corresponding to the guest CPUs (vcpus) are affined (as a set) to 8 hardware threads in the same NUMA node as CPU 5 (the host CPU processing packets per the RSS rules mentioned earlier). The vhost thread for the VM's tap device is also affined to a small set of host CPUs in the same NUMA node to avoid scheduling collisions with the vcpu threads, the CPU processing packets (5) and its sibling hardware thread (CPU 53 in my case) – all of which add variability to the results.

Forwarding with XDP

Packet forwarding with XDP is done by attaching an L2 forwarding program [4] to eth0 and eth1. The program pulls the VLAN and destination mac from the ethernet header, and uses the pair as a key for a lookup in a hash map. The lookup returns the next device index for the packet which for packets destined to the VM is the index of its tap device. If an entry is found, the packet is redirected to the device via XDP_REDIRECT. The use case was presented in depth at netdevconf 0x14 [5].

Packet generator

Packets are generated using 2 VMs on a server that is directly connected to the same TOR switches as the hypervisor running the VM under test. The point of the investigation is to measure the overhead of delivering packets to a VM, so memcpy is kept to a minimum by having the packet generator [6] in the VMs send 1-byte UDP packets.

Test setup

Each VM can generate a little over 1 million packets per sec (1M pps), for a maximum load of 2.2M pps based on 2 separate source addresses.

CPU Measurement

As discussed in [1] a fair number of packets are processed in the context of some interrupted, victim process or when handled on an idle CPU the cycles are not fully accounted in the softirq time shown in tools like mpstat.

This test binds openssl speed, a purely userspace command[1], to the CPU handling packets to fully consume 100% of all CPU cycles which makes the division of CPU time between user, system and softirq more transparent. In this case, the output of mpstat -P 5 shows how all of the cycles for CPU 5 were spent (within the resolution of system accounting): * %softirq is the time spent handling packets. This data is shown in the graphs below. * %usr represents the usable CPU time for processes to make progress on their workload. In this test, it shows the percentage of CPU consumed by openssl and compares to the times shown by openssl within 1-2%. * %sys is the percentage of kernel time and for the data shown below was always <0.2%.

As an example, in this mpstat output openssl is only getting 14.2% of the CPU while 85.8% was spent handling the packet load:

CPU    %usr   %nice    %sys  %iowait   %irq   %soft   %idle
  5   14.20    0.00    0.00     0.00   0.00   85.80   0.00

(%steal, %guest and %gnice dropped were always 0 and dropped for conciseness.)

Let's get to the data.

CPU Comparison

This chart shows a comparison of the %softirq required to handle various PPS rates for both OVS and XDP. Lower numbers are better (higher percentages mean more CPU cycles).

1-VM softirq

There is 1-2% variability in ksoftirqd percentages despite the 5-second averaging, but the variability does not really affect the important points of this comparison.

The results should not be that surprising. OVS has well established scaling problems and the chart shows that as packet rates increase. In my tests it was not hard to saturate a CPU with OVS, reaching a maximum packet rate to the VM of 1.2M pps. The 100% softirq at 1.5M pps and up is saturation of ksoftirqd alone with nothing else running on that CPU. Running another process on CPU 5 immediately affects the throughput rate as the CPU splits time between processing packets and running that process. With openssl, the packet rate to the VM is cut in half with packet drops at the host ingress as it can no longer keep up with the packet rate given the overhead of OVS.

XDP on the other hand could push 2M pps to the VM before the guest could no longer keep up with packet drops at the tap device (ie., no room in the tun ring meaning the guest has not processed the previous packets). As shown above, the host still has plenty of CPU to handle more packets or run workloads (preferred condition for a cloud host).

One thing to notice about the chart above is the apparent flat lining of CPU usage between 50k pps and 500k pps. That is not a typo, and the results are very repeatable. This needs more investigation, but I believe it shows the efficiencies kicking in from a combination of more packets getting handled per napi poll cycle (closer to maximum of the netdev budget) and the kernel side bulking in XDP before a flush is required.

Hosts typically run more than 1 VM, so let's see the effect of adding a second VM to the mix. For this case a second VM is started with the same setup as mentioned earlier, but now the traffic load is split equally between 2 VMs. The key point here is a single CPU processing interleaved network traffic for 2 different destinations.

2-VM softirq

For OVS, CPU saturation with ksoftirqd happens with a maximum packet rate to each VM of 800k pps (compared to 1.2M with only a single VM). The saturation is in the host with packet drops shown at host ingress, and again any competition for the CPU processing packets cuts the rate in half.

Meanwhile, XDP is barely affected by the second VM with a modest increase of 3-4% in softirq at the upper packet rates. In this case, the redirected packets are just hitting separate bulking queues in the kernel. The two packet generators are not able to hit 4+M pps to find the maximum per-VM rate.

Final Thoughts

CPU cycles are only the beginning for comparing network solutions. A full OVS-vs-XDP comparison needs to consider all the resources consumed – e.g., memory as well as CPU. For example, OVS has ovs-vswitchd which consumes a high amount of memory (>750MB RSS on this server with only the 2 VMs) and additional CPU cycles to handle upcalls (flow misses) and revalidate flow entries in the kernel which on an active hypervisor can easily consume 50+% cpu (not counting increased usage from various bugs[7]).

Meanwhile, XDP is still early in its lifecycle. Right now, using XDP for this setup requires VLAN acceleration in the NIC [5] to be disabled meaning the VLAN header has to be removed by the ebpf program before forwarding to the VM. Using the proposed hardware hints solution reduces the softirq time by another 1-2% meaning 1-2% more usable CPU by leveraging hardware acceleration with XDP. This is just an example of how XDP will continue to get faster as it works better with hardware offloads.

Acronyms

LACP Link Aggregation Control Protocol NIC Nework Interface Card NUMA Non-Uniform Memory Access OVS Open VSwitch PPS Packets per Second RPS Receive Packet Steering RSS Receive Side Scaling TOR Top-of-Rack VM Virtual Machine XDP Express Data Path in Linux

References

[1] https://people.kernel.org/dsahern/the-cpu-cost-of-networking-on-a-host [2] https://people.kernel.org/dsahern/rss-rps-locking-qdisc [3] https://github.com/dsahern/bpf-progs/blob/master/ksrc/rx_acl.c [4] https://github.com/dsahern/bpf-progs/blob/master/ksrc/xdp_l2fwd.c [5] https://netdevconf.info/0x14/session.html?tutorial-XDP-and-the-cloud [6] https://github.com/dsahern/random-cmds/blob/master/src/pktgen.c [7] https://www.mail-archive.com/ovs-dev@openvswitch.org/msg39266.html


Read more...

from Jakub Kicinski

All modern NICs implement IRQ coalescing (ethtool -c/-C), which delays RX/TX interrupts hoping more frames arrive in the meantime to allow for batch processing. IRQ coalescing trades off latency for system throughput.

It’s commonly believed that the higher the packet rate, the more batching system needs to keep up. At lower rates the batching would be limited, anyway. This leads to the idea of adaptive IRQ coalescing where the NIC itself – or more likely the driver – adjusts the IRQ timeouts based on the recent rate of packet arrivals.

Unfortunately adaptive coalescing is not a panacea, as it often has predefined range of values it chooses from, and it costs extra CPU processing to continuously recalculate and update the rate (especially with modern NICs which often need to talk to firmware to change settings rather than simply writing to device registers).

The summary above – while correct (I hope :)) misses one important point. There are two sets of IRQ coalescing settings, and only one of them has a significant latency impact. NICs (and the Linux kernel ethtool API) have separate settings for RX and TX. While RX processing is more costly, and therefore playing with RX settings feels more significant – RX batching costs latency. For TX processing (or actually TX completion processing) the latency matters much, much less.

With a simple bpftrace command:

bpftrace -e 'tracepoint:napi:napi_poll { @[args->work] = count(); }'

we can check how many RX packets get received on every NAPI poll (that’s to say how many packets get coalesced). On a moderately loaded system the top entries may look something like:

@[4]: 750
@[3]: 2180
@[2]: 15828
@[1]: 233080
@[0]: 298525

where the first number (in square brackets) is the number of packets coalesced, and the second number is a counter of occurrences.

The 0 work done entries (@[0]: 298525) usually mean that the driver received a TX interrupt, and there were no RX packets to process. Drivers will generally clear their TX rings while doing RX processing – so with TX processing being less latency sensitive – in an ideal scenario we’d like to see no TX interrupts at all, but rather have TX processing piggy back on the RX interrupts.

How high can we set the TX coalescing parameters, then? If the workload is mostly using TCP all we really need to ensure is that we don’t run awry of TCP Small Queues (/proc/sys/net/ipv4/tcp_limit_output_bytes) which is the number of bytes TCP stack is willing to queue up to the NIC without getting a TX completion.

For example recent upstream kernels have TSQ of 1MB, so even with a 50GB NIC – delaying TX interrupts for up to 350us should be fine. Obviously we want to give ourselves a safety margin for scheduling delays, timer slack etc. Additionally, according to my experiments the gains of TX coalescing above 200us are perhaps too low for the risk.

Repeating the bpftrace command from above after setting coalescing to 150us / 128 frames:

@[4]: 831
@[3]: 2066
@[2]: 16056
@[0]: 177186
@[1]: 228985

We see far less @[0] occurrences compared to the first run. The gain in system throughput depends on the workload, I’ve seen an increase of 6% on the workload I tested with.

A word of warning – even though upstream reviewers try to make sure drivers behave sanely and return errors for unsupported configurations – there are vendors out there who will silently ignore TX coalescing settings...


Read more...

from linusw

ARM traditionally uses compressed kernels. This is done for two major reasons:

  • It saves space on the flash memory or other storage media holding the kernel, and memory is money. For example for the Gemini platform that I work on, the vmlinux uncompressed kernel is 11.8 MB while the compressed zImage is a mere 4.8 MB, we save more than 50%
  • It is faster to load because the time it takes for the decompression to run is shorter than the time that it takes to transfer an uncompressed image from the storage media, such as flash. For NAND flash controllers this can easily be the case.

This is intended as a comprehensive rundown of how the Linux kernel self-decompresses on ARM 32-bit legacy systems. All machines under arch/arm/* uses this method if they are booted using a compressed kernel, and most of them are using compressed kernels.

Bootloader

The bootloader, whether RedBoot, U-Boot or EFI places the kernel image somewhere in physical memory and executes it passing some parameters in the lower registers.

Russell King defined the ABI for booting the Linux kernel from a bootloader in 2002 in the Booting ARM Linux document. The boot loader puts 0 into register r0, an architecture ID into register r1 and a pointer to the ATAGs in register r2. The ATAGs would contain the location and size of the physical memory. The kernel would be placed somewhere in this memory. It can be executed from any address as long as the decompressed kernel fits. The boot loader then jumps to the kernel in supervisor mode, with all interrupts, MMUs and caches disabled.

On contemporary device tree kernels, r2 is repurposed as a pointer to the device tree blob (DTB) in physical memory. (In this case r1 is ignored.) A DTB can also be appended to the kernel image, and optionally amended using the ATAGs from r2. We will discuss this more below.

Decompression of the zImage

If the kernel is compressed, execution begins in arch/arm/boot/compressed/head.S in the symbol start: a little bit down the file. (This is not immediately evident.) It begins with 8 or 7 NOP instructions for legacy reasons. It jumps over some magic numbers and saves the pointer to the ATAGs. So now the kernel decompression code is executing from the physical address of the physical memory where it was loaded.

The decompression code then locates the start of physical memory. On most modern platforms this is done with the Kconfig-selected code AUTO_ZRELADDR, which means a logical AND between the program counter and 0xf8000000. This means that the kernel readily assumes that it has been loaded and executed in the first part of the first block of physical memory.

There are patches being made that would instead attempt to get this information from the device tree.

Then the TEXT_OFFSET is added to the pointer to the start of physical memory. As the name says, this is where the kernel .text segment (as output from the compiler) should be located. The .text segment contains the executable code so this is the actual starting address of the kernel after decompression. The TEXT_OFFSET is usually 0x8000 so the kernel will be located 0x8000 bytes into the physical memory. This is defined in arch/arm/Makefile.

The 0x8000 (32KB) offset is a convention, because usually there is some immobile architecture-specific data placed at 0x00000000 such as interrupt vectors, and many elder systems place the ATAGs at 0x00000100. There also must be some space, because when the kernel finally boots, it will subtract 0x4000 (or 0x5000 for LPAE) from this address and store the initial kernel page table there.

For some specific platforms the TEXT_OFFSET will be pushed downwards in memory, notably some Qualcomm platforms will push it to 0x00208000 because the first 0x00200000 (2 MB) of the physical memory is used for shared memory communication with the modem CPU.

Next the decompression code sets up a page table, if it is possible to fit one over the whole uncompressed+compressed kernel image. The page table is not for virtual memory, but for enabling cache, which is then turned on. The decompression will for natural reasons be much faster if we can use cache.

Next the kernel sets up a local stack pointer and malloc() area so we can handle subroutine calls and small memory allocation going forward, executing code written in C. This is set to point right after the end of the kernel image.

Memory set-up Compressed kernel in memory with an attached DTB.

Next we check for an appended DTB blob enabled by the ARM_APPENDED_DTB symbol. This is a DTB that is added to the zImage during build, often with the simple cat foo.dtb >> zImage. The DTB is identified using a magic number, 0xD00DFEED.

If an appended DTB is found, and CONFIG_ARM_ATAG_DTB_COMPAT is set, we first expand the DTB by 50% and call atagstofdt that will augment the DTB with information from the ATAGs, such as memory blocks and sizes.

Next. the DTB pointer (what was passed in as r2 in the beginning) is overwritten with a pointer to the appended DTB, we also save the size of the DTB, and set the end of the kernel image after the DTB so the appended DTB (optionally modified with the ATAGs) is included in the total size of the compressed kernel. If an appended DTB was found, we also bump the stack and the malloc() location so we don’t destroy the DTB.

Notice: if a device tree pointer was passed in in r2, and an appended DTB was also supplied, the appended DTB “wins” and is what the system will use. This can sometimes be used to override a default DTB passed by a boot loader.

Notice: if ATAGs were passed in in r2, there certainly was no DTB passed in through that register. You almost always want the CONFIG_ARM_ATAG_DTB_COMPAT symbol if you use an elder boot loader that you do not want to replace, as the ATAGs properly defines the memory on elder platforms. It is possible to define the memory in the device tree, but more often than not, people skip this and rely on the boot loader to provide this, one way (the bootloader alters the DTB) or another (the ATAGs augment the appended DTB at boot).

Memory overlap The decompressed kernel may overlap the compressed kernel.

Next we check if we would overwrite the compressed kernel with the uncompressed kernel. That would be unfortunate. If this would happen, we check where in the memory the uncompressed kernel would end, and then we copy ourselves (the compressed kernel) past that location.

Then the code simply does a trick to jump back to the relocated address of a label called restart: which is the start of the code to set up the stack pointer and malloc() area, but now executing at the new physical address.

This means it will again set up the stack and malloc() area and look for the appended DTB and everything will look like the kernel was loaded in this location to begin with. (With one difference though: we have already augmented the DTB with ATAGs, so that will not be done again.) This time the uncompressed kernel will not overwrite the compressed kernel.

Moving the compressed kernel We move the compressed kernel down so the decompressed kernel can fit.

There is no check for if the memory runs out, i.e. if we would happen to copy the kernel beyond the end of the physical memory. If this happens, the result is unpredictable. This can happen if the memory is 8MB or less, in these situations: do not use compressed kernels.

Moving the compressed kernel below the decompressed kernel The compressed kernel is moved below the decompressed kernel.

Now we know that the kernel can be decompressed into a memory that is below the compressed image and that they will not collide during decompression and we execute at the label wont_overwrite:.

We check if we are executing on the address the decompressor was linked to, and possibly alter some pointer tables. This is for the C runtime environment executing the decompressor.

We make sure that the caches are turned on. (There is not certainly space for a page table.)

We clear the BSS area (so all uninitialized variables will be 0), also for the C runtime environment.

Next we call the decompress_kernel() symbol in boot/compressed/misc.c which in turn calls do_decompress() which calls __decompress() which will perform the actual decompression.

This is implemented in C and the type of decompression is different depending on Kconfig options: the same decompressor as the compression selected when building the kernel will be linked into the image and executed from physical memory. All architectures share the same decompression library. The __decompress() function called will depend on which of the decompressors in lib/decompress_*.c that was linked into the image. The selection of decompressor happens in arch/arm/boot/compressed/decompress.c by simply including the whole decompressor into the file.

All the variables the decompressor needs about the location of the compressed kernel are set up in the registers before calling the decompressor.

After decompression After decompression, the decompressed kernel is at TEXT_OFFSET and the appended DTB (if any) remains where the compressed kernel was.

After the decompression, we call get_inflated_image_size() to get the size of the final, decompressed kernel. We then flush and turn off the caches again.

We then jump to the symbol __enter_kernel which sets r0, r1 and r2 as the boot loader would have left them, unless we have an attached device tree blob, in which case r2 now points to that DTB. We then set the program counter to the start of the kernel, which will be the start of physical memory plus TEXT_OFFSET, typically 0x00008000 on a very conventional system, maybe 0x20008000 on some Qualcomm systems.

We are now at the same point as if we had loaded an uncompressed kernel, the vmlinux file, into memory at TEXT_OFFSET, passing (typically) a device tree in r2.

Kernel startup: executing vmlinux

The uncompressed kernel begins executing at the symbol stext(), start of text segment. This code can be found in arch/arm/kernel/head.S.

This is a subject of another discussion. However notice that the code here does not look for an appended device tree! If an appended device tree should be used, you must use a compressed kernel. The same goes for augmenting any device tree with ATAGs. That must also use a compressed kernel image, for the code to do this is part of the assembly that bootstraps a compressed kernel.

Looking closer at a kernel uncompress

Let us look closer at a Qualcomm APQ8060 decompression.

First you need to enable CONFIG_DEBUG_LL, which enables you to hammer out characters on the UART console without any intervention of any higher printing mechanisms. All it does is to provide a physical address to the UART and routines to poll for pushing out characters. It sets up DEBUG_UART_PHYS so that the kernel knows where the physical UART I/O area is located. Make sure these definitions are correct.

First enable a Kconfig option called CONFIG_DEBUG_UNCOMPRESS. All this does is to print the short message “Uncompressing Linux…” before decompressing the kernel and , “done, booting the kernel” after the decompression. It is a nice smoke test to show that the CONFIG_DEBUG_LL is set up and DEBUG_UART_PHYS is correct and decompression is working but not much more. This does not provide any low-level debug.

The actual kernel decompression can be debugged and inspected by enabling the DEBUG define in arch/arm/boot/compressed/head.S, this is easiest done by tagging on -DDEBUG to the AFLAGS (assembler flags) for head.S in the arch/arm/boot/compressed/Makefile like this:

AFLAGS_head.o += -DTEXT_OFFSET=$(TEXT_OFFSET) -DDEBUG

We then get this message when booting:

C:0x403080C0-0x40DF0CC0->0x41801D00-0x422EA900

This means that as we were booting I loaded the kernel to 0x40300000 which would collide with the uncompressed kernel. Therefore the kernel was copied to 0x41801D00 which is where the uncompressed kernel will end. Adding some further debug prints we can see that an appended DTB is first found at 0x40DEBA68 and after moving the kernel down it is found at 0x422E56A8, which is where it remains when the kernel is booted.


Read more...

from Christian Brauner

In my last article I looked at the seccomp notifier in detail and how it allows us to make unprivileged containers way more capable (Sorry, kernel joke.). This is the (very) crazy (but very short) sequel. (Sorry Jon, no novella this time. :))

Last time I mentioned two new features that we had landed:

  1. Retrieving file descriptors from another task via pidfd_getfd()
  2. Injection file descriptors via the new SECCOMP_IOCTL_NOTIF_ADDFD ioctl on the seccomp notifier

The 2. feature just landed in the merge window for v5.9. So what better time than now to boot a v5.9 pre-rc1 kernel and play with the new features.

I said that these features make it possible to intercept syscalls that return file descriptors or that pass file descriptors to the kernel. Syscalls that come to mind are open(), connect(), dup2(), but also bpf(). People that read the first blogpost might not have realized how crazy^serious one can get with these two new features so I thought it be a good exercise to illustrate it. And what better victim than bpf().

As we know, bpf() and unprivileged containers don't get along too well. But that doesn't need to be the case. For the demo you're about to see I enabled LXD to supervise the bpf() syscalls for tasks running in unprivileged containers. We will intercept the bpf() syscalls for the BPF_PROG_LOAD command for BPF_PROG_TYPE_CGROUP_DEVICE program types and the BPF_PROG_ATTACH, and BPF_PROG_DETACH commands for the BPF_CGROUP_DEVICE attach type. This allows a nested unprivileged container to load its own device profile in the cgroup2 hierarchy.

This is just a tiny glimpse into how this can be used and extended. ;) The pull request for LXD is already up here. Let's see if the rest of the team thinks I'm going crazy. :)

asciicast


Read more...

from David Ahern

I recently learned this fun fact: With RSS or RPS enabled [1] and a lock-based qdisc on a VM's tap device (e.g., fq_codel) a UDP packet storm targeted at the VM can severely impact the entire server.

The point of RSS/RPS is to distribute the packet processing load across all hardware threads (CPUs) in a server / host. However, when those packets are forwarded to a single device that has a lock-based qdisc (e.g., virtual machines and a tap device or a container and veth based device) that distributed processing causes heavy spinlock contention resulting in ksoftirqd spinning on all CPUs trying to handle the packet load.

As an example, my server has 96 cpus and 1 million udp packets per second targeted at the VM is enough to push all of the ksoftirqd threads to near 100%:

  PID %CPU COMMAND               P
   58 99.9 ksoftirqd/9           9
  128 99.9 ksoftirqd/23         23
  218 99.9 ksoftirqd/41         41
  278 99.9 ksoftirqd/53         53
  318 99.9 ksoftirqd/61         61
  328 99.9 ksoftirqd/63         63
  358 99.9 ksoftirqd/69         69
  388 99.9 ksoftirqd/75         75
  408 99.9 ksoftirqd/79         79
  438 99.9 ksoftirqd/85         85
 7411 99.9 CPU 7/KVM            64
   28 99.9 ksoftirqd/3           3
   38 99.9 ksoftirqd/5           5
   48 99.9 ksoftirqd/7           7
   68 99.9 ksoftirqd/11         11
   78 99.9 ksoftirqd/13         13
   88 99.9 ksoftirqd/15         15
   ...

perf top shows the spinlock contention:

    96.79%  [kernel]          [k] queued_spin_lock_slowpath
     0.40%  [kernel]          [k] _raw_spin_lock
     0.23%  [kernel]          [k] __netif_receive_skb_core
     0.23%  [kernel]          [k] __dev_queue_xmit
     0.20%  [kernel]          [k] __qdisc_run

With the callchain leading to

    94.25%  [kernel.vmlinux]    [k] queued_spin_lock_slowpath
            |
             --94.25%--queued_spin_lock_slowpath
                       |
                        --93.83%--__dev_queue_xmit
                                  do_execute_actions
                                  ovs_execute_actions
                                  ovs_dp_process_packet
                                  ovs_vport_receive

A little code analysis shows this is the qdisc lock in __dev_xmit_skb.

The overloaded ksoftirqd threads means it takes longer to process packets resulting in budget limits getting hit and packet drops at ingress. The packet drops can cause ssh sessions to stall or drop or cause disruptions in protocols like LACP.

Changing the qdisc on the device to a lockless one (e.g., noqueue) dramatically lowers the ksoftirqd load. perf top still shows the hot spot as a spinlock:

    25.62%  [kernel]          [k] queued_spin_lock_slowpath
     6.87%  [kernel]          [k] tasklet_action_common.isra.21
     3.28%  [kernel]          [k] _raw_spin_lock
     3.15%  [kernel]          [k] tun_net_xmit

but this time it is the lock for the tun ring:

    25.10%  [kernel.vmlinux]    [k] queued_spin_lock_slowpath
            |
             --25.05%--queued_spin_lock_slowpath
                       |
                        --24.93%--tun_net_xmit
                                  dev_hard_start_xmit
                                  __dev_queue_xmit
                                  do_execute_actions
                                  ovs_execute_actions
                                  ovs_dp_process_packet
                                  ovs_vport_receive

which is a much lighter lock in the sense of the amount of work done with the lock held.

systemd commit e6c253e363dee, released in systemd 217, changed the default qdisc from pfifo_fast (kernel default) to fq_codel (/usr/lib/sysctl.d/50-default.conf for Ubuntu). As of v5.8 kernel fq_codel still has a lock to enqueue packets, so systems using fq_codel with RSS/RPS are hitting this lock contention which affects overall system performance. pfifo_fast is lockless as of v4.16 so for newer kernels the kernel's default is best.

But, it begs the question why have a qdisc for a VM tap device (or a container's veth device) at all? To the VM a host is just part of the network. You would not want a top-of-rack switch to buffer packets for the server, so why have the host buffer packets for a VM? (The “Tx” path for a tap device represents packets going to the VM.)

You can change the default via:

sysctl -w net.core.default_qdisc=noqueue

or add that to a sysctl file (e.g., /etc/sysctl.d/90-local.conf). sysctl changes affect new devices only.

Alternatively, the default can be changed for selected devices via a udev rule:

cat > /etc/udev/rules.d/90-tap.rules <<EOF
ACTION=="add|change", SUBSYSTEM=="net", KERNEL=="tap*", PROGRAM="/sbin/tc qdisc add dev $env{INTERFACE} root handle 1000: noqueue"

Running sudo udevadm trigger should update existing devices. Check using tc qdisc sh dev <NAME>:

$ tc qdisc sh dev tapext4798884
qdisc noqueue 1000: root refcnt 2
qdisc ingress ffff: parent ffff:fff1 ----------------

[1] https://www.kernel.org/doc/Documentation/networking/scaling.txt


Read more...

from Konstantin Ryabitsev

With git, a cryptographic signature on a commit provides strong integrity guarantees of the entire history of that branch going backwards, including all metadata and all contents of the repository, all the way back to the initial commit. This is possible because git records the hash of the previous commit in each next commit's metadata, creating an unbreakable cryptographic chain of records. If you can verify the cryptographic signature at the tip of the branch, you effectively verify that branch's entire history.

For example, let's take a look at linux.git, where the latest tag at the time of writing, v5.8-rc7, is signed by Linus Torvalds. (Tag signatures are slightly different from commit signatures — but in every practical sense they offer the same guarantees.)

If you have a git checkout of torvalds/linux.git, you are welcome to follow along.

$ git cat-file -p v5.8-rc7
object 92ed301919932f777713b9172e525674157e983d
type commit
tag v5.8-rc7
tagger Linus Torvalds <torvalds@linux-foundation.org> 1595798046 -0700

Linux 5.8-rc7
-----BEGIN PGP SIGNATURE-----

iQFSBAABCAA8FiEEq68RxlopcLEwq+PEeb4+QwBBGIYFAl8d8h4eHHRvcnZhbGRz
QGxpbnV4LWZvdW5kYXRpb24ub3JnAAoJEHm+PkMAQRiGd0sH/2iktYhMwPxzzpnb
eI3OuTX/mRn4vUFOfpx9dmGVleMfKkpbvnn3IY7wA62Qfv7J7lkFRa1Bd1DlqXfW
yyGTGDSKG5chiRCOU3s9ni92M4xIzFlrojyt/dIK2lUGMzUPI9FGlZRGQLKqqwLh
2syOXRWbcQ7e52IHtDSy3YBNveKRsP4NyqV+GxGiex18SMB/M3Pw9EMH614eDPsE
QAGQi5uGv4hPJtFHgXgUyBPLFHIyFAiVxhFRIj7u2DSEKY79+wO1CGWFiFvdTY4B
CbqKXLffY3iQdFsLJkj9Dl8cnOQnoY44V0EBzhhORxeOp71StUVaRwQMFa5tp48G
171s5Hs=
=BQIl
-----END PGP SIGNATURE-----

If we have Linus's key in our GnuPG keyring, we can easily verify that this tag is valid:

$ git verify-tag v5.8-rc7
gpg: Signature made Sun 26 Jul 2020 05:14:06 PM EDT
gpg:                using RSA key ABAF11C65A2970B130ABE3C479BE3E4300411886
gpg:                issuer "torvalds@linux-foundation.org"
gpg: Good signature from "Linus Torvalds <torvalds@kernel.org>" [unknown]
gpg:                 aka "Linus Torvalds <torvalds@linux-foundation.org>" [full]

The entire contents of this tag are signed, so this tells us that when Linus signed the tag, the “object hash” on his system was 92ed301919932f777713b9172e525674157e983d. But what exactly is that “object hash?” What are the contents that are hashed here? We can find out by asking git to tell us more about that object:

$ git cat-file -p 92ed301919932f777713b9172e525674157e983d
tree f16e3e4bcea2d875a17d2278ff67364b3277b10a
parent 1c8594b8427290c178c5d39885eacd9e41f68743
author Linus Torvalds <torvalds@linux-foundation.org> 1595798046 -0700
committer Linus Torvalds <torvalds@linux-foundation.org> 1595798046 -0700

Linux 5.8-rc7

The above contents in their entirety (slightly differently formatted) is what gives us the sha1 hash 92ed301919932f777713b9172e525674157e983d. So, thus far, we have unbroken cryptographic attestation from Linus's PGP signature to two other important bits about his git repository:

  • information about the state of his source code (tree)
  • information about the previous commit in the history (parent)
  • information about the author of the commit and the committer, which are the one and the same in this particular case
  • information about the date and time when the commit was made

Let's take a look a the tree line — what contents were hashed to arrive at that checksum? Let's ask git:

$ git cat-file -p f16e3e4bcea2d875a17d2278ff67364b3277b10a
100644 blob a0a96088c74f49a961a80bc0851a84214b0a9f83    .clang-format
100644 blob 43967c6b20151ee126db08e24758e3c789bcb844    .cocciconfig
100644 blob a64d219137455f407a7b1f2c6b156c5575852e9e    .get_maintainer.ignore
100644 blob 4b32eaa9571e64e47b51c43537063f56b204d8b3    .gitattributes
100644 blob d5f4804ed07cd36336a5e80f2a24e45104f902cf    .gitignore
100644 blob db4f2295bd9d792b47eb77aab179a9db0d968454    .mailmap
100644 blob a635a38ef9405fdfcfe97f3a435393c1e9cae971    COPYING
100644 blob 0787b5872906c8a92a63cde3961ed630e2ec93b6    CREDITS
040000 tree 37e1b4166d912d69738beca645d3d539da4bbf30    Documentation
[...]
040000 tree ba6955ee6228666d9ef117fdd45df2e53ba0e221    virt

This is the entirety of the top-level Linux kernel directory contents. The blob entries are sha1sum's of the actual file contents in that directory, so these are straightforward. Subdirectories are represented as other tree entries, which also consist of blob and tree records going all the way down to the last sublevel, which will only contain blobs.

So, tree f16e3e4bcea2d875a17d2278ff67364b3277b10a in the commit record is a checksum of other checksums and it allows us to verify that each and every file in linux.git is exactly the same as it was on Linus Torvalds' system when he created the commit. If any file is changed, the tree checksum would be different and the whole repository would be considered invalid, because the object hash would be different than in the commit.

Finally, if we look at the object mentioned in parent 1c8594b8427290c178c5d39885eacd9e41f68743, we will see that it is a hash of another commit, containing its own tree and parent records:

$ git cat-file -p 1c8594b8427290c178c5d39885eacd9e41f68743
tree d56de40028d9ecdbebfc2121fd1ce1213fa09fa2
parent 40c60ac32174f0c0c090cd31d0d1712f2478e689
parent ca9b31f6bb9c6aa9b4e5f0792f39a97bbffb8c51
author Linus Torvalds <torvalds@linux-foundation.org> 1595796417 -0700
committer Linus Torvalds <torvalds@linux-foundation.org> 1595796417 -0700
mergetag object ca9b31f6bb9c6aa9b4e5f0792f39a97bbffb8c51
[...]

If we cared to, we could walk each commit all the way back to the beginning of Linux git history, but we don't need to do that — verifying the checksum of the latest commit is sufficient to provide us all the necessary assurances about the entire history of that tree.

So, if we verify the signature on the tag and confirm that it matches the key belonging to Linus Torvalds, we will have strong cryptographic assurances that the repository on our disk is byte-for-byte the same as the repository on the computer belonging to Linus Torvalds — with all its contents and its entire history going back to the initial commit.

The difference between signed tags and signed commits is minimal — in the case of commit signing, the signature goes into the commit object itself. It is generally a good practice to PGP-sign commits, particularly in environments where multiple people can push to the same repository branch. Signed commits provide easy forensic proof of code origins (e.g. without commit signing Alice can fake a commit to pretend that it was actually authored by Bob). It also allows for easy verification in cases where someone wants to cherry-pick specific commits into their own tree without performing a git merge.

If you are looking to get started with git and PGP signatures, I can recommend my own Protecting Code Integrity guide, or its kernel-specific adaptation that ships with the kernel docs: Kernel Maintainer PGP Guide.

Obligatory note: sha1 is not considered sufficiently strong for hashing purposes these days, and this is widely acknowledged by the git development community. Significant efforts are under way to migrate git to stronger cryptographic hashes, but they require careful planning and implementation in order to minimize disruption to various projects using git. To my knowledge, there are no effective attacks against sha1 as used by git, and git developers have added further precautions against sha1 collision attacks in git itself, which helps buy some time until stronger hashing implementations are considered ready for real-world use.


Read more...

from Christian Brauner

Introduction

As most people know by know we do a lot of upstream kernel development. This stretches over multiple areas and of course we also do a lot of kernel work around containers. In this article I'd like to take a closer look at the new seccomp notify feature we have been developing both in the kernel and in userspace and that is seeing more and more users. I've talked about this feature quite a few times at various conferences (just recently again at OSS NA) over the last two years but never actually sat down to write a blogpost about it. This is something I had wanted to do for quite some time. First, because it is a very exciting feature from a purely technical perspective but also from the new possibilities it opens up for (unprivileged) containers and other use-cases.

The Limits of Unprivileged Containers

That (Linux) Containers are a userspace fiction is a well-known dictum nowadays. It simply expresses the fact that there is no container kernel object in the Linux kernel. Instead, userspace is relatively free to define what a container is. But for the most part userspace agrees that a container is somehow concerned with isolating a task or a task tree from the host system. This is achieved by combining a multitude of Linux kernel features. One of the better known kernel features that is used to build containers are namespaces. The number of namespaces the kernel supports has grown over time and we are currently at eight. Before you go and look them up on namespaces(7) here they are:

  • cgroup: cgroup_namespaces(7)
  • ipc: ipc_namespaces(7)
  • network: network_namespaces(7)
  • mount: mount_namespaces(7)
  • pid: pid_namespaces(7)
  • time: time_namespaces(7)
  • user: user_namespaces(7)
  • uts: uts_namespaces(7)

Of these eight namespaces the user namespace is the only one concerned with isolating core privilege concepts on Linux such as user- and group ids, and capabilities.

Quite often we see tasks in userspace that check whether they run as root or whether they have a specific capability (e.g. CAP_MKNOD is required to create device nodes) and it seems that when the answer is “yes” then the task is actually a privileged task. But as usual things aren't that simple. What the task thinks it's checking for and what the kernel really is checking for are possibly two very different things. A naive task, i.e. a task not aware of user namespaces, might think it's asking whether it is privileged with respect to the whole system aka the host but what the kernel really checks for is whether the task has the necessary privileges relative to the user namespace it is located in.

In most cases the kernel will not check whether the task is privileged with respect to the whole system. Instead, it will almost always call a function called ns_capable() which is the kernel's way of checking whether the calling task has privilege in its current user namespace.

For example, when a new user namespace is created by setting the CLONE_NEWUSER flag in unshare(2) or in clone3(2) the kernel will grant a full set of capabilities to the task that called unshare(2) or the newly created child task via clone3(2) within the new user namespace. When this task now e.g. checks whether it has the CAP_MKNOD capability the kernel will report back that it indeed has that capability. The key point though is that this “yes” is not a global “yes”, i.e. the question “Am I privileged enough to perform this operation?” only applies to the current user namespace (and technically any nested user namespaces) not the host itself.

This distinction is important when trying to understand why a task running as root in a new user namespace with all capabilities raised will still see EPERM when e.g. trying to call mknod("/dev/mem", makedev(1, 1)) even though it seems to have all necessary privileges. The reason for this counterintuitive behavior is that the kernel isn't always checking whether you are privileged against your current user namespace. Instead, for any operation that it thinks is dangerous to expose to unprivileged users it will check whether the task is privileged in the initial user namespace, i.e. the host's user namespace.

Creating device nodes is one such example: if a task running in a user namespace were to be able to create character or block device nodes it could e.g. create /dev/kmem or any other critical device and use the device to take over the host. So the kernel simply blocks creating all device nodes in user namespaces by always performing the check for required privileges against the initial user namespace. This is of course technically inconsistent since capabilities are per user namespace as we observed above.

Other examples where the kernel requires privileges in the initial user namespace are mounting of block devices. So simply making a disk device node available to an unprivileged container will still not make it useable since it cannot mount it. On the other hand, some filesystems like cgroup, cgroup2, tmpfs, proc, sysfs, and fuse can be mounted in user namespace (with some caveats for proc and sys but we're ignoring those details for now) because the kernel can guarantee that this is safe.

But of course these restrictions are annoying. Not being able to mount block devices or create device nodes means quite a few workloads are not able to run in containers even though they could be made to run safely. Quite often a container manager like LXD will know better than the kernel when an operation that a container tries to perform is safe.

A good example are device nodes. Most containers bind-mount the set of standard devices into the container otherwise it would not work correctly:

/dev/console
/dev/full
/dev/null
/dev/random
/dev/tty
/dev/urandom
/dev/zero

Allowing a container to create these devices would be safe. Of course, the container will simply bind-mount these devices during container startup into the container so this isn't really a serious problem. But any program running inside the container that wants to create these harmless devices nodes would fail.

The other example that was mentioned earlier is mounting of block-based filesystems. Our users often instruct LXD to make certain disk devices available to their containers because they know that it is safe. For example, they could have a dedicated disk for the container or they want to share data with or among containers. But the container could not mount any of those disks.

For any use-case where the administrator is aware that a device node or disk device is missing from the container LXD provides the ability to hotplug them into one or multiple containers. For example, here is how you'd hotplug /dev/zero into a running container:

 brauner@wittgenstein|~
> lxc exec f5 -- ls -al /my/zero

brauner@wittgenstein|~
> lxc config device add f5 zero-device unix-char source=/dev/zero path=/my/zero
Device zero-device added to f5

brauner@wittgenstein|~
> lxc exec f5 -- ls -al /my/zero
crw-rw---- 1 root root 1, 5 Jul 23 10:47 /my/zero

But of course, that doesn't help at all when a random application inside the container calls mknod(2) itself. In these cases LXD has no way of helping the application by hotplugging the device as it's unaware that a mknod syscall has been performed.

So the root of the problem seems to be: – A task inside the container performs a syscall that will fail. – The syscall would not need to fail since the container manager knows that it is safe. – The container manager has no way of knowing when such a syscall is performed. – Even if the the container manager would know when such a syscall is performed it has no way of inspecting it in detail.

So a potential solution to this problem seems to be to enable the container manager or any sufficiently privileged task to take action on behalf of the container whenever it performs a syscall that would usually fail. So somehow we need to be able to interact with the syscalls of another task.

Seccomp – The Basics of Syscall Interception

The obvious candidate to look at is seccomp. Short for “secure computing” it provides a way of restricting the syscalls of a task either by allowing only a subset of the syscalls the kernel supports or by denying a set of syscalls it thinks would be unsafe for the task in question. But seccomp allows even more advanced configurations through so-called “filters”. Filters are BPF programs (Not to be equated with eBPF. BPF is a predecessor of eBPF.) that can be written in userspace and loaded into the kernel. For example, a task could use a seccomp filter to only allow the mount() syscall and only those mount syscalls that create bind mounts. This simple syscall management mechanism has made seccomp an essential security feature for a lot of userspace programs. Nowadays it is considered good practice to restrict any critical programs to only those syscalls it absolutely needs to run successfully. Browser-based sandboxes and containers being prime examples but even systemd services can be seccomp restricted.

At its core seccomp is nothing but a syscall interception mechanism. One way or another every operating system has something that is at least roughly comparable. The way seccomp works is that it intercepts syscalls right in the architecture specific syscall entry paths. So the seccomp invocations themselves live in the architecture specific codepaths although most of the logical around it is architecture agnostic.

Usually, when a syscall is performed, and no seccomp filter has been applied to the task issuing the syscall the kernel will simply lookup the syscall number in the architecture specific syscall table and if it is a known syscall will perform it reporting back the result to userspace.

But when a seccomp filter is loaded for the task issuing the syscall instead of directly looking up the syscall number in the architecture's syscall table the kernel will first call into seccomp and run the loaded seccomp filter.

Depending on whether a deny or allow approach is used for the seccomp filter any syscall that the filter is not handling specifically is either performed or denied reporting back a specified default value to the calling task. If the requested syscall is supposed to be specifically handled by the seccomp filter the kernel can e.g. be caused to report back a specific error code. This way, it is for example possible to have the kernel pretend like it doesn't know the mount(2) syscall by creating a seccomp filter that reports back ENOSYS whenever the task tries to call mount(2).

But the way seccomp used to work isn't very dynamic. Specifically, once a filter is loaded the decision whether or not the syscall is successful or not is fixed based on the policy expressed by the filter. So there is no way to make a case-by-case decision which might come in handy in some scenarios.

In addition seccomp itself can't make a syscall actually succeed other than in the trivial way of reporting back success to the caller. So seccomp will only allow the kernel to pretend that a syscall succeeded. So while it is possible to instruct the kernel to return 0 for the mount(2) syscall it cannot actually be instructed to make the mount(2) syscall succeed. So just making the seccomp filter return 0 for mounting a dedicated ext4 disk device to /mnt will still not actually mount it at /mnt; it just pretends to the caller that it did. Of course that is in itself already a useful property for a bunch of use-cases but it doesn't really help with the mknod(2) or mount(2) problem outlined above.

Extending Seccomp

So from the section above it should be clear that seccomp provides a few desirable properties that make it a natural candiate to look at to help solve our mknod(2) and mount(2) problem. Since seccomp intercepts syscalls early in the syscall path it already gives us a hook into the syscall path of a given task. What is missing though is a way to bring another task such as the LXD container manager into the picture. Somehow we need to modify seccomp in a way that makes it possible for a container manager to not just be informed when a task inside the container performs a syscall it wants to be informed about but also how to make it possible to block the task until the container manager instructs the kernel to allow it to proceed.

The answer to these questions is seccomp notify. This is as good a time as any to bring in some historical context. The exact origins of the idea for a more dynamic way to intercept syscalls is probably not recoverable and it has been thrown around in unspecific form in various discussions but nothing serious every materialized. The first concrete details around seccomp notify were conceived in early 2017 in the LXD team. The first public talk around the basic idea for this feature was given by Stéphane Graber at the Linux Plumbers Conference 2017 during the Container's Microconference in Los Angeles. The details of this talk are still listed here here and I'm sure Stéphane can still provide the slides we came up with. I didn't find a video recording even though I somehow thought we did have one. If someone is really curious I can try to investigate with the Linux Plumbers committee. After this talk implementation specifics were discussed in a hallway meeting later that day. And after a long arduous journey the implementation was upstreamed by Tycho Andersen who used to be on the LXD team. The rest is history^wchangelog.

Seccomp Notify – Syscall Interception 2.0

In its essence, the seccomp notify mechanism is simply a file descriptor (fd) for a specific seccomp filter. When a container starts it will usually load a seccomp filter to restrict its attack surface. That is even done for unprivileged containers even though it is not strictly necessary.

With the addition of seccomp notify a container wishing to have a subset of syscalls handled by another process can set the new SECCOMP_RET_USER_NOTIF flag on its seccomp filter. This flag instructs the kernel to return a file descriptor to the calling task after having loaded its filter. This file descriptor is a seccomp notify file descriptor.

Of course, the seccomp notify fd is not very useful to the task itself. First, since it doesn't make a lot of sense apart from very weird use-cases for a task to listen for its own syscalls. Second, because the task would likely block itself indefinitely pretty quickly without taking extreme care.

But what the task can do with the seccomp notify fd is to hand to another task. Usually the task that it will hand the seccomp notify fd to will be more privileged than itself. For a container the most obvious candidate would be the container manager of course.

Since the seccomp notify fd is pollable it is possible to put it into an event loop such as epoll(7), poll(2), or select(2) and wait for the file descriptor to become readable, i.e. for the kernel to return EPOLLIN to userspace. For the seccomp notify fd to become readable means that the seccomp filter it refers to has detected that one of the tasks it has been applied to has performed a syscall that is part of the policy it implements. This is a complicated way of saying the kernel is notifying the container manager that a task in the container has performed a syscall it cares about, e.g. mknod(2) or mount(2).

Put another way, this means the container manager can listen for syscall events for tasks running in the container. Now instead of simply running the filter and immediately reporting back to the calling task the kernel will send a notification to the container manager on the seccomp notify fd and block the task performing the syscall.

After the seccomp notify fd indicates that it is readable the container manager can use the new SECCOMP_IOCTL_NOTIF_RECV ioctl() associated with seccomp notify fds to read a struct seccomp_notif message for the syscall. Currently the data to be read from the seccomp notify fd includes the following pieces. But please be aware that we are in the process of discussing potentially intrusive changes for future versions:

struct seccomp_notif {
	__u64 id;
	__u32 pid;
	__u32 flags;
	struct seccomp_data data;
};

Let's look at this in a little more detail. The pid field is the pid of the task that performed the syscall as seen in the caller's pid namespace. To stay within the realm of our current examples, this is simply the pid of the task in the container the e.g. called mknod(2) as seen in the pid namespace of the container manager. The id field is a unique identifier for the performed syscall. This can be used to verify that the task is still alive and the syscall request still valid to avoid any race conditions caused by pid recycling. The flags argument is currently unused and reserved for future extensions.

The struct seccomp_data argument is probably the most interesting one as it contains the really exciting bits and pieces:

struct seccomp_data {
	int nr;
	__u32 arch;
	__u64 instruction_pointer;
	__u64 args[6];
};

The int field is the syscall number which can only be correctly interpreted relative to the arch field. The arch field is the (audit) architecture for which this syscall was made. This field is very relevant since compatible architectures (For the x86 architectures this encompasses at least x32, i386, and x86_64. The arm, mips, and power architectures also have compatible “sub” architectures.) are stackable and the returned syscall number might be different than the current headers imply (For example, you could be making a syscall from a 32bit userspace on a 64bit kernel. If the intercepted syscall has different syscall numbers on 32 bit and on 64bit, for example syscall foo() might have syscall number 1 on 32 bit and 2 on 64 bit. So the task reading the seccomp data can't simply assume that since it itself is running in a 32 bit environment the syscall number must be 1. Rather, it must check what the audit arch is and then either check that the value of the syscall is 1 on 32 bit and 2 on 64 bit. Otherwise the container manager might end up emulating mount() when it should be emulating mknod().). The instruction_pointer is set to the address of the instruction that performed the syscall. This is of course also architecture specific. And last the args member are the syscall arguments that the task performed the syscall with.

The args need to be interpreted and treated differently depending on the syscall layout and their type. If they are non-pointer arguments (unsigned int etc.) they can be copied into a local variable and interpreted right away. But if they are pointer arguments they are offsets into the virtual memory of the task that performed the syscall. In the latter case the memory needs to be read and copied before it can be interpreted.

Let's look at a concrete example to figure out why it is vital to know the syscall layout other than for knowing the types of the syscall arguments. Say the performed syscall was mount(2). In order to interpret the args field correctly we look at the syscall layout of mount(). (Please note, that I'm stressing that we need to look at the layout of syscall and the only reliable source for this is actually the kernel source code. The Linux manpages often list the wrapper provided by the system's libc and these wrapper do not necessarily line-up with the syscall itself (compare the waitid() wrapper and the waitid() syscall or the various clone() syscall layouts).) From the layout of mount(2) we see that args[0] is a pointer argument identifying the source path, args[1] is another pointer argument identifying the target path, args[2] is a pointer argument identifying the filesystem type, args[3] is a non-pointer argument identifying the options, and args[4] is another pointer argument identifying additional mount options.

So if we were to be interested in the source path of this mount(2) syscall we would need to open the /proc/<pid>/mem file of the task that performed this syscall and e.g. use the pread(2) function with args[0] as the offset into the task's virtual memory and read it into a buffer at least the length of a standard path. Alternatively, we can use a single syscall like process_vm_readv(2) to read multiple remote pointers at different locations all in one go. Once we have done this we can interpret it.

A friendly advice: in general it is a good idea for the container manager to read all syscall arguments once into a local buffer and base its decisions on how to proceed on the data in this local buffer. Not just because it will otherwise not be able for the container manager to interpret pointer arguments but it's also a possible attack vector since a sufficiently privileged attacker (e.g. a thread in the same thread-group) can write to /proc/<pid>/mem and change the contents of e.g. args[0] or any other syscall argument. Also note, that the container manager should ensure that /proc/<pid> still refers to the same task after opening it by checking the validity of the syscall request via the id field and the associated SECCOMP_IOCTL_NOTIF_ID_VALID ioctl() to exclude the possibility of the task having exited, been reaped and its pid having been recycled.

But let's assume we have done all that. Now that the container manager has the task's syscall arguments available in a local buffer it can interpret the syscall arguments. While it is doing so the target task remains blocked waiting for the kernel to tell it to proceed. After the container manager is done interpreting the arguments and has performed whatever action it wanted to perform it can use the SECCOMP_IOCTL_NOTIF_SEND ioctl() on the seccomp notify fd to tell the kernel what it should do with the blocked task's syscall. The response is given in the form struct seccomp_notif_resp:

struct seccomp_notif_resp {
	__u64 id;
	__s64 val;
	__s32 error;
	__u32 flags;
};

Let's look at this struct in a little more detail too. The id field is set to the id of the syscall request to respond to and should correspond to the received id in the struct seccomp_notif that the container manager read via the SECCOMP_IOCTL_NOTIF_RECV ioctl() when the seccomp notify fd became readable. The val field is the return value of the syscall and is only set if the error field is set to 0. The error field is the error to return from the syscall and should be set to a negative errno(3) code if the syscall is supposed to fail (For example, to trick the caller into thinking that mount(2) is not supported on this kernel set error to -ENOSYS.). The flags value can be used to tell the kernel to continue the syscall by setting the SECCOMP_USER_NOTIF_FLAG_CONTINUE flag which I added to be able to intercept mount(2) and other syscalls that are difficult for seccomp to filter efficiently because of the restrictions around pointer arguments. More on that in a little bit.

With this machinery in place we are for now ;) done with the kernel bits.

Emulating Syscalls In Userspace

So what is the container manager supposed to do after having read and interpreted the syscall information for the task running in the container and telling the kernel to let the task continue. Probably emulate it. Otherwise we just have a fancy and less performant seccomp userspace policy (Please read my comments on why that is a very bad idea.).

Emulating syscalls in userspace is not a very new thing to do. It has been done for a long time. For example, libc's can choose to emulate the execveat(2) syscall which allows a task to exec a program by providing a file descriptor to the binary instead of a path. On a kernel that doesn't support the execveat(2) syscall the libc can emulate it by calling exec(3) with the path set to /proc/self/fd/<nr>. The problem of course is that this emulation only works when the task in question actually uses the libc wrapper (fexecve(3) for our example). Any task using syscall(__NR_execveat, [...]) to perform the syscall without going through the provided wrapper will be bypassing libc and so libc doesn't know that the task wants to perform the execveat(2) syscall and will not be able to emulate it in case the kernel doesn't support it.

Seccomp notify doesn't suffer from this problem since its syscall interception abilities aren't located in userspace at the library level but directly in the syscall path as we have seen. This greatly expands the abilities to emulate syscalls.

So now we have all the kernel pieces in place to solve our mknod(2) and mount(2) problem in unprivileged containers. Instead of simply letting the container fail on such harmless requests as creating the /dev/zero device node we can use seccomp notify to intercept the syscall and emulate it for the container in userspace by simply creating the device node for it. Similarly, we can intercept mount(2) requests requiring the user to e.g. give us a list of allowed filesystems to mount for the container and performing the mount for the container. We can even make this a lot safer by providing a user with the ability to specify a fuse binary that should be used when a task in the container tries to mount a filesystem. We actually support this feature in LXD. Since fuse is a safe way for unprivileged users to mount filesystems rewriting mount(2) requests is a great way to expose filesystems to containers.

In general, the possibilities of seccomp notify can't be overstated and we are extremely happy that this work is now not just fully integrated into the Linux kernel but also into both LXD and LXC. As with many other technologies we have driven both in the upstream kernel and in userspace it directly benefits not just our users but all of userspace with seccomp notify seeing adoption in browsers and by other companies. A whole range of Travis workloads can now run in unprivileged LXD containers thanks to seccomp notify.

Seccomp Notify in action – LXD

After finishing the kernel bits we implemented support for it in LXD and the LXC shared library it uses. Instead of simply exposing the raw seccomp notify fd for the container's seccomp filter directly to LXD each container connects to a multi-threaded socket that the LXD container manager exposes and on which it listens for new clients. Clients here are new containers who the administrator has signed up for syscall supervisions through LXD. Each container has a dedicated syscall supervisor which runs as a separate go routine and stays around for as long as the container is running.

When the container performs a syscall that the filter applies to a notification is generated on the seccomp notify fd. The container then forwards this request including some additional data on the socket it connected to during startup by sending a unix message including necessary credentials. LXD then interprets the message, checking the validity of the request, verifying the credentials, and processing the syscall arguments. If LXD can prove that the request is valid according to the policy the administrator specified for the container LXD will proceed to emulate the syscall. For mknod(2) it will create the device node for the container and for mount(2) it will mount the filesystem for the container. Either by directly mounting it or by using a specified fuse binary for additional security.

If LXD manages to emulate the syscall successfully it will prepare a response that it will forward on the socket to the container. The container then parses the message, verifying the credentials and will use the SECCOMP_IOCTL_NOTIF_SEND ioctl() sending a struct seccomp_notif_resp causing the kernel to unblock the task performing the syscall and reporting back that the syscall succeeded. Conversely, if LXD fails to emulate the syscall for whatever reason or the syscall is not allowed by the policy the administrator specified it will prepare a message that instructs the container to report back that the syscall failed and unblocking the task.

Show Me!

Ok, enough talk. Let's intercept some syscalls. The following demo shows how LXD uses the seccomp notify fd to emulate the mknod(2) and mount(2) syscalls for an unprivileged container:

asciicast

Current Work and Future Directions

SECCOMP_USER_NOTIF_FLAG_CONTINUE

After the initial support for the seccomp notify fd landed we ran into limitations pretty quickly. We realized we couldn't intercept the mount syscall. Since the mount syscall has various pointer arguments it is difficult to write highly specific seccomp filters such that we only accept syscalls that we intended to intercept. This is caused by seccomp not being able to handle pointer arguments. They are opaque for seccomp. So while it is possible to tell seccomp to only intercept mount(2) requests for real filesystems by only intercepting mount(2) syscalls where the MS_BIND flag is not set in the flags argument it is not possible to write a seccomp filter that only notifies the container manager about mount(2) syscalls for the ext4 or btrfs filesystem because the filesystem argument is a pointer.

But this means we will inadvertently intercept syscalls that we didn't intend to intercept. That is a generic problem but for some syscalls it's not really a big deal. For example, we know that mknod(2) fails for all character and block devices in unprivileged containers. So as long was we write a seccomp filter that intercepts only character and block device mknod(2) syscalls but no socket or fifo mknod() syscalls we don't have a problem. For any character or block device that is not in the list of allowed devices in LXD we can simply instruct LXD to prepare a seccomp message that tells the kernel to report EPERM and since the syscalls would fail anyway there's no problem.

But any system call that we intercepted as a consequence of seccomp not being able to filter on pointer arguments that would succeed in unprivileged containers would need to be emulated in userspace. But this would of course include all mount(2) syscalls for filesystems that can be mounted in unprivileged containers. I've listed a subset of them above. It includes at least tmpfs, proc, sysfs, devpts, cgroup, cgroup2 and probably a few others I'm forgetting. That's not ideal. We only want to emulate syscalls that we really have to emulate, i.e. those that would actually fail.

The solution to this problem was a patchset of mine that added the ability to continue an intercepted syscall. To instruct the kernel to continue the syscall the SECCOMP_USER_NOTIF_FLAG_CONTINUE flag can be set in struct seccomp_notif_resp's flag argument when instructing the kernel to unblock the task.

This is of course a very exciting feature and has a few readers probably thinking “Hm, I could implement a dynamic userspace seccomp policy.” to which I want to very loudly respond “No, you can't!”. In general, the seccomp notify fd cannot be used to implement any kind of security policy in userspace. I'm now going to mostly quote verbatim from my comment for the extension: The SECCOMP_USER_NOTIF_FLAG_CONTINUE flag must be used with extreme caution! If set by the task supervising the syscalls of another task the syscall will continue. This is problematic is inherent because of TOCTOU (Time of Check-Time of Use). An attacker can exploit the time while the supervised task is waiting on a response from the supervising task to rewrite syscall arguments which are passed as pointers of the intercepted syscall. It should be absolutely clear that this means that seccomp notify cannot be used to implement a security policy on syscalls that read from dereferenced pointers in user space! It should only ever be used in scenarios where a more privileged task supervises the syscalls of a lesser privileged task to get around kernel-enforced security restrictions when the privileged task deems this safe. In other words, in order to continue a syscall the supervising task should be sure that another security mechanism or the kernel itself will sufficiently block syscalls if arguments are rewritten to something unsafe.

Similar precautions should be applied when stacking SECCOMP_RET_USER_NOTIF or SECCOMP_RET_TRACE. For SECCOMP_RET_USER_NOTIF filters acting on the same syscall, the most recently added filter takes precedence. This means that the new SECCOMP_RET_USER_NOTIF filter can override any SECCOMP_IOCTL_NOTIF_SEND from earlier filters, essentially allowing all such filtered syscalls to be executed by sending the response SECCOMP_USER_NOTIF_FLAG_CONTINUE. Note that SECCOMP_RET_TRACE can equally be overriden by SECCOMP_USER_NOTIF_FLAG_CONTINUE.

Retrieving file descriptors pidfd_getfd()

Another extension that was added by Sargun Dhillon recently building on top of my pidfd work was to make it possible to retrieve file descriptors from another task. This works even without seccomp notify since it is a new syscall but is of course especially useful in conjunction with it.

Often we would like to intercept syscalls such as connect(2). For example, the container manager might want to rewrite the connect(2) request to something other than the task intended for security reasons or because the task lacks the necessary information about the networking layout to connect to the right endpoint. In these cases pidfd_getfd(2) can be used to retrieve a copy of the file descriptor of the task and perform the connect(2) for it. This unblocks another wide range of use-cases.

For example, it can be used for further introspection into file descriptors than ss, or netstat would typically give you, as you can do things like run getsockopt(2) on the file descriptor, and you can use options like TCP_INFO to fetch a significant amount of information about the socket. Not only can you fetch information about the socket, but you can also set fields like TCP_NODELAY, to tune the socket without requiring the user's intervention. This mechanism, in conjunction can be used to build a rudimentary layer 4 load balancer where connect(2) calls are intercepted, and the destination is changed to a real server instead.

Early results indicate that this method can yield incredibly good latency as compared to other layer 4 load balancing techniques.

Plot 63
Injecting file descriptors SECCOMP_NOTIFY_IOCTL_ADDFD

Current work for the upcoming merge window is focussed on making it possible to inject file descriptors into a task. As things stand, we are unable to intercept syscalls (Unless we share the file descriptor table with the task which is usually never the case for container managers and the containers they supervise.) such as open(2) that cause new file descriptors to be installed in the task performing the syscall.

The new seccomp extension effectively allows the container manager to instructs the target task to install a set of file descriptors into its own file descriptor table before instructing it to move on. This way it is possible to intercept syscalls such as open(2) or accept(2), and install (or replace, like dup2(2)) the container manager's resulting fd in the target task.

This new technique opens the door to being able to make massive changes in userspace. For example, techniques such as enabling unprivileged access to perf_event_open(2), and bpf(2) for tracing are available via this mechanism. The manager can inspect the program, and the way the perf events are being setup to prevent the user from doing ill to the system. On top of that, various network techniques are being introducd, such as zero-cost IPv6 transition mechanisms in the future.

Last, I want to note that Sargun Dhillon was kind enough to contribute paragraphs to the pidfd_getfd(2) and SECCOMP_NOTIFY_IOCTL_ADDFD sections. He also provided the graphic in the pidfd_getfd(2) sections to illustrate the performance benefits of this solution.

Christian


Read more...

from David Ahern

When evaluating networking for a host the focus is typically on latency, throughput or packets per second (pps) to see the maximum load a system can handle for a given configuration. While those are important and often telling metrics, results for such benchmarks do not tell you the impact processing those packets has on the workloads running on that system.

This post looks at the cost of networking in terms of CPU cycles stolen from processes running in a host.

Packet Processing in Linux

Linux will process a fair amount of packets in the context of whatever is running on the CPU at the moment the irq is handled. System accounting will attribute those CPU cycles to any process running at that moment even though that process is not doing any work on its behalf. For example, 'top' can show a process appears to be using 99+% cpu but in reality 60% of that time is spent processing packets meaning the process is really only get 40% of the CPU to make progress on its workload.

net_rx_action, the handler for network Rx traffic, usually runs really fast – like under 25 usecs[1] – dealing with up to 64 packets per napi instance (NIC and RPS) at a time before deferring to another softirq cycle. softirq cycles can be back to back, up to 10 times or 2 msec (see __do_softirq), before taking a break. If the softirq vector still has more work to do after the maximum number of loops or time is reached, it defers further work to the ksoftirqd thread for that CPU. When that happens the system is a bit more transparent about the networking overhead in the sense that CPU usage can be monitored (though with the assumption that it is packet handling versus other softirqs).

One way to see the above description is using perf:

sudo perf record -a \
        -e irq:irq_handler_entry,irq:irq_handler_exit \
        -e irq:softirq_entry --filter="vec == 3" \
        -e irq:softirq_exit --filter="vec == 3"  \
        -e napi:napi_poll \
        -- sleep 1

sudo perf script

The output is something like:

swapper     0 [005] 176146.491879: irq:irq_handler_entry: irq=152 name=mlx5_comp2@pci:0000:d8:00.0
swapper     0 [005] 176146.491880:  irq:irq_handler_exit: irq=152 ret=handled
swapper     0 [005] 176146.491880:     irq:softirq_entry: vec=3 [action=NET_RX]
swapper     0 [005] 176146.491942:        napi:napi_poll: napi poll on napi struct 0xffff9d3d53863e88 for device eth0 work 64 budget 64
swapper     0 [005] 176146.491943:      irq:softirq_exit: vec=3 [action=NET_RX]
swapper     0 [005] 176146.491943:     irq:softirq_entry: vec=3 [action=NET_RX]
swapper     0 [005] 176146.491971:        napi:napi_poll: napi poll on napi struct 0xffff9d3d53863e88 for device eth0 work 27 budget 64
swapper     0 [005] 176146.491971:      irq:softirq_exit: vec=3 [action=NET_RX]
swapper     0 [005] 176146.492200: irq:irq_handler_entry: irq=152 name=mlx5_comp2@pci:0000:d8:00.0

In this case the cpu is idle (hence swapper for the process), an irq fired for an Rx queue on CPU 5, softirq processing looped twice handling 64 packets and then 27 packets before exiting with the next irq firing 229 usec later and starting the loop again.

The above was recorded on an idle system. In general, any task can be running on the CPU in which case the above series of events plays out by interrupting that task, doing the irq/softirq dance and with system accounting attributing cycles to the interrupted process. Thus, processing packets is typically hidden from the usual CPU monitoring as it is done in the context of some random, victim process, so how do you view or quantify the time a process is interrupted handling packets? And how can you compare 2 different networking solutions to see which one is less disruptive to a workload?

With RSS, RPS, and flow steering, packet processing is usually distributed across cores, so the packet processing sequence describe above is all per-CPU. As packet rates increase (think 100,000 pps and up) the load means 1000's to 10,000's of packets are processed per second per cpu. Processing that many packets will inevitably have an impact on the workloads running on those systems.

Let's take a look at one way to see this impact.

Undo the Distributed Processing

First, let's undo the distributed processing by disabling RPS and installing flow rules to force the processing of all packets for a specific MAC address on a single, known CPU. My system has 2 nics enslaved to a bond in an 802.3ad configuration with the networking load targeted at a single virtual machine running in the host.

RPS is disabled on the 2 nics using

for d in eth0 eth1; do
    find /sys/class/net/${d}/queues -name rps_cpus |
    while read f; do
            echo 0 | sudo tee ${f}
    done
done

Next, add flow rules to push packets for the VM under test to a single CPU

DMAC=12:34:de:ad:ca:fe
sudo ethtool -N eth0 flow-type ether dst ${DMAC} action 2
sudo ethtool -N eth1 flow-type ether dst ${DMAC} action 2

Together, lack of RPS + flow rules ensure all packets destined to the VM are processed on the same CPU. You can use a command like ethq[3] to verify packets are directed to the expected queue and then map that queue to a CPU using /proc/interrupts. In my case queue 2 is handled on CPU 5.

openssl speed

I could use perf or a bpf program to track softirq entry and exit for network Rx, but that gets complicated quick, and the observation will definitely influence the results. A much simpler and more intuitive solution is to infer the networking overhead using a well known workload such as 'openssl speed' and look at how much CPU access it really gets versus is perceived to get (recognizing the squishiness of process accounting).

'openssl speed' is a nearly 100% userspace command and when pinned to a CPU will use all available cycles for that CPU for the duration of its tests. The command works by setting an alarm for a given interval (e.g., 10 seconds here for easy math), launches into its benchmark and then uses times() when the alarm fires as a way of checking how much CPU time it was actually given. From a syscall perspective it looks like this:

alarm(10)                               = 0
times({tms_utime=0, tms_stime=0, tms_cutime=0, tms_cstime=0}) = 1726601344
--- SIGALRM {si_signo=SIGALRM, si_code=SI_KERNEL} ---
rt_sigaction(SIGALRM, ...) = 0
rt_sigreturn({mask=[]}) = 2782545353
times({tms_utime=1000, tms_stime=0, tms_cutime=0, tms_cstime=0}) = 1726602344

so very few system calls between the alarm and checking the results of times(). With no/few interruptions the tms_utime will match the test time (10 seconds in this case).

Since it is is a pure userspace benchmark ANY system time that shows up in times() is overhead. openssl may be the process on the CPU, but the CPU is actually doing something else, like processing packets. For example:

alarm(10)                               = 0
times({tms_utime=0, tms_stime=0, tms_cutime=0, tms_cstime=0}) = 1726617896
--- SIGALRM {si_signo=SIGALRM, si_code=SI_KERNEL} ---
rt_sigaction(SIGALRM, ...) = 0
rt_sigreturn({mask=[]}) = 4079301579
times({tms_utime=178, tms_stime=571, tms_cutime=0, tms_cstime=0}) = 1726618896

shows that openssl was on the cpu for 7.49 seconds (178 + 571 in .01 increments), but 5.71 seconds of that time was in system time. Since openssl is not doing anything in the kernel, that 5.71 seconds is all overhead – time stolen from this process for “system needs.”

Using openssl to Infer Networking Overhead

With an understanding of how 'openssl speed' works, let's look at a near idle server:

$ taskset -c 5 openssl speed -seconds 10 aes-256-cbc >/dev/null
Doing aes-256 cbc for 10s on 16 size blocks: 66675623 aes-256 cbc's in 9.99s
Doing aes-256 cbc for 10s on 64 size blocks: 18096647 aes-256 cbc's in 10.00s
Doing aes-256 cbc for 10s on 256 size blocks: 4607752 aes-256 cbc's in 10.00s
Doing aes-256 cbc for 10s on 1024 size blocks: 1162429 aes-256 cbc's in 10.00s
Doing aes-256 cbc for 10s on 8192 size blocks: 145251 aes-256 cbc's in 10.00s
Doing aes-256 cbc for 10s on 16384 size blocks: 72831 aes-256 cbc's in 10.00s

so in this case openssl reports 9.99 to 10.00 seconds of run time for each of the block sizes confirming no contention for the CPU. Let's add network load, netperf TCP_STREAM from 2 sources, and re-do the test:

$ taskset -c 5 openssl speed -seconds 10 aes-256-cbc >/dev/null
Doing aes-256 cbc for 10s on 16 size blocks: 12061658 aes-256 cbc's in 1.96s
Doing aes-256 cbc for 10s on 64 size blocks: 3457491 aes-256 cbc's in 2.10s
Doing aes-256 cbc for 10s on 256 size blocks: 893939 aes-256 cbc's in 2.01s
Doing aes-256 cbc for 10s on 1024 size blocks: 201756 aes-256 cbc's in 1.86s
Doing aes-256 cbc for 10s on 8192 size blocks: 25117 aes-256 cbc's in 1.78s
Doing aes-256 cbc for 10s on 16384 size blocks: 13859 aes-256 cbc's in 1.89s

Much different outcome. Each block size test wants to run for 10 seconds, but times() is reporting the actual user time to be between 1.78 and 2.10 seconds. Thus, the other 7.9 to 8.22 seconds was spent processing packets – either in the context of openssl or via ksoftirqd.

Looking at top for the previous openssl run:

 PID USER      PR  NI    VIRT    RES    SHR S  %CPU %MEM     TIME+ COMMAND              P
 8180 libvirt+  20   0 33.269g 1.649g 1.565g S 279.9  0.9  18:57.81 qemu-system-x86     75
 8374 root      20   0       0      0      0 R  99.4  0.0   2:57.97 vhost-8180          89
 1684 dahern    20   0   17112   4400   3892 R  73.6  0.0   0:09.91 openssl              5
   38 root      20   0       0      0      0 R  26.2  0.0   0:31.86 ksoftirqd/5          5

one would think openssl is using ~73% of cpu 5 with ksoftirqd taking the rest but in reality so many packets are getting processed in the context of openssl that it is only effectively getting 18-21% time on the cpu to make progress on its workload.

If I drop the network load to just 1 stream, openssl appears to be running at 99% CPU:

  PID USER      PR  NI    VIRT    RES    SHR S  %CPU %MEM     TIME+ COMMAND              P
 8180 libvirt+  20   0 33.269g 1.722g 1.637g S 325.1  0.9 166:38.12 qemu-system-x86     29
44218 dahern    20   0   17112   4488   3996 R  99.2  0.0   0:28.55 openssl              5
 8374 root      20   0       0      0      0 R  64.7  0.0  60:40.50 vhost-8180          55
   38 root      20   0       0      0      0 S   1.0  0.0   4:51.98 ksoftirqd/5          5

but openssl reports ~4 seconds of userspace time:

Doing aes-256 cbc for 10s on 16 size blocks: 26596388 aes-256 cbc's in 4.01s
Doing aes-256 cbc for 10s on 64 size blocks: 7137481 aes-256 cbc's in 4.14s
Doing aes-256 cbc for 10s on 256 size blocks: 1844565 aes-256 cbc's in 4.31s
Doing aes-256 cbc for 10s on 1024 size blocks: 472687 aes-256 cbc's in 4.28s
Doing aes-256 cbc for 10s on 8192 size blocks: 59001 aes-256 cbc's in 4.46s
Doing aes-256 cbc for 10s on 16384 size blocks: 28569 aes-256 cbc's in 4.16s

Again, monitoring tools show a lot of CPU access, but reality is much different with 55-80% of the CPU spent processing packets. The throughput numbers look great (22+Gbps for a 25G link), but the impact on processes is huge.

In this example, the process robbed of CPU cycles is a silly benchmark. On a fully populated host the interrupted process can be anything – virtual cpus for a VM, emulator threads for the VM, vhost threads for the VM, or host level system processes with varying degrees of impact on performance of those processes and the system.

Up Next

This post is the basis for a follow up post where I will discuss a comparison of the overhead of “full stack” on a VM host to “XDP”.

[1] Measured using ebpf program on entry and exit. See net_rx_action in https://github.com/dsahern/bpf-progs

[2] Assuming no bugs in the networking stack and driver. I have examined systems where net_rx_action takes well over 20,000 usec to process less than 64 packets due to a combination of bugs in the NIC driver (ARFS path) and OVS (thundering herd wakeup).

[3] https://github.com/isc-projects/ethq


Read more...
